ISO 4706:2023

Gas cylinders — Refillable welded steel cylinders — Test pressure 60 bar and below

This document specifies the minimum requirements concerning material selection, design, construction and workmanship, procedure, and test at manufacture of refillable welded-steel gas cylinders of water capacities from 0,5 l up to and including 150 l and drums of water capacities of 150 l to 500 l of a test pressure not greater than 60 bar[1], exposed to extreme worldwide temperatures (−50 °C to +65 °C) used for compressed, liquefied or dissolved gases. NOTE Unless specified in the text, for the purpose of this document, the word “cylinder” includes “pressure drums”. This document is primarily intended to be used for industrial gases other than liquefied petroleum gas (LPG), and is also applicable to LPG. [1] 1 bar = 0,1 MPa = 105 Pa; 1 MPa = 1 N/mm2.

Bouteilles à gaz — Bouteilles en acier soudées rechargeables — Pression d'essai de 60 bar et moins

General Information

• Status: Published
• Publication Date: 19-Sep-2023
• ICS: 23.020.35 - Gas cylinders
• Technical Committee: ISO/TC 58/SC 3 - Cylinder design
• Drafting Committee: ISO/TC 58/SC 3/WG 21 - Refillable welded steel gas cylinders
• Current Stage: 6060 - International Standard published
• Start Date: 20-Sep-2023
• Due Date: 07-Oct-2023
• Completion Date: 20-Sep-2023

Relations

• Revises: ISO 4706:2008 - Gas cylinders — Refillable welded steel cylinders — Test pressure 60 bar and below
• Effective Date: 23-Apr-2020

Standards Content (Sample)

ISO/FDISPRF 4706:2023
Date: February 28, 2023
ISO/TC 58/SC 3/WG 21
Secretariat: BSI
Date: 2023-07-21
Gas cylinders — Refillable welded steel cylinders — Test pressure
60 bar and below
Bouteilles à gaz — Bouteilles en acier soudées rechargeables — Pression d'essai de 60 bar et moins
FDIS stage
