SIST EN IEC 60404-18:2025
(Main)Magnetic materials - Part 18: Permanent magnet (magnetically hard) materials - Methods of measurement of the magnetic properties in an open magnetic circuit using a superconducting magnet (IEC 60404-18:2025)
Magnetic materials - Part 18: Permanent magnet (magnetically hard) materials - Methods of measurement of the magnetic properties in an open magnetic circuit using a superconducting magnet (IEC 60404-18:2025)
IEC 60404-18:2025 defines the general principle and technical details of the methods of measurement of the DC magnetic properties of permanent magnet materials in an open magnetic circuit using a superconducting magnet (SCM).
This method is applicable to permanent magnet materials, such as those specified in IEC 60404‑8‑1, the properties of which are presumed homogeneous throughout their volume.
There are two methods:
- the SCM-vibrating sample magnetometer (VSM) method;
- the SCM-extraction method.
This document also specifies methods to correct the influence of the self-demagnetizing field in the test specimen on the demagnetization curve obtained in an open magnetic circuit. The magnetic properties are determined from the corrected demagnetization curve.
Magnetische Werkstoffe - Teil 18: Permanentmagnetische (magnetisch harte) Werkstoffe - Verfahren zur Messung der magnetischen Eigenschaften in einem offenen Magnetkreis mit Hilfe eines supraleitenden Magneten (IEC 60404-18:2025)
Matériaux magnétiques - Partie 18: Matériaux (magnétiques durs) pour aimants permanents - Méthodes de mesure des propriétés magnétiques en circuit magnétique ouvert à l'aide d'un aimant supraconducteur (IEC 60404-18:2025)
L'IEC 60404-18:2025 définit le principe général et les détails techniques des méthodes de mesure des propriétés magnétiques en courant continu des matériaux pour aimants permanents en circuit magnétique ouvert à l'aide d'un aimant supraconducteur (SCM).
Cette méthode s'applique aux matériaux pour aimants permanents, tels que ceux spécifiés dans l'IEC 60404‑8‑1, dont les propriétés sont présumées homogènes sur l'ensemble de leur volume.
Il existe deux méthodes:
- la méthode SCM-magnétomètre à échantillon vibrant (VSM, Vibrating Sample Magnetometer);
- la méthode SCM-extraction.
Le présent document spécifie également les méthodes de correction de l'influence du champ d'autodésaimantation de l'éprouvette sur la courbe de désaimantation obtenue en circuit magnétique ouvert. Les propriétés magnétiques sont déterminées à partir de la courbe de désaimantation corrigée.
Magnetni materiali - 18. del: Materiali za permanentne (trdomagnetne) magnete - Metode merjenja magnetnih lastnosti v odprtem magnetnem krogu z uporabo superprevodnega magneta (IEC 60404-18:2025)
