Standards Content (Sample)

INTERNATIONAL ISO
STANDARD 15156-3
Fourth edition
2020-11
Petroleum and natural gas
industries — Materials for use in H S-
2
containing environments in oil and
gas production —
Part 3:
Cracking-resistant CRAs (corrosion-
resistant alloys) and other alloys
Industries du pétrole et du gaz naturel — Matériaux pour utilisation
dans des environnements contenant de l'hydrogène sulfuré (H S) dans
2
la production de pétrole et de gaz —
Partie 3: ARC (alliages résistants à la corrosion) et autres alliages
résistants à la fissuration
Reference number
ISO 15156-3:2020(E)
©
ISO 2020

---------------------- Page: 1 ----------------------
ISO 15156-3:2020(E)

COPYRIGHT PROTECTED DOCUMENT
© ISO 2020
All rights reserved. Unless otherwise specified, or required in the context of its implementation, no part of this publication may
be reproduced or utilized otherwise in any form or by any means, electronic or mechanical, including photocopying, or posting
on the internet or an intranet, without prior written permission. Permission can be requested from either ISO at the address
below or ISO’s member body in the country of the requester.
ISO copyright office
CP 401 • Ch. de Blandonnet 8
CH-1214 Vernier, Geneva
Phone: +41 22 749 01 11
Email: copyright@iso.org
Website: www.iso.org
Published in Switzerland
ii © ISO 2020 – All rights reserved

---------------------- Page: 2 ----------------------
ISO 15156-3:2020(E)

Contents Page
Foreword .iv
Introduction .vi
1 Scope . 1
2 Normative references . 2
3 Terms and definitions . 3
4 Symbols and abbreviated terms . 5
5 Factors affecting the cracking-resistance of CRAs and other alloys in H S-containing
2
environments . 6
6 Qualification and selection of CRAs and other alloys with respect to SSC, SCC, and
GHSC in H S-containing environments . 6
2
6.1 General . 6
6.2 Evaluation of materials properties . 7
6.2.1 Hardness of parent metals . 7
6.2.2 Cracking-resistance properties of welds. 7
6.2.3 Cracking-resistance properties associated with other fabrication methods . 8
6.3 PREN . 9
7 Purchasing information and marking . 9
7.1 Information that should be supplied for material purchasing . 9
7.2 Marking, labelling, and documentation .10
Annex A (normative) Environmental cracking-resistant CRAs and other alloys (including
Table A.1 — Guidance on the use of the materials selection tables) .11
Annex B (normative) Qualification of CRAs for H S-service by laboratory testing .57
2
Annex C (informative) Information that should be supplied for material purchasing .67
Annex D (informative) Nominated sets of test conditions .69
Bibliography .70
© ISO 2020 – All rights reserved iii

---------------------- Page: 3 ----------------------
ISO 15156-3:2020(E)

Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards
bodies (ISO member bodies). The work of preparing International Standards is normally carried out
through ISO technical committees. Each member body interested in a subject for which a technical
committee has been established has the right to be represented on that committee. International
organizations, governmental and non-governmental, in liaison with ISO, also take part in the work.
ISO collaborates closely with the International Electrotechnical Commission (IEC) on all matters of
electrotechnical standardization.
The procedures used to develop this document and those intended for its further maintenance are
described in the ISO/IEC Directives, Part 1. In particular, the different approval criteria needed for the
different types of ISO documents should be noted. This document was drafted in accordance with the
editorial rules of the ISO/IEC Directives, Part 2 (see www .iso .org/ directives).
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. ISO shall not be held responsible for identifying any or all such patent rights. Details of
any patent rights identified during the development of the document will be in the Introduction and/or
on the ISO list of patent declarations received (see www .iso .org/ patents).
Any trade name used in this document is information given for the convenience of users and does not
constitute an endorsement.
For an explanation of the voluntary nature of standards, the meaning of ISO specific terms and
expressions related to conformity assessment, as well as information about ISO's adherence to the
World Trade Organization (WTO) principles in the Technical Barriers to Trade (TBT), see www .iso .org/
iso/ foreword .html.
This document was prepared by Technical Committee ISO/TC 67, Materials, equipment and offshore
structures for petroleum, petrochemical and natural gas industries, in collaboration with the European
Committee for Standardization (CEN) Technical Committee CEN/TC 12, Materials, equipment and
offshore structures for petroleum, petrochemical and natural gas industries, in accordance with the
Agreement on technical cooperation between ISO and CEN (Vienna Agreement).
This fourth edition cancels and replaces the third edition (ISO 15156-3:2015), which has been
technically revised. The main changes compared to the previous edition are as follows:
— Table A.27 UNS S17400 (17-4PH SS) has new limits. The use of the alloy at the annotated environmental
conditions is now limited to applications where sustained stress is no more than 50 % of SMYS;
— Table A.32 new limits and annotations for UNS N09946 separate from UNS N09945;
— Table A.41 inclusion of UNS R55400 (new a-b Ti alloy);
— Table A.3 UNS S20910 (Nitronic 50) note modifications;
— Tables A.22, A.23, A.26 through A.30, and A.33 temperature conversion corrections;
— Table A.23 new note for maximum design tensile stress for UNS J91540;
— Table A.32 newly added UNS N07718 (high strength Alloy 718, with two-step aging cycle, meeting
API 6A CRA composition and a maximum hardness of 45 HRC) and UNS N09955 requirements and
note letters designation changes on UNS N09925, N09935, N09945 and N09946;
— Table A.40 title modification and note clarification;
— Clause A.13 Cladding, overlays, and wear-resistant alloys modifications;
— Table A.18 and Table A.19 (Martensitic SS) remarks modifications;
— Table A.24 Duplex SS Hot Isostatically Pressed (HIP) inclusion and remarks modification;
iv © ISO 2020 – All rights reserved

---------------------- Page: 4 ----------------------
ISO 15156-3:2020(E)

— the informative Annex D, "Materials chemical compositions and other information", has been
removed due to copyright reasons;
— additions to the bibliography.
A list of all parts in the ISO 15156 series can be found on the ISO website.
Any feedback or questions on this document should be directed to the user’s national standards body. A
complete listing of these bodies can be found at www .iso .org/ members .html.
© ISO 2020 – All rights reserved v

---------------------- Page: 5 ----------------------
ISO 15156-3:2020(E)

Introduction
The consequences of sudden failures of metallic oil and gas field components associated with their
exposure to H S-containing production fluids led to the preparation of the first edition of NACE MR0175
2
which was published in 1975 by the National Association of Corrosion Engineers, now known as NACE
International.
The original and subsequent editions of NACE MR0175 established limits of H S partial pressure above
2
which precautions against sulfide stress cracking (SSC) were always considered necessary. They
also provided guidance for the selection and specification of SSC-resistant materials when the H S
2
thresholds were exceeded. In more recent editions, NACE MR0175 has also provided application limits
for some corrosion-resistant alloys in terms of environmental composition and pH, temperature, and
H S partial pressures.
2
In separate developments, the European Federation of Corrosion issued EFC Publication 16 in 1995 and
EFC Publication 17 in 1996. These documents are generally complementary to those of NACE, though
they differed in scope and detail.
In 2003, the publication of the ISO 15156 series and NACE MR0175/ISO 15156 was completed for the
first time. These technically identical documents utilized the above sources to provide requirements
and recommendations for materials qualification and selection for application in environments
containing wet H S in oil and gas production systems. They are complemented by NACE TM0177 and
2
NACE TM0284 test methods.
The revision of this document, i.e. ISO 15156, involves a consolidation of all changes agreed and published
in the Technical Circular 1, ISO 15156-3:2015/Cir.1:2016, the Technical Circular 2, ISO 15156-3:2015/
Cir.2:2018 and the Technical Circular 3, ISO 15156-3:2015/Cir.3:2019, published by the ISO 15156 series
Maintenance Agency secretariat at DIN.
The changes were developed by, and approved by the ballot of, representative groups from within
the oil and gas production industry. The great majority of these changes stem from issues raised by
document users. A description of the process by which these changes were approved can be found at
the ISO 15156 series maintenance website: www .iso .org/ iso15156maintenance.
When found necessary by oil and gas production industry experts, future interim changes to this
document will be processed in the same way and will lead to interim updates to this document in
the form of Technical Corrigenda or Technical Circulars. Document users should be aware that such
documents can exist and can impact the validity of the dated references in this document.
The ISO 15156 series Maintenance Agency at DIN was set up after approval by the ISO Technical
Management Board given in document 34/2007. This document describes the makeup of the agency,
which includes experts from NACE, EFC, and ISO/TC 67, and the process for approval of amendments.
It is available from the ISO 15156 series maintenance website and from the ISO/TC 67 Secretariat. The
website also provides access to related documents that provide more detail of the ISO 15156 series
maintenance activities.
vi © ISO 2020 – All rights reserved

---------------------- Page: 6 ----------------------
INTERNATIONAL STANDARD ISO 15156-3:2020(E)
Petroleum and natural gas industries — Materials
for use in H S-containing environments in oil and gas
2
production —
Part 3:
Cracking-resistant CRAs (corrosion-resistant alloys) and
other alloys
WARNING — CRAs (corrosion-resistant alloys) and other alloys selected using this document
are resistant to cracking in defined HS-containing environments in oil and gas production,
2
but not necessarily immune to cracking under all service conditions. It is the equipment user's
responsibility to select the CRAs and other alloys suitable for the intended service.
1 Scope
This document gives requirements and recommendations for the selection and qualification of CRAs
(corrosion-resistant alloys) and other alloys for service in equipment used in oil and natural gas
production and natural gas treatment plants in H S-containing environments whose failure can pose
2
a risk to the health and safety of the public and personnel or to the environment. It can be applied to
help avoid costly corrosion damage to the equipment itself. It supplements, but does not replace, the
materials requirements of the appropriate design codes, standards, or regulations.
This document addresses the resistance of these materials to damage that can be caused by sulfide
stress cracking (SSC), stress corrosion cracking (SCC), and galvanically induced hydrogen stress
cracking (GHSC).
This document is concerned only with cracking. Loss of material by general (mass loss) or localized
corrosion is not addressed.
Table 1 provides a non-exhaustive list of equipment to which this document is applicable, including
exclusions.
This document applies to the qualification and selection of materials for equipment designed and
constructed using load controlled design methods. For design utilizing strain-based design methods,
see ISO 15156-1:2020, Clause 5.
This document is not necessarily suitable for application to equipment used in refining or downstream
processes and equipment.
© ISO 2020 – All rights reserved 1

---------------------- Page: 7 ----------------------
ISO 15156-3:2020(E)

Table 1 — List of equipment
This document is applicable to materials used for the Exclusions
following equipment
Drilling, well construction, and well-servicing Equipment exposed only to drilling fluids of con-
equipment trolled
a
composition
Drill bits
b
Blowout-preventer (BOP) shear blades
Drilling riser systems
Work strings
c
Wireline and wireline equipment
Surface and intermediate casing
d
Wells including subsurface equipment, gas lift Sucker rod pumps and sucker rods
equipment, wellheads, and christmas trees
Electric submersible pumps
Other artificial lift equipment
Slips
Flow-lines, gathering lines, field facilities, and field Crude oil storage and handling facilities operating
processing plants at
a total absolute pressure below 0,45 MPa (65 psi)
Water-handling equipment Water-handling facilities operating at a total
absolute
pressure below 0,45 MPa (65 psi)
Water injection and water disposal equipment
Natural gas treatment plants —
Transportation pipelines for liquids, gases, and Lines handling gas prepared for general commer-
multi-phase fluids cial
and domestic use
For all equipment above Components loaded only in compression
a
See ISO 15156-2:2020, A.2.3.2.3 for more information.
b
See ISO 15156-2:2020, A.2.3.2.1 for more information.
c
Wireline lubricators and lubricator connecting devices are not excluded.
d
For sucker rod pumps and sucker rods, reference can be made to NACE MR0176.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 6507-1, Metallic materials — Vickers hardness test — Part 1: Test method
ISO 6508-1, Metallic materials — Rockwell hardness test — Part 1: Test method
ISO 6892-1, Metallic materials — Tensile testing — Part 1: Method of test at room temperature
ISO 10423, Petroleum and natural gas industries — Drilling and production equipment — Wellhead and
christmas tree equipment
ISO 11960, Petroleum and natural gas industries — Steel pipes for use as casing or tubing for wells
2 © ISO 2020 – All rights reserved

---------------------- Page: 8 ----------------------
ISO 15156-3:2020(E)

ISO 15156-1:2020, Petroleum and natural gas industries — Materials for use in H S-containing
2
environments in oil and gas production — Part 1: General principles for selection of cracking-resistant
materials
ISO 15156-2:2020, Petroleum and natural gas industries — Materials for use in H S-containing
2
environments in oil and gas production — Part 2: Cracking-resistant carbon and low alloy steels, and the
use of cast irons
1)
ASTM A747/A747M , Standard Specification for Steel Castings, Stainless, Precipitation Hardening
ASTM E29, Standard Practice for Using Significant Digits in Test Data to Determine Conformance with
Specifications
ASTM E562, Standard Test Method for Determining Volume Fraction by Systematic Manual Point Count
2)
EFC Publication 17 , Corrosion resistant alloys for oil and gas production: guidelines on general
requirements and test methods for H S service
2

NACE CORROSION/95 Paper 47, Test methodology for elemental sulfur-resistant advanced materials for oil
and gas field equipment
NACE TM0177: 2016, Laboratory testing of metals for resistance to sulfide stress cracking and stress
corrosion cracking in H S environments
2
3)
SAE AMS-2430 , Shot Peening
SAE — ASTM, Metals and alloys in the Unified Numbering System
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 15156-1, ISO 15156-2 and the
following apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at http:// www .electropedia .org/
3.1
ageing
change in metallurgical properties that generally occurs slowly at room temperature (natural ageing)
and more rapidly at higher temperature (artificial ageing)
3.2
anneal
heat to and hold at a temperature appropriate for the specific material and then cool at a suitable rate
for such purposes as reducing hardness, improving machineability, or obtaining desired properties
3.3
austenite
face-centred cubic crystalline phase of iron-based alloys
1) www .astm .org
2) www .efcweb .org
3) www .sae .org
© ISO 2020 – All rights reserved 3

---------------------- Page: 9 ----------------------
ISO 15156-3:2020(E)

3.4
duplex stainless steel
austenitic/ferritic stainless steel
stainless steel (3.13) whose microstructure at room temperature consists primarily of a mixture of
austenite (3.3) and ferrite (3.5)
3.5
ferrite
body-centred cubic crystalline phase of iron-based alloys
3.6
ferritic stainless steel
stainless steel (3.13) whose microstructure at room temperature consists predominantly of ferrite (3.5)
3.7
galvanically induced hydrogen stress cracking
GHSC
cracking that results due to the presence of hydrogen in a metal induced in the cathode of a galvanic
couple and tensile stress (residual and/or applied)
3.8
martensite
hard, supersaturated solid solution of carbon in iron characterized by an acicular (needle-like)
microstructure
3.9
martensitic steel
steel in which a microstructure of martensite (3.8) can be attained by quenching at a cooling rate fast
enough to avoid the formation of other microstructures
3.10
pitting-resistance equivalent number
PREN
F
PREN
number developed to reflect and predict the pitting resistance of a CRA based upon the proportions of
the elements Cr, Mo, W, and N in the chemical composition of the alloy
Note 1 to entry: See 6.3 for further information.
3.11
production environment
natural occurring produced fluids without contamination from chemicals that will temporarily or
continuously reduce the in situ pH
Note 1 to entry: Flow back of chemicals for stimulation and scale removal may temporarily reduce the pH
significantly and some continuously injected chemicals, such as scale inhibitors, can continuously reduce pH.
3.12
solid solution
single crystalline phase containing two or more elements
3.13
stainless steel
steel containing 10,5 % mass fraction or more chromium, possibly with other elements added to secure
special properties
4 © ISO 2020 – All rights reserved

---------------------- Page: 10 ----------------------
ISO 15156-3:2020(E)

4 Symbols and abbreviated terms
AYS actual yield strength
bal balance of composition up to 100 %
BOP blowout preventer
CR c-ring
CRA corrosion-resistant alloy
DCB double cantilever beam (test)
FPB four-point bend (test)
GHSC galvanically induced hydrogen stress cracking
HAZ heat-affected zone
HBW Brinell hardness
HIC hydrogen-induced cracking
HIP hot isostatically pressed
HRB Rockwell hardness (scale B)
HRC Rockwell hardness (scale C)
HSC hydrogen stress cracking
HV Vickers hardness
NDS no data submitted
pCO partial pressure of CO
2 2
pH S partial pressure of H S
2 2
PREN pitting-resistance equivalent number
PWHT post-weld heat treatment
RSRT rippled strain rate test
0
S elemental sulfur
SCC stress-corrosion cracking
SMYS specified minimum yield strength
SOHIC stress-oriented hydrogen-induced cracking
SSC sulfide stress cracking
SSRT slow strain rate test
© ISO 2020 – All rights reserved 5

---------------------- Page: 11 ----------------------
ISO 15156-3:2020(E)

SZC soft-zone cracking
UNS unified (alloy) numbering system
UT uniaxial tensile (test)
5 Factors affecting the cracking-resistance of CRAs and other alloys in H S-
2
containing environments
The cracking behaviour of CRAs and other alloys in H S-containing environments can be affected by
2
complex interactions of parameters including the following:
— chemical composition, strength, heat treatment, microstructure, method of manufacture, and
finished condition of the material;
— H S partial pressure or equivalent dissolved concentration in the water phase;
2
— acidity (in situ pH) of the water phase;
— chloride or other halide ion concentration;
— presence of oxygen, sulfur, or other oxidants;
— exposure temperature;
— pitting resistance of the material in the service environment;
— galvanic effects;
— total tensile stress (applied plus residual);
— exposure time.
These factors shall be considered when using this document for the selection of materials suitable for
environments containing H S in oil and gas production systems.
2
6 Qualification and selection of CRAs and other alloys with respect to SSC, SCC,
and GHSC in H S-containing environments
2
6.1 General
CRAs and other alloys shall be selected for their resistance to SSC, SCC, and/or GHSC as required by the
intended service.
Conformance of a CRA or other alloy with this document implies cracking-resistance within defined
environmental service limits. These limits are dependent on the material type or the individual alloy.
To enable qualification and/or selection of CRAs and other alloys, the equipment purchaser can be
required to provide information on the proposed conditions of exposure to the equipment supplier.
In defining the severity of H S-containing environments, exposures that can occur during system
2
upsets or shutdowns, etc. shall also be considered. Such exposures can include unbuffered, low pH
condensed water. The limits given in the tables in Annex A are for production environments and do not
cover conditions occurring during injection or flowback of chemicals that can reduce the in situ pH.
CRAs and other alloys shall be selected using Annex A or following qualification by successful
laboratory testing in accordance with Annex B. Qualification based on satisfactory field experience is
also acceptable. Such qualification shall conform with ISO 15156-1.
6 © ISO 2020 – All rights reserved

---------------------- Page: 12 ----------------------
ISO 15156-3:2020(E)

In Annex A, materials are identified by materials groups. Within each group, alloys are identified by
materials type (within compositional limits) or as individual alloys. Acceptable metallurgical conditions
and environmental limits are given for which alloys are expected to resist cracking. Environmental
limits are given for H S partial pressure, temperature, chloride concentration, and elemental sulfur.
2
A CRA or other alloy can be qualified by testing for use under operating conditions that are more severe
than the environmental limits given in Annex A. Similarly, a CRA or other alloy can be qualified for use
in different metallurgical conditions (higher strength, alternative heat treatment, etc.) to those given in
Annex A.
The documentation of qualifications performed in accordance with Annex B shall meet the requirements
in ISO 15156-1:2020, Clause 9.
The equipment user shall verify qualifications (see B.2.2) and retain documentation supporting the
materials selections made.
6.2 Evaluation of materials properties
6.2.1 Hardness of parent metals
If hardness measurements on parent metal are specified, sufficient hardness tests shall be made
to establish the actual hardness of the CRA or other alloy being examined. Individual HRC readings
exceeding the value permitted by this document may be considered acceptable if the average of several
readings taken within close proximity does not exceed the value permitted by this document and no
individual reading is greater than 2 HRC above the specified value. Equivalent requirements shall
apply to other methods of hardness measurement when specified in this document or referenced in a
manufacturing specification.
The conversion of hardness readings to or from other scales is material-dependent. The user may
establish the required conversion tables.
NOTE The number and location of hardness tests on parent metal are not specified in ISO 15156 (all parts).
6.2.2 Cracking-resistance properties of welds
6.2.2.1 General
The metallurgical changes that occur when welding CRAs and other alloys can affect their susceptibility
to SSC, SCC, and/or GHSC. Welded joints can have a greater susceptibility to cracking than the parent
material(s) joined.
The equipment user may allow the cracking susceptibility of weldments to govern the limits of safe
service conditions for a fabricated system.
Processes and consumables used in welding should be selected in accordance with good practice and to
achieve the required corrosion and cracking resistances.
Welding shall be carried out in conformance with appropriate codes and standards as agreed between
the supplier and the purchaser. Welding procedure specifications (WPSs) and procedure qualification
records (PQRs) shall be available for inspection by the equipment user.
Welding PQRs shall include documented evidence demonstrating satisfactory cracking resistance
under conditions at least as severe as those of the proposed application. Such evidence shall be based
upon one or more of the following:
— conformance with the requirements and recommendations for the specific materials group of
Annex A (see also 6.2.2.2 and 6.2.2.3);
— weld cracking-resistance qualification testing in accordance with Annex B;
© ISO 2020 – All rights reserved 7

---------------------- Page: 13 ----------------------
ISO 15156-3:2020(E)

— documented field experience modelled upon that specified for parent materials in ISO 15156-1.
The requirements and recommendations given in Annex A might not be appropriate for all combinations
of parent and weld metals used in the fabrication of equipment and components. The equipment user
may require evidence of successful cracking-resistance testing as part of the welding procedure
qualification to ensure the weldment produced provides adequate resistance to SSC, SCC, and GHSC for
the application.
6.2.2.2 Qualification of welding procedures in accordance with Annex A based upon hardness
6.2.2.2.1 General
The qualification of welding procedures for sour service shall, if specified in Annex A, include hardness
testing in accordance with 6.2.2.2.2, 6.2.2.2.3 and 6.2.2.2.4.
6.2.2.2.2 Hardness testing methods for welding procedure qualification
Unless otherwise approved by the user, hardness testing for welding procedure qualification shall be
carried out using Vickers HV 10 or HV 5 methods in accordance with ISO 6507-1 or the Rockwell 15N
method in accordance with ISO 6508
...

FINAL
INTERNATIONAL ISO/FDIS
DRAFT
STANDARD 15156-3
ISO/TC 67
Petroleum and natural gas
Secretariat: NEN
industries — Materials for use in H S-
2
Voting begins on:
2020-06-19 containing environments in oil and
gas production —
Voting terminates on:
2020-09-11
Part 3:
Cracking-resistant CRAs (corrosion-
resistant alloys) and other alloys
Industries du pétrole et du gaz naturel — Matériaux pour utilisation
dans des environnements contenant de l'hydrogène sulfuré (H S) dans
2
la production de pétrole et de gaz —
Partie 3: ARC (alliages résistants à la corrosion) et autres alliages
résistants à la fissuration
ISO/CEN PARALLEL PROCESSING
RECIPIENTS OF THIS DRAFT ARE INVITED TO
SUBMIT, WITH THEIR COMMENTS, NOTIFICATION
OF ANY RELEVANT PATENT RIGHTS OF WHICH
THEY ARE AWARE AND TO PROVIDE SUPPOR TING
DOCUMENTATION.
IN ADDITION TO THEIR EVALUATION AS
Reference number
BEING ACCEPTABLE FOR INDUSTRIAL, TECHNO-
ISO/FDIS 15156-3:2020(E)
LOGICAL, COMMERCIAL AND USER PURPOSES,
DRAFT INTERNATIONAL STANDARDS MAY ON
OCCASION HAVE TO BE CONSIDERED IN THE
LIGHT OF THEIR POTENTIAL TO BECOME STAN-
DARDS TO WHICH REFERENCE MAY BE MADE IN
©
NATIONAL REGULATIONS. ISO 2020

---------------------- Page: 1 ----------------------
ISO/FDIS 15156-3:2020(E)

COPYRIGHT PROTECTED DOCUMENT
© ISO 2020
All rights reserved. Unless otherwise specified, or required in the context of its implementation, no part of this publication may
be reproduced or utilized otherwise in any form or by any means, electronic or mechanical, including photocopying, or posting
on the internet or an intranet, without prior written permission. Permission can be requested from either ISO at the address
below or ISO’s member body in the country of the requester.
ISO copyright office
CP 401 • Ch. de Blandonnet 8
CH-1214 Vernier, Geneva
Phone: +41 22 749 01 11
Email: copyright@iso.org
Website: www.iso.org
Published in Switzerland
ii © ISO 2020 – All rights reserved

---------------------- Page: 2 ----------------------
ISO/FDIS 15156-3:2020(E)

Contents Page
Foreword .iv
Introduction .vi
1 Scope . 1
2 Normative references . 2
3 Terms and definitions . 3
4 Symbols and abbreviated terms . 5
5 Factors affecting the cracking-resistance of CRAs and other alloys in H S-containing
2
environments . 6
6 Qualification and selection of CRAs and other alloys with respect to SSC, SCC, and
GHSC in H S-containing environments . 6
2
6.1 General . 6
6.2 Evaluation of materials properties . 7
6.2.1 Hardness of parent metals . 7
6.2.2 Cracking-resistance properties of welds. 7
6.2.3 Cracking-resistance properties associated with other fabrication methods . 8
6.3 PREN . 9
7 Purchasing information and marking . 9
7.1 Information that should be supplied for material purchasing . 9
7.2 Marking, labelling, and documentation .10
Annex A (normative) Environmental cracking-resistant CRAs and other alloys (including
Table A.1 — Guidance on the use of the materials selection tables) .11
Annex B (normative) Qualification of CRAs for H S-service by laboratory testing .57
2
Annex C (informative) Information that should be supplied for material purchasing .67
Annex D (informative) Nominated sets of test conditions .69
Bibliography .70
© ISO 2020 – All rights reserved iii

---------------------- Page: 3 ----------------------
ISO/FDIS 15156-3:2020(E)

Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards
bodies (ISO member bodies). The work of preparing International Standards is normally carried out
through ISO technical committees. Each member body interested in a subject for which a technical
committee has been established has the right to be represented on that committee. International
organizations, governmental and non-governmental, in liaison with ISO, also take part in the work.
ISO collaborates closely with the International Electrotechnical Commission (IEC) on all matters of
electrotechnical standardization.
The procedures used to develop this document and those intended for its further maintenance are
described in the ISO/IEC Directives, Part 1. In particular, the different approval criteria needed for the
different types of ISO documents should be noted. This document was drafted in accordance with the
editorial rules of the ISO/IEC Directives, Part 2 (see www .iso .org/ directives).
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. ISO shall not be held responsible for identifying any or all such patent rights. Details of
any patent rights identified during the development of the document will be in the Introduction and/or
on the ISO list of patent declarations received (see www .iso .org/ patents).
Any trade name used in this document is information given for the convenience of users and does not
constitute an endorsement.
For an explanation of the voluntary nature of standards, the meaning of ISO specific terms and
expressions related to conformity assessment, as well as information about ISO's adherence to the
World Trade Organization (WTO) principles in the Technical Barriers to Trade (TBT), see www .iso .org/
iso/ foreword .html.
This document was prepared by Technical Committee ISO/TC 67, Materials, equipment and offshore
structures for petroleum, petrochemical and natural gas industries, in collaboration with the European
Committee for Standardization (CEN) Technical Committee CEN/TC 12, Materials, equipment and
offshore structures for petroleum, petrochemical and natural gas industries, in accordance with the
Agreement on technical cooperation between ISO and CEN (Vienna Agreement).
This fourth edition cancels and replaces the third edition (ISO 15156-3:2015), which has been
technically revised. The main changes compared to the previous edition are as follows:
— Table A.27 UNS S17400 (17-4PH SS) has new limits. The use of the alloy at the annotated environmental
conditions is now limited to applications where sustained stress is no more than 50 % of SMYS;
— Table A.32 new limits and annotations for UNS N09946 separate from UNS N09945;
— Table A.41 inclusion of UNS R55400 (new a-b Ti alloy);
— Table A.3 UNS S20910 (Nitronic 50) note modifications;
— Tables A.22, A.23, A.26 through A.30, and A.33 temperature conversion corrections;
— Table A.23 new note for maximum design tensile stress for UNS J91540;
— Table A.32 newly added UNS N07718 (high strength Alloy 718, with two-step aging cycle, meeting
API 6A CRA composition and a maximum hardness of 45 HRC) and UNS N09955 requirements and
note letters designation changes on UNS N09925, N09935, N09945 and N09946;
— Table A.40 title modification and note clarification;
— Clause A.13 Cladding, overlays, and wear-resistant alloys modifications;
— Table A.18 and Table A.19 (Martensitic SS) remarks modifications;
— Table A.24 Duplex SS Hot Isostatically Pressed (HIP) inclusion and remarks modification;
iv © ISO 2020 – All rights reserved

---------------------- Page: 4 ----------------------
ISO/FDIS 15156-3:2020(E)

— the informative Annex D, "Materials chemical compositions and other information", has been
removed due to copyright reasons;
— additions to the bibliography.
A list of all parts in the ISO 15156 series can be found on the ISO website.
Any feedback or questions on this document should be directed to the user’s national standards body. A
complete listing of these bodies can be found at www .iso .org/ members .html.
© ISO 2020 – All rights reserved v

---------------------- Page: 5 ----------------------
ISO/FDIS 15156-3:2020(E)

Introduction
The consequences of sudden failures of metallic oil and gas field components associated with their
exposure to H S-containing production fluids led to the preparation of the first edition of NACE MR0175
2
which was published in 1975 by the National Association of Corrosion Engineers, now known as NACE
International.
The original and subsequent editions of NACE MR0175 established limits of H S partial pressure above
2
which precautions against sulfide stress-cracking (SSC) were always considered necessary. They
also provided guidance for the selection and specification of SSC-resistant materials when the H S
2
thresholds were exceeded. In more recent editions, NACE MR0175 has also provided application limits
for some corrosion-resistant alloys in terms of environmental composition and pH, temperature, and
H S partial pressures.
2
In separate developments, the European Federation of Corrosion issued EFC Publication 16 in 1995 and
EFC Publication 17 in 1996. These documents are generally complementary to those of NACE, though
they differed in scope and detail.
In 2003, the publication of the ISO 15156 series and NACE MR0175/ISO 15156 was completed for the
first time. These technically identical documents utilized the above sources to provide requirements
and recommendations for materials qualification and selection for application in environments
containing wet H S in oil and gas production systems. They are complemented by NACE TM0177 and
2
NACE TM0284 test methods.
The revision of this document, i.e. ISO 15156, involves a consolidation of all changes agreed and published
in the Technical Circular 1, ISO 15156-3:2015/Cir.1:2016, the Technical Circular 2, ISO 15156-3:2015/
Cir.2:2018(E) and the Technical Circular 3, ISO 15156-3:2015/Cir.3:2019, published by the ISO 15156
series Maintenance Agency secretariat at DIN.
The changes were developed by, and approved by the ballot of, representative groups from within
the oil and gas production industry. The great majority of these changes stem from issues raised by
document users. A description of the process by which these changes were approved can be found at
the ISO 15156 series maintenance website: www .iso .org/ iso15156maintenance.
When found necessary by oil and gas production industry experts, future interim changes to this
document will be processed in the same way and will lead to interim updates to this document in
the form of Technical Corrigenda or Technical Circulars. Document users should be aware that such
documents can exist and can impact the validity of the dated references in this document.
The ISO 15156 series Maintenance Agency at DIN was set up after approval by the ISO Technical
Management Board given in document 34/2007. This document describes the makeup of the agency,
which includes experts from NACE, EFC, and ISO/TC 67, and the process for approval of amendments.
It is available from the ISO 15156 series maintenance website and from the ISO/TC 67 Secretariat. The
website also provides access to related documents that provide more detail of the ISO 15156 series
maintenance activities.
vi © ISO 2020 – All rights reserved

---------------------- Page: 6 ----------------------
FINAL DRAFT INTERNATIONAL STANDARD ISO/FDIS 15156-3:2020(E)
Petroleum and natural gas industries — Materials
for use in H S-containing environments in oil and gas
2
production —
Part 3:
Cracking-resistant CRAs (corrosion-resistant alloys) and
other alloys
WARNING — CRAs (corrosion-resistant alloys) and other alloys selected using this document
are resistant to cracking in defined HS-containing environments in oil and gas production,
2
but not necessarily immune to cracking under all service conditions. It is the equipment user's
responsibility to select the CRAs and other alloys suitable for the intended service.
1 Scope
This document gives requirements and recommendations for the selection and qualification of CRAs
(corrosion-resistant alloys) and other alloys for service in equipment used in oil and natural gas
production and natural gas treatment plants in H S-containing environments whose failure can pose
2
a risk to the health and safety of the public and personnel or to the environment. It can be applied to
help avoid costly corrosion damage to the equipment itself. It supplements, but does not replace, the
materials requirements of the appropriate design codes, standards, or regulations.
This document addresses the resistance of these materials to damage that can be caused by sulfide
stress-cracking (SSC), stress-corrosion cracking (SCC), and galvanically induced hydrogen stress
cracking (GHSC).
This document is concerned only with cracking. Loss of material by general (mass loss) or localized
corrosion is not addressed.
Table 1 provides a non-exhaustive list of equipment to which this document is applicable, including
exclusions.
This document applies to the qualification and selection of materials for equipment designed and
constructed using load controlled design methods. For design utilizing strain-based design methods,
see ISO 15156-1:2020, Clause 5.
This document is not necessarily suitable for application to equipment used in refining or downstream
processes and equipment.
© ISO 2020 – All rights reserved 1

---------------------- Page: 7 ----------------------
ISO/FDIS 15156-3:2020(E)

Table 1 — List of equipment
This document is applicable to materials used for the Exclusions
following equipment
Drilling, well construction, and well-servicing Equipment exposed only to drilling fluids of con-
equipment trolled
a
composition
Drill bits
b
Blowout-preventer (BOP) shear blades
Drilling riser systems
Work strings
c
Wireline and wireline equipment
Surface and intermediate casing
d
Wells including subsurface equipment, gas lift Sucker rod pumps and sucker rods
equipment, wellheads, and christmas trees
Electric submersible pumps
Other artificial lift equipment
Slips
Flow-lines, gathering lines, field facilities, and field Crude oil storage and handling facilities operating
processing plants at
a total absolute pressure below 0,45 MPa (65 psi)
Water-handling equipment Water-handling facilities operating at a total
absolute
pressure below 0,45 MPa (65 psi)
Water injection and water disposal equipment
Natural gas treatment plants —
Transportation pipelines for liquids, gases, and Lines handling gas prepared for general commer-
multi-phase fluids cial
and domestic use
For all equipment above Components loaded only in compression
a
See ISO 15156-2:2020, A.2.3.2.3 for more information.
b
See ISO 15156-2:2020, A.2.3.2.1 for more information.
c
Wireline lubricators and lubricator connecting devices are not excluded.
d
For sucker rod pumps and sucker rods, reference can be made to NACE MR0176.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 6507-1, Metallic materials — Vickers hardness test — Part 1: Test method
ISO 6508-1, Metallic materials — Rockwell hardness test — Part 1: Test method
ISO 6892-1, Metallic materials — Tensile testing — Part 1: Method of test at room temperature
ISO 10423, Petroleum and natural gas industries — Drilling and production equipment — Wellhead and
christmas tree equipment
ISO 11960, Petroleum and natural gas industries — Steel pipes for use as casing or tubing for wells
2 © ISO 2020 – All rights reserved

---------------------- Page: 8 ----------------------
ISO/FDIS 15156-3:2020(E)

ISO 15156-1:2020, Petroleum and natural gas industries — Materials for use in H S-containing
2
environments in oil and gas production — Part 1: General principles for selection of cracking-resistant
materials
ISO 15156-2:2020, Petroleum and natural gas industries — Materials for use in H S-containing
2
environments in oil and gas production — Part 2: Cracking-resistant carbon and low alloy steels, and the
use of cast irons
1)
ASTM A747/A747M , Standard Specification for Steel Castings, Stainless, Precipitation Hardening
ASTM E29, Standard Practice for Using Significant Digits in Test Data to Determine Conformance with
Specifications
ASTM E562, Standard Test Method for Determining Volume Fraction by Systematic Manual Point Count
2)
EFC Publication 17 , Corrosion resistant alloys for oil and gas production: guidelines on general
requirements and test methods for H S service
2

NACE CORROSION/95 Paper 47, Test methodology for elemental sulfur-resistant advanced materials for oil
and gas field equipment
N AC E T M0177: 2016 , Laboratory testing of metals for resistance to sulfide stress cracking and stress
corrosion cracking in H S environments
2
3)
SAE AMS-2430 , Shot Peening
SAE — ASTM, Metals and alloys in the Unified Numbering System
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 15156-1, ISO 15156-2 and the
following apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at http:// www .electropedia .org/
3.1
ageing
change in metallurgical properties that generally occurs slowly at room temperature (natural ageing)
and more rapidly at higher temperature (artificial ageing)
3.2
anneal
heat to and hold at a temperature appropriate for the specific material and then cool at a suitable rate
for such purposes as reducing hardness, improving machineability, or obtaining desired properties
3.3
austenite
face-centred cubic crystalline phase of iron-based alloys
1) www .astm .org
2) www .efcweb .org
3) www .sae .org
© ISO 2020 – All rights reserved 3

---------------------- Page: 9 ----------------------
ISO/FDIS 15156-3:2020(E)

3.4
duplex stainless steel
austenitic/ferritic stainless steel
stainless steel (3.13) whose microstructure at room temperature consists primarily of a mixture of
austenite (3.3) and ferrite (3.5)
3.5
ferrite
body-centred cubic crystalline phase of iron-based alloys
3.6
ferritic stainless steel
stainless steel (3.13) whose microstructure at room temperature consists predominantly of ferrite (3.5)
3.7
galvanically induced hydrogen stress cracking
GHSC
cracking that results due to the presence of hydrogen in a metal induced in the cathode of a galvanic
couple and tensile stress (residual and/or applied)
3.8
martensite
hard, supersaturated solid solution of carbon in iron characterized by an acicular (needle-like)
microstructure
3.9
martensitic steel
steel in which a microstructure of martensite (3.8) can be attained by quenching at a cooling rate fast
enough to avoid the formation of other microstructures
3.10
pitting-resistance equivalent number
PREN
F
PREN
number developed to reflect and predict the pitting resistance of a CRA based upon the proportions of
the elements Cr, Mo, W, and N in the chemical composition of the alloy
Note 1 to entry: See 6.3 for further information.
3.11
production environment
natural occurring produced fluids without contamination from chemicals that will temporarily or
continuously reduce the in situ pH
Note 1 to entry: Flow back of chemicals for stimulation and scale removal may temporarily reduce the pH
significantly and some continuously injected chemicals, such as scale inhibitors, can continuously reduce pH.
3.12
solid solution
single crystalline phase containing two or more elements
3.13
stainless steel
steel containing 10,5 % mass fraction or more chromium, possibly with other elements added to secure
special properties
4 © ISO 2020 – All rights reserved

---------------------- Page: 10 ----------------------
ISO/FDIS 15156-3:2020(E)

4 Symbols and abbreviated terms
AYS actual yield strength
bal balance of composition up to 100 %
BOP blowout preventer
CR c-ring
CRA corrosion-resistant alloy
DCB double cantilever beam (test)
FPB four-point bend (test)
GHSC galvanically induced hydrogen stress cracking
HAZ heat-affected zone
HBW Brinell hardness
HIC hydrogen-induced cracking
HIP hot isostatically pressed
HRB Rockwell hardness (scale B)
HRC Rockwell hardness (scale C)
HSC hydrogen stress cracking
HV Vickers hardness
NDS no data submitted
pCO partial pressure of CO2
2
pH S partial pressure of H2S
2
PREN pitting-resistance equivalent number
PWHT post-weld heat treatment
RSRT rippled strain rate test
0
S elemental sulfur
SCC stress-corrosion cracking
SMYS specified minimum yield strength
SOHIC stress-oriented hydrogen-induced cracking
SSC sulfide stress-cracking
SSRT slow strain rate test
© ISO 2020 – All rights reserved 5

---------------------- Page: 11 ----------------------
ISO/FDIS 15156-3:2020(E)

SZC soft-zone cracking
UNS unified (alloy) numbering system
UT uniaxial tensile (test)
5 Factors affecting the cracking-resistance of CRAs and other alloys in H S-
2
containing environments
The cracking behaviour of CRAs and other alloys in H S-containing environments can be affected by
2
complex interactions of parameters including the following:
— chemical composition, strength, heat treatment, microstructure, method of manufacture, and
finished condition of the material;
— H S partial pressure or equivalent dissolved concentration in the water phase;
2
— acidity (in situ pH) of the water phase;
— chloride or other halide ion concentration;
— presence of oxygen, sulfur, or other oxidants;
— exposure temperature;
— pitting resistance of the material in the service environment;
— galvanic effects;
— total tensile stress (applied plus residual);
— exposure time.
These factors shall be considered when using this document for the selection of materials suitable for
environments containing H S in oil and gas production systems.
2
6 Qualification and selection of CRAs and other alloys with respect to SSC, SCC,
and GHSC in H S-containing environments
2
6.1 General
CRAs and other alloys shall be selected for their resistance to SSC, SCC, and/or GHSC as required by the
intended service.
Conformance of a CRA or other alloy with this document implies cracking-resistance within defined
environmental service limits. These limits are dependent on the material type or the individual alloy.
To enable qualification and/or selection of CRAs and other alloys, the equipment purchaser can be
required to provide information on the proposed conditions of exposure to the equipment supplier.
In defining the severity of H S-containing environments, exposures that can occur during system
2
upsets or shutdowns, etc. shall also be considered. Such exposures can include unbuffered, low pH
condensed water. The limits given in the tables in Annex A are for production environments and do not
cover conditions occurring during injection or flowback of chemicals that can reduce the in situ pH.
CRAs and other alloys shall be selected using Annex A or following qualification by successful
laboratory testing in accordance with Annex B. Qualification based on satisfactory field experience is
also acceptable. Such qualification shall conform with ISO 15156-1.
6 © ISO 2020 – All rights reserved

---------------------- Page: 12 ----------------------
ISO/FDIS 15156-3:2020(E)

In Annex A, materials are identified by materials groups. Within each group, alloys are identified by
materials type (within compositional limits) or as individual alloys. Acceptable metallurgical conditions
and environmental limits are given for which alloys are expected to resist cracking. Environmental
limits are given for H S partial pressure, temperature, chloride concentration, and elemental sulfur.
2
A CRA or other alloy can be qualified by testing for use under operating conditions that are more severe
than the environmental limits given in Annex A. Similarly, a CRA or other alloy can be qualified for use
in different metallurgical conditions (higher strength, alternative heat treatment, etc.) to those given in
Annex A.
The documentation of qualifications performed in accordance with Annex B shall meet the requirements
in ISO 15156-1:2020, Clause 9.
The equipment user shall verify qualifications (see B.2.2) and retain documentation supporting the
materials selections made.
6.2 Evaluation of materials properties
6.2.1 Hardness of parent metals
If hardness measurements on parent metal are specified, sufficient hardness tests shall be made
to establish the actual hardness of the CRA or other alloy being examined. Individual HRC readings
exceeding the value permitted by this document may be considered acceptable if the average of several
readings taken within close proximity does not exceed the value permitted by this document and no
individual reading is greater than 2 HRC above the specified value. Equivalent requirements shall
apply to other methods of hardness measurement when specified in this document or referenced in a
manufacturing specification.
The conversion of hardness readings to or from other scales is material-dependent. The user may
establish the required conversion tables.
NOTE The number and location of hardness tests on parent metal are not specified in ISO 15156 (all parts).
6.2.2 Cracking-resistance properties of welds
6.2.2.1 General
The metallurgical changes that occur when welding CRAs and other alloys can affect their susceptibility
to SSC, SCC, and/or GHSC. Welded joints can have a greater susceptibility to cracking than the parent
material(s) joined.
The equipment user may allow the cracking susceptibility of weldments to govern the limits of safe
service conditions for a fabricated system.
Processes and consumables used in welding should be selected in accordance with good practice and to
achieve the required corrosion and cracking resistances.
Welding shall be carried out in conformance with appropriate codes and standards as agreed between
the supplier and the purchaser. Welding procedure specifications (WPSs) and procedure qualification
records (PQRs) shall be available for inspection by the equipment user.
Welding PQRs shall include documented evidence demonstrating satisfactory cracking resistance
under conditions at least as severe as those of the proposed application. Such evidence shall be based
upon one or more of the following:
— conformance with the requirements and recommendations for the specific materials group of
Annex A (see also 6.2.2.2 and 6.2.2.3);
— weld cracking-resistance qualification testing in accordance with Annex B;
© ISO 2020 – All rights reserved 7

---------------------- Page: 13 ----------------------
ISO/FDIS 15156-3:2020(E)

— documented field experience modelled upon that specified for parent materials in ISO 15156-1.
The requirements and recommendations given in Annex A might not be appropriate for all combinations
of parent and weld metals used in the fabrication of equipment and components. The equipment user
may require evidence of successful cracking-resistance testing as part of the welding procedure
qualification to ensure the
...

Questions, Comments and Discussion

Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
