IMT cellular networks - Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive - Part 4: CDMA Multi-Carrier (cdma2000) User Equipment (UE)

The present document applies to the following radio equipment type:
- User Equipment (also denoted as Mobile stations or Access Terminals) for IMT-2000 CDMA multi-carrier (cdma2000). These radio equipment types are capable of operating in all or any part of the frequency bands given in table 1-1.
The present document covers requirements for IMT-2000 CDMA multi-carrier (cdma2000) User Equipments and Evolved CDMA Multi-Carrier (UMB) User Equipment. User Equipment for IMT-2000 CDMA multi-carrier (cdma2000) may support:
1) operation in cdma2000 Spread Spectrum Systems as defined in 3GPP2 C.S0002-E [2], referred to herein as operation in type 1 cdma2000 systems; or
2) operation in cdma2000 High Rate Packet Data Systems as defined in 3GPP2 C.S0024-200-C [7] subtypes 0, 1, 2 and 3, referred to herein as operation in type 2 cdma2000 systems; or
3) operation in both, type 1 and type 2 cdma2000 systems.
The present document is intended to cover the provisions of Directive 1999/5/EC [i.2] (R&TTE Directive) article 3.2, which states that "… radio equipment shall be so constructed that it effectively uses the spectrum allocated to terrestrial/space radio communications and orbital resources so as to avoid harmful interference". In addition to the present document, other ENs that specify technical requirements in respect of essential requirements under other parts of article 3 of the R&TTE Directive [i.2] may apply to equipment within the scope of the present document.

Celična omrežja IMT - Harmonizirani EN, ki zajema bistvene zahteve člena 3.2 direktive R&TTE - 4. del: Uporabniška oprema CDMA z več nosilnimi frekvencami (cdma2000)

Ta dokument se uporablja za radijsko opremo naslednje vrste:
– uporabniška oprema (imenovana tudi mobilne postaje ali dostopni terminali) IMT-2000 CDMA z več nosilnimi frekvencami (cdma2000). Radijska oprema teh vrst lahko deluje v vseh delih frekvenčnih pasov iz preglednice 1-1.
Preglednica 1-1: Pasovi, v katerih delujejo mobilne postaje CDMA z več nosilnimi frekvencami
V tem dokumentu so določene zahteve za uporabniško opremo IMT-2000 CDMA z več nosilnimi frekvencami (cdma2000) in uporabniško opremo sproščenega CDMA (UMB) z več nosilnimi frekvencami. Uporabniška oprema IMT-2000 CDMA z več nosilnimi frekvencami (cdma2000) lahko podpira:
1) delovanje v sistemih razširjenega spektra cdma2000, kot je opisano v 3GPP2 C.S0002-E [2]; v tem besedilu: delovanje v tipu 1 sistema cdma2000; ali
2) delovanje v paketnih podatkovnih sistemih z visoko stopnjo prenosa, kot je opisano v 3GPP2 C.S0024-200-C [7] v podvrstah 0, 1, 2 in 3; v tem besedilu: delovanje v tipu 2 sistema cdma2000; ali
3) delovanje v tipih 1 in 2 sistemov cdma2000.
Ta dokument zajema določbe člena 3.2 Direktive 1999/5/ES [i.2] (direktive R&TTE), ki navaja, da »[...] mora biti radijska oprema skonstruirana tako, da učinkovito uporablja spekter, razporejen za prizemne/vesoljske radijske komunikacije in orbitalne vire, tako da ne pride do škodljivega motenja.« Poleg tega dokumenta se za opremo na področju uporabe tega dokumenta uporabljajo tudi drugi standardi EN, ki določajo tehnične zahteve v zvezi z bistvenimi zahtevami iz drugih delov člena 3 direktive R&TTE [i.2].
