ISO/DTS 25588

• Abstract:

  Specification of the set-up of a testing system and the test suite structure and test purposes, i.e. tests to be used to assess conformity to specification of the processes that implement an image-based tolling system.

• Status: Not Published
• ICS: 35.240.60 - IT applications in transport
• Technical Committee: ISO/TC 204 - Intelligent transport systems
• Drafting Committee: ISO/TC 204/WG 5 - Fee and toll collection
• Current Stage: 5020 - FDIS ballot initiated: 2 months. Proof sent to secretariat
• Start Date: 15-Jul-2026
• Completion Date: 15-Jul-2026

• Consolidates: FprCEN ISO/TS 25588 - Electronic fee collection - Image-based systems - Test suite structure and test purposes (ISO/DTS 25588:2026)
• Effective Date: 12-Feb-2026

Overview

ISO/DTS 25588:2026, developed by ISO/TC 204, specifies the requirements for the structure of test suites and the specification of test purposes to determine conformity in image-based electronic fee collection (EFC) systems. As image-based tolling systems become increasingly central to modern intelligent transport systems (ITS), effective and standardized testing is critical for ensuring accurate, reliable, and interoperable operation. This standard outlines laboratory and on-site test setups, interfaces, and events crucial for assessing core functions such as passage detection, vehicle identification, and vehicle classification.

Key Topics

• Test System Setup: ISO/DTS 25588 details both laboratory and operational (on-site) test configurations, including requirements for equipment such as cameras, licence plates, control workstations, and measurement devices.
• Test Suite Structure: The standard specifies a modular structure for test suites, including test scenarios that evaluate individual EFC components independently. This isolation ensures conformity to specification for each process before assessing overall system performance.
• Core Processes Tested:
  • Passage Detection: Validation of event generation when vehicles pass tolling points using technologies such as inductive loops, presence radars, and cameras.
  • Vehicle Identification: Evaluation of capabilities to correctly recognize licence plate numbers and related vehicle information, using optical character recognition (OCR) and automatic number plate recognition (ANPR).
  • Vehicle Classification: Assessment of classification algorithms that determine vehicle type, size, or axle count, often leveraging artificial intelligence (AI) or support vector machines (SVM).
• Data Format & Interfaces: Standardization of event generation, timestamping, interface requirements, and data formats ensures interoperability and facilitates result validation.

Applications

Practical Value for Stakeholders

Adoption of ISO/DTS 25588 supports a broad range of applications within the intelligent transportation ecosystem:

• Toll Service Providers: Ensure compliance with international specifications for image-based toll systems, improving reliability and harmonizing operations across regions.
• System Integrators: Utilize clearly defined test purposes and interfaces to select compatible components, facilitate integration, and expedite deployment.
• Regulators and Authorities: Rely on standardized test suites to verify system conformity, conduct audits, and maintain public trust in electronic tolling operations.
• Technology Developers: Reference test scenarios and data formats to design and validate new equipment (e.g., advanced ANPR cameras, AI classifiers).

Broader Use Cases

While the focus is on EFC/tolling, the framework can be adapted to related image-based intelligent transport system applications such as:

• Automated parking and access systems
• Vehicle compliance checks and roadside enforcement
• Traffic violation detection or monitoring

Related Standards

For comprehensive implementation and conformity in electronic fee collection and intelligent transport systems, the following ISO standards are relevant:

• ISO 17573-2: Electronic fee collection - System architecture for vehicle-related tolling - Vocabulary; referenced for terms and definitions.
• ISO/TR 25221: Classifies relevant characteristics of image-based systems and forms the basis for component-level testing.
• ISO/TS 37444 (future): Will define key performance indicators (KPIs) and numerical thresholds for EFC systems, integrating with the conformity assessment methods outlined here.

Conclusion

ISO/DTS 25588:2026 is essential for organizations seeking to validate compliance and performance in image-based EFC systems. By providing a standardized approach to test suite structure and test purposes, it promotes interoperability, transparency, and continual improvement across international electronic tolling operations and broader ITS applications. Implementers, regulators, and technology vendors all benefit from its clarity and actionable guidance.
