IEC TR 62977-1-31:2021/AMD1:2022 (Amendment 1) is an IEC technical report amendment to Part 1‑31 of the electronic‑displays TR series. It provides additional, practical information on the use of light measuring devices (LMDs) for display metrology - in particular the influence of spectral stray light and the spectral bandwidth of spectroradiometers on chromaticity measurements. The amendment also corrects editorial errors and updates figures, notes and annex content of the 2021 edition.

Key topics and technical points

• Spectral stray light effects
  • Annex E gives experimental data showing how spectrometer stray light distorts measured spectral power distributions and computed CIE 1931 chromaticities.
  • Example: stray light magnitude was reduced from about 1:100–1:1 000 to 1:1 000–1:10 000 after correction.
  • Measured chromaticity differences (without minus with stray‑light correction): Red Δx = −0.0021, Δy = 0.0014; Green Δx = 0.0025, Δy = −0.0162; Blue Δx = 0.0008, Δy = 0.0006.
• Spectral bandwidth (instrument resolution)
  • Annex E demonstrates how increasing spectroradiometer bandwidth (FWHM) desaturates monochromatic (narrow‑linewidth) sources, with the green region most affected.
  • Presents synthetic‑spectrum simulations and explains how instrument bandwidth interacts with colour‑matching functions (CMFs) to bias tristimulus and chromaticity results.
• Measurement methods and corrections
  • Example measurement setup: integrating sphere + spectroradiometer used for retinal scanning projection display irradiance data (correction method valid for radiance as well).
  • Emphasises reducing background levels (stray light or electronic noise) to improve accuracy for saturated colours.
• Editorial and normative updates
  • Corrections to annexes on photometry/colorimetry (Annex A), colourimeter calibration (Annex B), input data and figures (Annex C), and the addition of Annex E.

Practical applications

• Ensures more accurate chromaticity and colour measurements for:
  • Display manufacturers (LCD, OLED, micro‑LED, laser projection, AR/VR retinal displays)
  • Test and calibration laboratories and NMI/metrology institutes
  • Instrument vendors (spectroradiometer/spectrometer designers)
  • Colour scientists and QA engineers performing production and R&D colorimetry
• Helps users decide appropriate LMD selection (wavelength accuracy, bandwidth, stray‑light performance), correction procedures, and interpretation of measurement uncertainty when testing highly saturated or narrow‑linewidth sources.

Related standards and references

• CIE 1931 colourimetry (used in chromaticity calculations) is cited throughout the amendment.
• The amendment sits within the IEC electronic‑displays TR series and complements instrument‑specific standards and manufacturer specifications for spectroradiometers and colourimeters.

Keywords: IEC TR 62977-1-31, amendment, electronic displays, spectroradiometer, spectral stray light, spectral bandwidth, chromaticity, colorimetry, display metrology, CIE 1931.
