SIST EN 302 065-3 V1.1.1:2014

Electromagnetic compatibility and Radio spectrum Matters (ERM) - Short Range Devices (SRD) using Ultra Wide Band technology (UWB) for communications purposes - Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive - Part 3: Requirements for UWB devices for road and rail vehicles

The present document applies to transceivers, transmitters and receivers utilizing Ultra WideBand (UWB) technologies and used for short range applications in road and rail vehicles, which includes devices mounted inside or at the surface. The present document applies to impulse, modified impulse and RF carrier based UWB technologies in the main operating frequency ranges from 3,1 GHz to 4,8 GHz or from 6 GHz to 9 GHz. Examples of applications for road and rail vehicles are:
• stand-alone radio equipment with or without its own control provisions;
• plug-in radio devices intended for use with, or within, a variety of host systems, e.g. personal computers, etc.;
• plug-in radio devices intended for use within combined equipment, e.g. modems, access points, etc.;
• equipment for telemetry communication inside and outside of road and rail vehicles;
• equipment for the localization of devices inside and outside of road and rail vehicles (e.g. hand-held devices);
• equipment to investigate materials (e.g. fuel).
The present document does not apply to fixed road infrastructure installations. For fixed rail infrastructure tracking applications see TR 101 538 [i.5] and TS 103 085 [i.6]. The present document applies to UWB equipment with an output connection used with a dedicated antenna or UWB
equipment with an integral antenna. The present document applies to UWB equipment conforming to ECC/DEC/(06)04 amended 9 December 2011 [i.11]
and CEPT Report 45 [i.13].

Elektromagnetna združljivost in zadeve v zvezi z radijskim spektrom (ERM) - Naprave kratkega dosega (SRD), ki uporabljajo ultra širokopasovno (UWB) tehnologijo za komuniciranje - Harmonizirani EN, ki zajema bistvene zahteve člena 3.2 direktive R&TTE - 3. del: Zahteve za ultra širokopasovne (UWB) naprave za cestna in železniška vozila

Ta dokument velja za oddajno-sprejemne naprave, oddajnike in sprejemnike, ki uporabljajo ultra širokopasovne (UWB) tehnologije in se uporabljajo za aplikacije kratkega dosega v cestnih in železniških vozilih, vključno z napravami, nameščenimi v notranjosti ali na zunanjem delu vozila. Ta dokument velja za impulzne, spremenjene impulzne in UWB komunikacijske tehnologije, osnovane na RF nosilcih, ki delujejo v frekvenčnem območju od 3,1 GHz do 4,8 GHz ali od 6 GHz do 9 GHz. Primeri aplikacij za cestna in železniška vozila:
• samostojna radijska oprema s pripadajočimi določbami o nadzoru ali brez;
• vtične radijske naprave za uporabo z različnimi gostiteljskimi sistemi, npr. osebnimi računalniki itd., ali v njih;
• vtične radijske naprave za uporabo v sestavljenih sistemih, npr. kabelskih modemih, komunikatorjih, dostopnih točkah itd.;
• naprave za telemetrično komunikacijo v notranjosti ali na zunanjem delu cestnih in železniških vozil;
• oprema za lokalizacijo naprav v notranjosti ali na zunanjem delu cestnih in železniških vozil (npr. ročne naprave);
• oprema za preverjanje materialov (npr. goriva).
Ta dokument ne velja za fiksno obcestno infrastrukturo. Za aplikacije sledenja železniške infrastrukture glej TR 101 538 [i.5] in TS 103 085 [i.6]. Ta dokument velja za opremo UWB z izhodno povezavo in ustrezno anteno ali opremo UWB
z vgrajeno anteno. Ta dokument velja za opremo UWB, ki je v skladu s sklepom ECC/DEC/(06)04, dopolnjenim 9. decembra 2011 [i.11]
in poročilom CEPT 45 [i.13].
