1 Scope
This part of IEC 61755 defines dimensional limits and material properties of a 2,5 mm and a
1,25 mm diameter cylindrical composite ferrule optical interface to meet specific requirements
for PC fibre-to-fibre interconnection. The composite ferrule uses different materials in the end
face contact zone and in ferrule to sleeve contact zone. The specified materials for each zone
are zirconia (ZrO ) for the ferrule to sleeve contact zone and titanium for the end face contact
zone. Ferrules made from the material specified in this standard are suitable for use in
categories C, U, E and O as defined in IEC 61753-1.
NOTE If mated within the same family (cylindrical PC ferrule), the ferrules specified in this standard are intended
to have the same optical attenuation performance grade for connections with all ferrules described in different
parts of IEC 61775-3.
2 Description
The performance of a cylindrical ferrule optical interface is determined by the accuracy with
which the optical datum targets of two mating ferrules are aligned with each other. There are
three conditions affecting the alignment of two optical datum targets, lateral offset, angular
offset and longitudinal offset.
Parameters influencing the lateral and angular offset of the optical fibre axes include the
following:
• ferrule outside diameter;
• fibre hole concentricity relative to the ferrule outside diameter;
• fibre hole angle relative to outside diameter axis;
• fibre cladding diameter to fibre hole clearance;
• alignment sleeve inside diameter;
• fibre core concentricity relative to the cladding diameter;
• fibre core orientation relative to keying feature.
Parameters influencing the longitudinal offset of the optical fibre axes include the following:
• end face spherical radius;
• end face spherical radius apex offset;
• fibre undercut;
• axial force on ferrule end face;
• ferrule and fibre material physical constants;
• alignment sleeve frictional force.
