IEC 60384-23-1:2005

Fixed capacitors for use in electronic equipment - Part 23-1: Blank detail specification - Fixed surface mount metallized polyethylene naphthalate film dielectric DC capacitors - Assessment level EZ

supplementary document to the sectional specification and contains requirements for style, layout and minimum content of detail specifications. Detail specifications not complying with these requirements may not be considered as being in accordance with IEC specifications nor shall they so be described.

Condensateurs fixes utilisés dans les équipements électroniques - Partie 23-1: Spécification particulière cadre - Condensateurs fixes pour montage en surface pour courant continu à diélectrique en film de polyéthylène naphtalate métallisé - Niveau d'assurance de la qualité EZ

qui vient en supplément de la spécification intermédiaire et elle contient des exigences portant sur les modèles, la disposition et le contenu minimal des spécifications particulières. Les spécifications particulières qui ne sont pas conformes à ces exigences peuvent ne pas être considérées comme conformes aux spécifications CEI et elles ne doivent pas être décrites comme telles.

General Information

• Status: Withdrawn
• Publication Date: 09-Feb-2005
• Withdrawal Date: 06-Jul-2023
• ICS: 01 - GENERALITIES. TERMINOLOGY. STANDARDIZATION. DOCUMENTATION
• ICS: 31.060.10 - Fixed capacitors
• Technical Committee: TC 40 - Capacitors and resistors for electronic equipment
• Current Stage: WPUB - Publication withdrawn
• Start Date: 07-Jul-2023
• Completion Date: 07-Jul-2023

Standards Content (Sample)

INTERNATIONAL IEC
STANDARD 60384-23-1
First edition
2005-02
Fixed capacitors for use in electronic equipment –
Part 23-1:
Blank detail specification –
Fixed surface mount metallized polyethylene
naphthalate film dielectric DC capacitors –
Assessment level EZ
Reference number
Publication numbering
As from 1 January 1997 all IEC publications are issued with a designation in the
60000 series. For example, IEC 34-1 is now referred to as IEC 60034-1.

Consolidated editions
The IEC is now publishing consolidated versions of its publications. For example,

edition numbers 1.0, 1.1 and 1.2 refer, respectively, to the base publication, the
base publication incorporating amendment 1 and the base publication incorporating
amendments 1 and 2.
Further information on IEC publications
The technical content of IEC publications is kept under constant review by the IEC,
thus ensuring that the content reflects current technology. Information relating to
this publication, including its validity, is available in the IEC Catalogue of
publications (see below) in addition to new editions, amendments and corrigenda.
Information on the subjects under consideration and work in progress undertaken
by the technical committee which has prepared this publication, as well as the list
of publications issued, is also available from the following:
• IEC Web Site (www.iec.ch)
• Catalogue of IEC publications
The on-line catalogue on the IEC web site (www.iec.ch/searchpub) enables you to
search by a variety of criteria including text searches, technical committees
and date of publication. On-line information is also available on recently issued
publications, withdrawn and replaced publications, as well as corrigenda.
• IEC Just Published
This summary of recently issued publications (www.iec.ch/online_news/ justpub)
is also available by email. Please contact the Customer Service Centre (see
below) for further information.
• Customer Service Centre
If you have any questions regarding this publication or need further assistance,
please contact the Customer Service Centre:

Email: [e-mail]
Tel: [phone]
Fax: [phone]
INTERNATIONAL IEC
STANDARD 60384-23-1
First edition
2005-02
Fixed capacitors for use in electronic equipment –
Part 23-1:
Blank detail specification –
Fixed surface mount metallized polyethylene
naphthalate film dielectric DC capacitors –
Assessment level EZ
© IEC 2005 ⎯ Copyright - all rights reserved
No part of this publication may be reproduced or utilized in any form or by any means, electronic or
mechanical, including photocopying and microfilm, without permission in writing from the publisher.
International Electrotechnical Commission, 3, rue de Varembé, PO Box 131, CH-1211 Geneva 20, Switzerland
Telephone: [phone] Telefax: [phone] E-mail: [e-mail] Web: www.iec.ch
PRICE CODE
Commission Electrotechnique Internationale
M
International Electrotechnical Commission
Международная Электротехническая Комиссия
For price, see current catalogue

– 2 – 60384-23-1 IEC:2005(E)
INTERNATIONAL ELECTROTECHNICAL COMMISSION

____________
FIXED CAPACITORS FOR USE IN ELECTRONIC EQUIPMENT –

Part 23-1: Blank detail specification –

Fixed surface mount metallized polyethylene naphthalate film

dielectric DC capacitors – Assessment level EZ

FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising all
national electrotechnical committees (IEC National Committees). The object of IEC is to promote international co-
operation on all questions concerning standardization in the electrical and electronic fields. To this end and in
addition to other activities, IEC publishes International Standards, Technical Specifications, Technical Reports,
Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC Publication(s)”). Their preparation
is entrusted to technical committees; any IEC National Committee interested in the subject dealt with may
participate in this preparatory work. International, governmental and non-governmental organizations liaising with
the IEC also participate in this preparation. IEC collaborates closely with the International Organization for
Standardization (ISO) in accordance with conditions determined by agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all
interested IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence between
any IEC Publication and the corresponding national or regional publication shall be clearly indicated in the latter.
5) IEC provides no marking procedure to indicate its approval and cannot be rendered responsible for any equipment
declared to be in conformity with an IEC Publication.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and expenses
arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of patent
rights. IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 60384-23-1 has been prepared by IEC technical committee 40:

Capacitors and resistors for electronic equipment.
The text of this standard is based on the following documents:
FDIS Report on voting
40/1504/FDIS 40/1533/RVD
Full information on the voting for the approval of this standard can be found in the report on
voting indicated in the above table.
This publication has been drafted in accordance with the ISO/IEC Directives, Part 2.

60384-23-1  IEC:2005(E) – 3 –

IEC 60384 consists of the following parts, under the general title Fixed capacitors for use in
electronic equipment:
Part 1: Generic specification

Part 2: Sectional specification: Fixed metallized polyethylene-terephthalate film dielectric DC

capacitors
Part 3: Sectional specification: Fixed tantalum chip capacitors

Part 4: Sectional specification: Aluminium electrolytic capacitors with solid and non-solid

electrolyte
Part 5: Sectional specification: Fixed mica dielectric DC capacitors with a rated voltage not

exceeding 3000 V – Selection of methods of test and general requirements
Part 6: Sectional specification: Fixed metallized polycarbonate film dielectric DC capacitors
Part 7: Sectional specification: Fixed polystyrene film dielectric metal foil DC capacitors
Part 8: Sectional specification: Fixed capacitors of ceramic dielectric, Class 1
Part 9: Sectional specification: Fixed capacitors of ceramic dielectric, Class 2
Part 11: Sectional specification: Fixed polyethylene-terephthalate film dielectric metal foil DC
capacitors
Part 12: Sectional specification: Fixed polycarbonate film dielectric metal foil DC capacitors
Part 13: Sectional specification: Fixed polypropylene film dielectric metal foil DC capacitors
Part 14: Sectional specification: Fixed capacitors for electromagnetic interference suppression
and connection to the supply mains
Part 15: Sectional specification: Fixed tantalum capacitors with non-solid or solid electrolyte
Part 16: Sectional specification: Fixed metallized polypropylene film dielectric DC capacitors
Part 17: Sectional specification: Fixed metallized polypropylene film dielectric AC and pulse
capacitors
Part 18: Sectional specification: Fixed aluminium electrolytic chip capacitors with solid and
non-solid electrolyte
Part 19: Sectional specification: Fixed metallized polyethylene-terephthalate film dielectric
chip DC capacitors
Part 20: Sectional specification: Fixed metallized polyphenylene sulfide film dielectric chip DC
capacitors
Part 21: Sectional specification: Fixed surface mount multilayer capacitors of ceramic
dielectric, Class 1
Part 22: Sectional specification: Fixed surface mount multilayer capacitors of ceramic
dielectric, Class 2
Part 23: Sectional specification – Fixed surface mount metallized polyethylene naphthalate
film dielectric DC capacitors
The committee has decided that the contents of this publication will remain unchanged until the
maintenance result date indicated on the IEC web site under "http://webstore.iec.ch" in the data
related to the specific publication. At this date, the publication will be
• reconfirmed;
• withdrawn;
• replaced by a revised edition, or
• amended.
A bilingual version of this publication may be issued at a later date.

– 4 – 60384-23-1 IEC:2005(E)
FIXED CAPACITORS FOR USE IN ELECTRONIC EQUIPMENT –

Part 23-1: Blank detail specification –

Fixed surface mount metallized polyethylene naphthalate film

dielectric DC capacitors – Assessment level EZ

Blank detail specification
A blank detail specification is a supplementary document to the sectional specification and
contains requirements for style, layout and minimum content of detail specifications. Detail
specifications not complying with these requirements may not be considered as being in
accordance with IEC specifications nor shall they so be described.
In the preparation of detail specifications the content of 1.4 of the sectional specification shall be
taken into account.
The numbers between brackets on the first page correspond to the following information which
shall be inserted in the position indicated.
Identification of the detail specification
[1] The "International Electrotechnical Commission" or the National Standards Organisation
under whose authority the detail specification is drafted.
[2] The IEC or National Standards number of the detail specification, date of issue and any
further information required by the national system.
[3] The number and issue number of the IEC or national generic specification.
[4] The IEC number of the blank detail specification.
Identification of the capacitor
[5] A short description of the type of capacitor.
[6] Information on typical construction (when applicable).
[7] Outline drawing with main dimensions which are of importance for interchangeability and/or
reference to the national or international documents for outlines. Alternatively, this drawing
may be given in an appendix to the detail specification.
[8] Application or group of applications covered and/or assessment level.

NOTE The assessment level(s) to be used in a detail specification are selected from 3.5.4 of the sectional
specification This implies that one blank detail specification may be used in combination with several assessment
levels, provided the grouping of the tests does not change.
[9] Reference data on the most important properties, to allow comparison between the various
capacitor types.
60384-23-1  IEC:2005(E) – 5 –

IEC 60384-23-1-XXX
[1] QC 30YYYYXXXXXX [2]
ELECTRONIC COMPONENTS OF ASSESSED IEC 60384-23-1 [4]

QUALITY IN ACCORDANCE WITH: QC 30YYYY

[3] FIXED METALLIZED
POLYETHYLENE NAPHTHALATE
FILM DIELECTRIC CHIP DC [5]
Outline drawing: [see table 1]
CAPACITORS
[. angle projection]
[7]
[6]
Assessment level(s): EZ [8]
[Other shapes are permitted within the dimensions given]
For Notes [1] to [9] see preceding page.

[9]
Information on the availability of components qualified to this detail
specification is given in the IEC QC 001005.

1 General data
1.1 Recommended method(s) of mounting (to be inserted)
See 1.4.2 of IEC 60384-23.
1.2 Dimensions
Table 1 – Dimensions
Case size Dimensions
reference
mm
L W H L L L …
1 1 1 2 3 4
When there is no case size reference, Table 1 may be omitted and the dimensions shall be given
in Table 2, which then becomes Table 1.
The dimensions shall be given as maximum dimensions or as nominal dimensions with a
tolerance.
– 6 – 60384-23-1 IEC:2005(E)
1.3 Ratings and characteristics

Capacitance range (see Table 2)

Tolerance on rated capacitance

Rated voltage (see Table 2)
Category voltage (if applicable) (see Table 2)

Climatic category
Rated temperature
Max. AC voltage (if applicable)
Max pulse load (if applicable)
Tangent of loss angle
Insulation resistance
Table 2 – Values of capacitance and of voltage related to case sizes
Rated voltage
1)
Category voltage
Case size Case size Case size Case size
Rated capacitance
µF
1)
If different from the rated voltage.

1.4 Normative references
IEC 60384-1:1999, Fixed capacitors for use in electronic equipment – Part 1: Generic
specification
IEC 60384-23, Fixed capacitors for use in electronic equipment – Part 23: Sectional specification
1.5 Marking
The marking of the capacitor and the package shall be in accordance with the requirements of 1.6
of IEC 60384-23.
The details of the marking of the component and package shall be given in full in the detail
specification.
1.6 Ordering information
Orders for capacitors covered by this specification shall contain, in clear
...

IEC 60384-23-1
Edition 1.0 2005-02
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
Fixed capacitors for use in electronic equipment –
Part 23-1: Blank detail specification – Fixed surface mount metallized
polyethylene naphthalate film dielectric DC capacitors – Assessment level EZ

Condensateurs fixes utilisés –
Partie 23-1: Spécification particulière cadre – Condensateurs fixes pour montage
en surface pour courant continu à diélectrique en film de polyéthylène
naphtalate métallisé – Niveau d’assurance de la qualité EZ

All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form or by
any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from either IEC or
IEC's member National Committee in the country of the requester.
If you have any questions about IEC copyright or have an enquiry about obtaining additional rights to this publication,
please contact the address below or your local IEC member National Committee for further information.

Droits de reproduction réservés. Sauf indication contraire, aucune partie de cette publication ne peut être reproduite
ni utilisée sous quelque forme que ce soit et par aucun procédé, électronique ou mécanique, y compris la photocopie
et les microfilms, sans l'accord écrit de la CEI ou du Comité national de la CEI du pays du demandeur.
Si vous avez des questions sur le copyright de la CEI ou si vous désirez obtenir des droits supplémentaires sur cette
publication, utilisez les coordonnées ci-après ou contactez le Comité national de la CEI de votre pays de résidence.

IEC Central Office
3, rue de Varembé
CH-1211 Geneva 20
Switzerland
Email: [e-mail]
Web: www.iec.ch
About the IEC
The International Electrotechnical Commission (IEC) is the leading global organization that prepares and publishes
International Standards for all electrical, electronic and related technologies.

About IEC publications
The technical content of IEC publications is kept under constant review by the IEC. Please make sure that you have the
latest edition, a corrigenda or an amendment might have been published.
ƒ Catalogue of IEC publications: www.iec.ch/searchpub
The IEC on-line Catalogue enables you to search by a variety of criteria (reference number, text, technical committee,…).
It also gives information on projects, withdrawn and replaced publications.
ƒ IEC Just Published: www.iec.ch/online_news/justpub
Stay up to date on all new IEC publications. Just Published details twice a month all new publications released. Available
on-line and also by email.
ƒ Electropedia: www.electropedia.org
The world's leading online dictionary of electronic and electrical terms containing more than 20 000 terms and definitions
in English and French, with equivalent terms in additional languages. Also known as the International Electrotechnical
Vocabulary online.
ƒ Customer Service Centre: www.iec.ch/webstore/custserv
If you wish to give us your feedback on this publication or need further assistance, please visit the Customer Service
Centre FAQ or contact us:
Email: [e-mail]
Tel.: [phone]
Fax: [phone]
A propos de la CEI
La Commission Electrotechnique Internationale (CEI) est la première organisation mondiale qui élabore et publie des
normes internationales pour tout ce qui a trait à l'électricité, à l'électronique et aux technologies apparentées.

A propos des publications CEI
Le contenu technique des publications de la CEI est constamment revu. Veuillez vous assurer que vous possédez
l’édition la plus récente, un corrigendum ou amendement peut avoir été publié.
ƒ Catalogue des publications de la CEI: www.iec.ch/searchpub/cur_fut-f.htm
Le Catalogue en-ligne de la CEI vous permet d’effectuer des recherches en utilisant différents critères (numéro de référence,
texte, comité d’études,…). Il donne aussi des informations sur les projets et les publications retirées ou remplacées.
ƒ Just Published CEI: www.iec.ch/online_news/justpub
Restez informé sur les nouvelles publications de la CEI. Just Published détaille deux fois par mois les nouvelles
publications parues. Disponible en-ligne et aussi par email.
ƒ Electropedia: www.electropedia.org
Le premier dictionnaire en ligne au monde de termes électroniques et électriques. Il contient plus de 20 000 termes et
définitions en anglais et en français, ainsi que les termes équivalents dans les langues additionnelles. Egalement appelé
Vocabulaire Electrotechnique International en ligne.
ƒ Service Clients: www.iec.ch/webstore/custserv/custserv_entry-f.htm
Si vous désirez nous donner des commentaires sur cette publication ou si vous avez des questions, visitez le FAQ du
Service clients ou contactez-nous:
Email: [e-mail]
Tél.: [phone]
Fax: [phone]
IEC 60384-23-1
Edition 1.0 2005-02
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
Fixed capacitors for use in electronic equipment –
Part 23-1: Blank detail specification – Fixed surface mount metallized
polyethylene naphthalate film dielectric DC capacitors – Assessment level EZ

Condensateurs fixes utilisés –
Partie 23-1: Spécification particulière cadre – Condensateurs fixes pour
montage en surface pour courant continu à diélectrique en film de polyéthylène
naphtalate métallisé – Niveau d’assurance de la qualité EZ

INTERNATIONAL
ELECTROTECHNICAL
COMMISSION
COMMISSION
ELECTROTECHNIQUE
PRICE CODE
INTERNATIONALE
M
CODE PRIX
ICS 31.060.10 ISBN 2-8318-8655-4
– 2 – 60384-23-1 © CEI:2005
COMMISSION ÉLECTROTECHNIQUE INTERNATIONALE
____________
CONDENSATEURS FIXES UTILISÉS
DANS LES ÉQUIPEMENTS ÉLECTRONIQUES –

Partie 23-1: Spécification particulière cadre –
Condensateurs fixes pour montage en surface pour courant continu
à diélectrique en film de polyéthylène naphtalate métallisé –
Niveau d’assurance de la qualité EZ

AVANT-PROPOS
1) La Commission Electrotechnique Internationale (CEI) est une organisation mondiale de normalisation composée de
l'ensemble des comités électrotechniques nationaux (Comités nationaux de la CEI). La CEI a pour objet de favoriser
la coopération internationale pour toutes les questions de normalisation dans les domaines de l'électricité et de
l'électronique. A cet effet, la CEI – entre autres activités – publie des Normes internationales, des Spécifications
techniques, des Rapports techniques, des Spécifications accessibles au public (PAS) et des Guides (ci-après
dénommés "Publication(s) de la CEI"). Leur élaboration est confiée à des comités d'études, aux travaux desquels tout
Comité national intéressé par le sujet traité peut participer. Les organisations internationales, gouvernementales et
non gouvernementales, en liaison avec la CEI, participent également aux travaux. La CEI collabore étroitement avec
l'Organisation Internationale de Normalisation (ISO), selon des conditions fixées par accord entre les deux
organisations.
2) Les décisions ou accords officiels de la CEI concernant les questions techniques représentent, dans la mesure du
possible, un accord international sur les sujets étudiés, étant donné que les Comités nationaux de la CEI intéressés
sont représentés dans chaque comité d’études.
3) Les Publications de la CEI se présentent sous la forme de recommandations internationales et sont agréées comme
telles par les Comités nationaux de la CEI. Tous les efforts raisonnables sont entrepris afin que la CEI s'assure de
l'exactitude du contenu technique de ses publications; la CEI ne peut pas être tenue responsable de l'éventuelle
mauvaise utilisation ou interprétation qui en est faite par un quelconque utilisateur final.
4) Dans le but d'encourager l'uniformité internationale, les Comités nationaux de la CEI s'engagent, dans toute la
mesure possible, à appliquer de façon transparente les Publications de la CEI dans leurs publications nationales et
régionales. Toutes divergences entre toutes Publications de la CEI et toutes publications nationales ou régionales
correspondantes doivent être indiquées en termes clairs dans ces dernières.
5) La CEI n’a prévu aucune procédure de marquage valant indication d’approbation et n'engage pas sa responsabilité
pour les équipements déclarés conformes à une de ses Publications.
6) Tous les utilisateurs doivent s'assurer qu'ils sont en possession de la dernière édition de cette publication.
7) Aucune responsabilité ne doit être imputée à la CEI, à ses administrateurs, employés, auxiliaires ou mandataires, y
compris ses experts particuliers et les membres de ses comités d'études et des Comités nationaux de la CEI, pour
tout préjudice causé en cas de dommages corporels et matériels, ou de tout autre dommage de quelque nature que
ce soit, directe ou indirecte, ou pour supporter les coûts (y compris les frais de justice) et les dépenses découlant de
la publication ou de l'utilisation de cette Publication de la CEI ou de toute autre Publication de la CEI, ou au crédit qui
lui est accordé.
8) L'attention est attirée sur les références normatives citées dans cette publication. L'utilisation de publications
référencées est obligatoire pour une application correcte de la présente publication.
9) L’attention est attirée sur le fait que certains des éléments de la présente Publication de la CEI peuvent faire l’objet
de droits de propriété intellectuelle ou de droits analogues. La CEI ne saurait être tenue pour responsable de ne pas
avoir identifié de tels droits de propriété et de ne pas avoir signalé leur existence.
La Norme internationale CEI 60384-23-1 a été établie par le comité d’études 40 de la CEI:
Condensateurs et résistances pour équipements électroniques.
Cette version bilingue, publiée en 2006-05, correspond à la version anglaise.
Le texte anglais de cette norme est issu des documents 40/1504/FDIS et 40/1533/RVD.
Le rapport de vote 40/1533/RVD donne toute information sur le vote ayant abouti à l'approbation
de cette norme.
La version française de cette norme n’a pas été soumise au vote.

60384-23-1 © IEC:2005 – 3 –
INTERNATIONAL ELECTROTECHNICAL COMMISSION
____________
FIXED CAPACITORS FOR USE IN ELECTRONIC EQUIPMENT –

Part 23-1: Blank detail specification –
Fixed surface mount metallized polyethylene naphthalate film
dielectric DC capacitors – Assessment level EZ

FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising all
national electrotechnical committees (IEC National Committees). The object of IEC is to promote international co-
operation on all questions concerning standardization in the electrical and electronic fields. To this end and in
addition to other activities, IEC publishes International Standards, Technical Specifications, Technical Reports,
Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC Publication(s)”). Their preparation is
entrusted to technical committees; any IEC National Committee interested in the subject dealt with may participate in
this preparatory work. International, governmental and non-governmental organizations liaising with the IEC also
participate in this preparation. IEC collaborates closely with the International Organization for Standardization (ISO) in
accordance with conditions determined by agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all interested
IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence between any
IEC Publication and the corresponding national or regional publication shall be clearly indicated in the latter.
5) IEC provides no marking procedure to indicate its approval and cannot be rendered responsible for any equipment
declared to be in conformity with an IEC Publication.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or other
damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and expenses arising
out of the publication, use of, or reliance upon, this IEC Publication or any other IEC Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of patent
rights. IEC shall not be held responsible for identifying any or all such patent rights.
International Standard IEC 60384-23-1 has been prepared by IEC technical committee 40:
Capacitors and resistors for electronic equipment.
This bilingual version, published in 2006-05, corresponds to the English version.
The text of this standard is based on the following documents:
FDIS Report on voting
40/1504/FDIS 40/1533/RVD
Full information on the voting for the approval of this standard can be found in the report on voting
indicated in the above table.
The French version of this standard has not been voted upon.

– 4 – 60384-23-1 © CEI:2005
Cette publication a été rédigée selon les Directives ISO/CEI, Partie 2.
La CEI 60384 comprend les parties suivantes, sous le titre général Condensateurs fixes utilisés
dans les équipements électroniques:
Partie 1: Spécification générique
Partie 2: Spécification intermédiaire: Condensateurs fixes pour courant continu à diélectrique
en film de polytérépht
...
