INTERNATIONAL STANDARD ISO 10406-3:2019(E)
Fibre-reinforced polymer (FRP) reinforcement of
concrete — Test methods —
Part 3:
CFRP strips
1 Scope
This document specifies test methods applicable to unidirectional carbon fibre-reinforced polymer
(CFRP) strips as external-bonded reinforcements on the concrete substrate.
This document is applicable for the CFRP strips that:
— consist of carbon fibre and thermoset resin;
— are manufactured by pultrusion method;
— have a higher carbon fibre fraction such as over 60 %; and
— have a thickness within 3 mm.
Also, the test pieces for determining tensile properties are cut down from CFRP strips along the CFRP
strips axis, and have bonded anchorage block at the both ends.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 7500-1, Metallic materials — Calibration and verification of static uniaxial testing machines — Part 1:
Tension/compression testing machines — Calibration and verification of the force-measuring system
ISO 10406-2:2015, Fibre-reinforced polymer (FRP) reinforcement of concrete — Test methods — Part 2:
FRP sheets
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https: //www .iso .org/obp
— IEC Electropedia: available at http: //www .electropedia .org/
3.1
accelerated artificial exposure testing machine
machine that creates reproducible standard test conditions to accelerate weathering artificially
3.2
anchorage block
tab (3.6) corresponding to the test block to prevent bond failure of the CFRP strips
© ISO 2019 – All rights reserved 1

---------------------- Page: 5 ----------------------
ISO 10406-3:2019(E)

3.3
anchorage portion
end parts of a test piece fitted with anchoring devices to transmit loads from the testing machine to the
test portion
3.4
Young’s modulus
E
f
elastic modulus in the direction of the fibres
3.5
strip
flat board which has thin thickness compared to width, a flatness-formed rectangular section and
stretches in the longitudinal direction
3.6
tab
plate made of fibre-reinforced polymer, aluminium, or any other suitable material bonded to the test
piece to transmit l
...
