Overview

ISO 4437-1:2026 is the foundational part of the ISO 4437 series, specifying the general aspects and material requirements for polyethylene (PE) piping systems designed for the supply of gaseous fuels. Published by the International Organization for Standardization (ISO), this standard provides the framework for safe, reliable, and efficient design, installation, and operation of PE piping systems in gas supply networks.

The document outlines material properties, general system requirements, and relevant test parameters, ensuring that the pipes, fittings, and valves, as well as their joints, perform reliably under defined conditions. It is applicable to systems designed for gaseous fuels including natural gas, methane, propane, hydrogen, biogas, and mixtures thereof, operating at pressures up to 10 bar and within a temperature range of −20 °C to 40 °C.

Key Topics

• Material Specifications: Defines requirements for PE compounds used in manufacturing pipes, fittings, and valves. This includes details on fusion compatibility, additives, pigmentation, and mechanical properties.
• Operating Conditions: Addresses maximum operating pressure (MOP) up to 10 bar at a reference temperature of 20 °C, with consideration for derating factors in the 20 °C to 40 °C range, as specified in ISO 4437-5.
• Joints and Compatibility: Covers fusion technologies such as butt fusion and electrofusion, ensuring that joints between PE components, or with other materials, maintain system integrity under gas pressure.
• Test Methods: Specifies test parameters to verify material performance, including resistance to pressure, environmental stress cracking, rapid crack propagation, and long-term strength.
• Component Classification: Provides a basis for assigning minimum required strength (MRS) ratings for PE compounds and design coefficients to ensure long-term durability.

Applications

ISO 4437-1 is essential for organizations involved in the design, manufacture, and installation of PE piping systems for gas distribution. Key sectors and use cases include:

• Natural Gas Distribution: Establishes baseline safety and performance criteria for municipal and regional gas supply networks.
• Hydrogen and Gas Mixtures: Supports the transition to renewable gases and hydrogen integration, with information on PE pipe suitability for 100% hydrogen and various gas blends.
• Construction and Utilities: Helps contractors, utilities, and engineers select appropriate materials and components for safe underground gas pipeline installation.
• Product Certification and Compliance: Used by manufacturers and certification bodies to demonstrate conformity with international safety, reliability, and performance standards.

By adhering to ISO 4437-1, stakeholders ensure system compatibility across the supply chain and compliance with national and international regulations.

Related Standards

ISO 4437-1 is part of a broader family of standards governing plastics piping systems for gaseous fuels:

• ISO 4437-2: Specifies requirements for PE pipes.
• ISO 4437-3: Details requirements for PE fittings.
• ISO 4437-4: Covers valve requirements.
• ISO 4437-5: Outlines fitness for purpose testing and derating for temperature effects.
• ISO/TS 4437-7: Provides guidance for assessment of conformity.
• ISO/TS 10839: Recommends practices for design, handling, and installation of PE piping systems.

Supporting standards covering testing and terminology, such as ISO 1133-1 (melt mass-flow rate), ISO 1167 (pressure resistance), and ISO 13953 (tensile strength of PE joints), are also referenced to ensure full compliance and safety in gas pipeline projects.

Conclusion

ISO 4437-1:2026 plays a critical role in the safe supply of gaseous fuels through PE pipes and fittings. Its adoption ensures system interoperability, public safety, and support for innovative energy distribution methods including hydrogen integration. For engineers, designers, and manufacturers, ISO 4437-1 is an indispensable reference for delivering reliable gas piping infrastructure in line with international best practices.

FINAL DRAFT
International
Standard
ISO/FDIS 4437-1
ISO/TC 138/SC 4
Plastics piping systems for
Secretariat: NEN
the supply of gaseous fuels —
Voting begins on:
Polyethylene (PE) —
2026-07-14
Part 1:
Voting terminates on:
2026-09-08
General
Systèmes de canalisations en plastique pour la distribution de
combustibles gazeux — Polyéthylène (PE) —
Partie 1: Généralités
RECIPIENTS OF THIS DRAFT ARE INVITED TO SUBMIT,
WITH THEIR COMMENTS, NOTIFICATION OF ANY
RELEVANT PATENT RIGHTS OF WHICH THEY ARE AWARE
AND TO PROVIDE SUPPOR TING DOCUMENTATION.
IN ADDITION TO THEIR EVALUATION AS
BEING ACCEPTABLE FOR INDUSTRIAL, TECHNO-
LOGICAL, COMMERCIAL AND USER PURPOSES, DRAFT
INTERNATIONAL STANDARDS MAY ON OCCASION HAVE
TO BE CONSIDERED IN THE LIGHT OF THEIR POTENTIAL
TO BECOME STAN DARDS TO WHICH REFERENCE MAY BE
MADE IN NATIONAL REGULATIONS.
Reference number
ISO/FDIS 4437-1:2026(en) © ISO 2026

FINAL DRAFT
ISO/FDIS 4437-1:2026(en)
International
Standard
ISO/FDIS 4437-1
ISO/TC 138/SC 4
Plastics piping systems for
Secretariat: NEN
the supply of gaseous fuels —
Voting begins on:
Polyethylene (PE) —
Part 1:
Voting terminates on:
General
Systèmes de canalisations en plastique pour la distribution de
combustibles gazeux — Polyéthylène (PE) —
Partie 1: Généralités
RECIPIENTS OF THIS DRAFT ARE INVITED TO SUBMIT,
WITH THEIR COMMENTS, NOTIFICATION OF ANY
RELEVANT PATENT RIGHTS OF WHICH THEY ARE AWARE
AND TO PROVIDE SUPPOR TING DOCUMENTATION.
© ISO 2026
IN ADDITION TO THEIR EVALUATION AS
All rights reserved. Unless otherwise specified, or required in the context of its implementation, no part of this publication may
BEING ACCEPTABLE FOR INDUSTRIAL, TECHNO-
LOGICAL, COMMERCIAL AND USER PURPOSES, DRAFT
be reproduced or utilized otherwise in any form or by any means, electronic or mechanical, including photocopying, or posting on
INTERNATIONAL STANDARDS MAY ON OCCASION HAVE
the internet or an intranet, without prior written permission. Permission can be requested from either ISO at the address below
TO BE CONSIDERED IN THE LIGHT OF THEIR POTENTIAL
or ISO’s member body in the country of the requester.
TO BECOME STAN DARDS TO WHICH REFERENCE MAY BE
MADE IN NATIONAL REGULATIONS.
ISO copyright office
CP 401 • Ch. de Blandonnet 8
CH-1214 Vernier, Geneva
Phone: [phone]
Email: [e-mail]
Website: www.iso.org
Published in Switzerland Reference number
ISO/FDIS 4437-1:2026(en) © ISO 2026
