IEC 60875-1:2024
(Main)Fibre optic interconnecting devices and passive components - Non-wavelength-selective fibre optic branching devices - Part 1: Generic specification
Fibre optic interconnecting devices and passive components - Non-wavelength-selective fibre optic branching devices - Part 1: Generic specification
IEC 60875-1:2024 applies to non-wavelength-selective fibre optic branching devices, all exhibiting the following features:
- they are passive, in that they contain no optoelectronic or other transducing elements;
- they have three or more ports for either the entry or exit, or both, of optical power, and share optical power among these ports in a predetermined fashion;
- the ports are optical fibres, or optical fibre connectors.
This document establishes uniform requirements for the optical, mechanical and environmental properties. This seventh edition cancels and replaces the sixth edition published in 2015. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
a) removal of variant and reference extensions in clause classification
b) removal of specification system in clause documentation
c) removal of interface standards, reliability standards and interlinking in clause standardization system
Dispositifs d'interconnexion et composants passifs fibroniques - Dispositifs de couplage fibroniques ne dépendant pas de la longueur d'onde - Partie 1: Spécification générique
L'IEC 60875-1:2024 s’applique aux dispositifs de couplage fibroniques qui ne dépendent pas de la longueur d’onde. Tous présentent les caractéristiques suivantes:
- ils sont passifs, au sens où ils ne contiennent aucun élément optoélectronique ou transducteur;
- ils ont trois ports ou plus pour l'entrée ou la sortie de la puissance optique, ou pour les deux, et ils partagent la puissance optique parmi ces ports, selon une modalité prédéterminée;
- les ports sont des fibres optiques ou des connecteurs à fibres optiques.
Le présent document établit des exigences uniformes relatives aux propriétés optiques, mécaniques et environnementales. Cette septième édition annule et remplace la sixième édition parue en 2015. Cette édition constitue une révision technique. Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
a) suppression des variantes et des extensions de référence dans la classification des articles;
b) suppression de la structure des spécifications dans la documentation des articles;
c) suppression des normes d’interface, des normes de fiabilité et des correspondances croisées dans le système de normalisation des articles.
General Information
Relations
Buy Standard
Standards Content (Sample)
IEC 60875-1 ®
Edition 7.0 2024-04
REDLINE VERSION
INTERNATIONAL
STANDARD
colour
inside
Fibre optic interconnecting devices and passive components – Non-wavelength-
selective fibre optic branching devices –
Part 1: Generic specification
All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form
or by any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from
either IEC or IEC's member National Committee in the country of the requester. If you have any questions about IEC
copyright or have an enquiry about obtaining additional rights to this publication, please contact the address below or
your local IEC member National Committee for further information.
IEC Secretariat Tel.: +41 22 919 02 11
3, rue de Varembé info@iec.ch
CH-1211 Geneva 20 www.iec.ch
Switzerland
About the IEC
The International Electrotechnical Commission (IEC) is the leading global organization that prepares and publishes
International Standards for all electrical, electronic and related technologies.
About IEC publications
The technical content of IEC publications is kept under constant review by the IEC. Please make sure that you have the
latest edition, a corrigendum or an amendment might have been published.
IEC publications search - webstore.iec.ch/advsearchform IEC Products & Services Portal - products.iec.ch
The advanced search enables to find IEC publications by a Discover our powerful search engine and read freely all the
variety of criteria (reference number, text, technical publications previews, graphical symbols and the glossary.
committee, …). It also gives information on projects, replaced With a subscription you will always have access to up to date
and withdrawn publications. content tailored to your needs.
IEC Just Published - webstore.iec.ch/justpublished
Electropedia - www.electropedia.org
Stay up to date on all new IEC publications. Just Published
The world's leading online dictionary on electrotechnology,
details all new publications released. Available online and once
containing more than 22 500 terminological entries in English
a month by email.
and French, with equivalent terms in 25 additional languages.
Also known as the International Electrotechnical Vocabulary
IEC Customer Service Centre - webstore.iec.ch/csc
(IEV) online.
If you wish to give us your feedback on this publication or need
further assistance, please contact the Customer Service
Centre: sales@iec.ch.
IEC 60875-1 ®
Edition 7.0 2024-04
REDLINE VERSION
INTERNATIONAL
STANDARD
colour
inside
Fibre optic interconnecting devices and passive components – Non-wavelength-
selective fibre optic branching devices –
Part 1: Generic specification
INTERNATIONAL
ELECTROTECHNICAL
COMMISSION
ICS 33.180.20 ISBN 978-2-8322-8768-2
– 2 – IEC 60875-1:2024 RLV © IEC 2024
CONTENTS
