SIST EN 61300-2-2:2009

Fibre optic interconnecting devices and passive components - Basic test and measurement procedures - Part 2-2: Tests - Mating durability (IEC 61300-2-2:2009)

IEC 61300-2-2:2009 specifies a test to evaluate the effects of a number of successive cycles of engagement and separation of fibre optic connectors or other interconnecting devices on optical performance and mechanical degradation of the component under normal conditions of use. Specific technical changes from the previous edition include a mating durability test for a plug-socket configuration, a new measurement condition and a new severity level.

Lichtwellenleiter - Verbindungselemente und passive Bauteile - Grundlegende Prüf- und Messverfahren - Teil 2-2: Prüfungen - Mechanische Lebensdauer (IEC 61300-2-2:2009)

Dispositifs d'interconnexion et composants passifs à fibres optiques - Méthodes fondamentales d'essais et de mesures - Partie 2-2: Essais - Durabilité de l'accouplement (CEI 61300-2-2:2009)

La CEI 61300-2-2:2009 spécifie un essai en vue d'évaluer les effets d'un certain nombre de cycles successifs d'accouplements et de désaccouplemements des connecteurs ou d'autres dispositifs d'interconnexion pour fibres optiques sur une performance optique, et la dégradation mécanique du composant dans des conditions d'utilisation normales. Les modifications techniques spécifiques par rapport à l'édition précédente consistent en l'ajout d'un essai de durabilité d'accouplement pour une configuration fiche-socle, de nouvelles conditions de mesures et un nouveau niveau de sévérité.",PE

Povezovalne naprave in pasivne komponente optičnih vlaken - Postopki osnovnega preskušanja in merjenja - 2-2. del: Preskusi - Mehanično trajanje (IEC 61300-2-2:2009)

General Information

• Status: Published
• Publication Date: 22-Mar-2009
• ICS: 33.180.20 - Fibre optic interconnecting devices
• Technical Committee: iTEL - Communication cables
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 11-Mar-2009
• Due Date: 16-May-2009
• Completion Date: 23-Mar-2009
• Ref Project: EN 61300-2-2:2009 - Fibre optic interconnecting devices and passive components - Basic test and measurement procedures - Part 2-2: Tests - Mating durability
