Digital Enhanced Cordless Telecommunications (DECT); Common Interface (CI); Part 6: Identities and addressing
Digital Enhanced Cordless Telecommunications (DECT); Common Interface (CI); Part 6: Identities and addressing
The present document is one of the parts of the specification of the Digital Enhanced Cordless Telecommunications
(DECT) Common Interface (CI).
This part specifies the identities and addressing structure of the Digital Enhanced Cordless Telecommunications
(DECT) Common Interface (CI).
There are four categories of identities to be used for identification and addressing in a general DECT environment.
These four categories are:
• Fixed Part (FP) identities;
• Portable Part (PP) identities;
• connection-related identities;
• equipment-related identities.
Fixed part identities and portable part identities are used for:
• access information from fixed parts to portable parts;
• access requests from portable parts;
• identification of portable parts;
• identification of fixed parts and radio fixed parts;
• paging;
• billing.
These identities support:
• different environments, such as residential, public or private;
• supply to manufacturers, installers, and operators of globally unique identity elements with a minimum of
central administration;
• multiple access rights for the same portable;
• large freedom for manufacturers, installers, and operators to structure the fixed part identities, e.g. to facilitate
provision of access rights to groups of DECT systems;
• roaming agreements between DECT networks run by the same or different owners/operators;
• indication of handover domains;
• indication of location areas, i.e. paging area;
• indication of subscription areas of a public service.
The present document also provides for length indicators and other messages that can override the default location
and/or paging area and domain indications given by the structure of the identities.
Connection related identities are used to identify the protocol instances associated with a call and are used for
peer-to-peer communication.
Equipment related identities are used to identify a stolen PP and to derive a default identity coding for PP emergency
call set-up.
Coding of identity information elements for higher layer messages is found in ETSI EN 300 175-5 [5], clause 7.7.User authentication and ciphering need additional key information and is outside the scope of the present document, but
is covered in other parts of ETSI EN 300 175 [1] to [8], e.g. ETSI EN 300 175-7 [7].
The present document includes New Generation DECT, a further development of the DECT standard introducing
wideband speech, improved data services, new slot types and other technical enhancements.
Digitalne izboljšane brezvrvične telekomunikacije (DECT) - Skupni vmesnik (CI) - 6. del: Identitete in naslavljanje
Ta dokument je eden od delov specifikacije skupnega vmesnika (CI) za digitalne izboljšane brezvrvične telekomunikacije (DECT).
Ta del določa identitete in strukturo naslavljanja za skupni vmesnik za digitalne izboljšane brezvrvične telekomunikacije.
Za identifikacijo in naslavljanje v splošnem okolju digitalnih izboljšanih brezvrvičnih telekomunikacij se uporabljajo štiri kategorije identitet:
Te štiri kategorije so:
• identitete fiksnih delov (FP);
• identitete prenosnih delov (PP);
• identitete, povezane s povezavo;
• identitete, povezane z opremo.
Identitete fiksnih in prenosnih delov se uporabljajo za:
• dostop do informacij iz fiksnih delov v prenosne dele;
• zahteve za dostop iz prenosnih delov;
• identifikacijo prenosnih delov;
• identifikacijo fiksnih delov in radijskih fiksnih delov;
• storitev pozivanja;
• zaračunavanje.
Te identitete podpirajo:
• različna okolja, npr. stanovanjska, javna ali zasebna;
• dobavo globalnih enoličnih identifikacijskih elementov proizvajalcem, montažerjem in upravljavcem na osnovi najmanjšega možnega obsega centralnega skrbništva;
• več pravic za dostop za isto prenosno napravo;
• svobodo proizvajalcev, montažerjev in upravljavcev na področju strukture identitet fiksnih delov, npr. glede omogočanja pravic za dostop skupinam v sistemih digitalnih izboljšanih brezvrvičnih telekomunikacij;
• pogodbe o gostovanju med omrežji digitalnih izboljšanih brezvrvičnih telekomunikacij, ki jih upravljajo isti ali različni lastniki/upravljavci;
• navedbo o domenah za prenose;
• navedbo o področjih lokacij, npr. področju pozivanja;
• navedbo o področjih naročnin javne storitve.
Ta dokument zagotavlja tudi indikatorje dolžine in druga sporočila, ki lahko preglasijo privzeto lokacijo in/ali področje pozivanja, ter navedbe domene, ki jih določa struktura identitet.
Identitete, povezane s povezavo, se uporabljajo za identificiranje primerkov protokola, povezanih s klicem, in komunikacijo v omrežju enakovrednih.
Identitete, povezane z opremo, se uporabljajo za identificiranje ukradenih PP-jev in izpeljavo privzetega šifriranja identitete za nastavitev klicev v sili za PP-je.
Kodiranje informacijskih elementov identitete za sporočila višje plasti je določeno v standardu ETSI EN 300 175-5 [5], točka 7.7. Preverjanje pristnosti uporabnika in kodiranje zahtevata dodatne ključne informacije in sta zunaj obsega tega dokumenta, vendar sta zajeta v drugih delih standarda ETSI EN 300 175 [1] do [8], npr. v ETSI EN 300 175-7 [7]. Ta dokument vključuje novo generacijo digitalnih izboljšanih brezvrvičnih telekomunikacij, nadaljnji razvoj standarda za digitalne izboljšane brezvrvične telekomunikacije, ki uvaja širokopasovni govor, izpopolnjene podatkovne storitve, nove tipe rež in druge tehnične izpopolnitve.
