ETSI ETSI EN 301 839-2 V1.3.1 (2009-10) 6 1 Scope The present document applies to the following radio equipment types: • Ultra Low Power Active Medical Implants (ULP-AMI); • and Peripherals (ULP-AMI-P). These radio equipment types are capable of operating in all or any part of the frequency bands in table 1. Table 1: Ultra Low Power Active Medical Implants (ULP-AMI) and
Peripherals (ULP-AMI-P) service frequency bands
Ultra Low Power Active Medical Implants (ULP-AMI) and Peripherals (ULP-AMI-P) service frequency bands Transmit Ultra Low Power Active Medical Implants
(ULP-AMI) and Peripherals (ULP-AMI-P) 402 MHz to 405 MHz Receive Ultra Low Power Active Medical Implants
(ULP-AMI) and Peripherals (ULP-AMI-P) 402 MHz to 405 MHz
The present document is intended to cover the provisions of Directive 1999/5/EC [i.1] (R&TTE Directive), Article 3.2, which states that "…. radio equipment shall be so constructed that it effectively uses the spectrum allocated to terrestrial/space radio communications and orbital resources so as to avoid harmful interference". An AIMD is regulated under the AIMD Directive 90/385/EEC [i.2]: radio parts contained therein (referred to herein as ULP-AMI and ULP-AMI-P for peripheral devices) are regulated under the Directive 1999/5/EC [i.1]. In addition to the present document, other ENs that specify technical requirements in respect of essential requirements under other parts of Article 3 of the R&TTE Directive [i.1] may apply to equipment within the scope of the present document. NOTE: A list of such ENs is included on the web site http://www.newapproach.org. 2 References References are either specific (identified by date of publication and/or edition number or version number) or non-specific. • For a specific reference, subsequent revisions do not apply. • Non-specific reference may be made only to a complete document or a part thereof and only in the following cases: - if it is accepted that it will be possible to use all future changes of the referenced document for the purposes of the referring document; - for informative references. Referenced documents which are not found to be publicly
...
