SIST EN 300 175-3 V2.3.1:2010

Digital Enhanced Cordless Telecommunications (DECT) - Common Interface (CI) - Part 3: Medium Access Control (MAC) layer

The present document is one of the parts of the specification of the Digital Enhanced Cordless Telecommunications (DECT) Common Interface (CI). This part of the DECT CI specifies the Medium Access Control (MAC) layer. The MAC layer is part 3 of the DECT Common Interface standard and layer 2a of the DECT protocol stack. It specifies three groups of MAC services:
- the broadcast message control service;
- the connectionless message control service; and
- the multi-bearer control service.
It also specifies the logical channels that are used by the above mentioned services, and how they are multiplexed and mapped into the Service Data Units (SDUs) that are exchanged with the Physical Layer (PHL).
The present document includes New Generation DECT, a further development of the DECT standard introducing wideband speech, improved data services, new slot types and other technical enhancements.

Digitalne izboljšane brezvrvične telekomunikacije (DECT) - Skupni vmesnik (CI) - 3. del: Plast krmiljenja dostopa do prenosnega medija (MAC)

Pričujoči dokument je eden izmed delov specifikacije skupnega vmesnika (CI) digitalne izboljšane brezvrvične telekomunikacije (DECT).  Ta del CI DECT določa plast krmiljenja dostopa do prenosnega medija (MAC). Plast MAC je 3. del standarda skupnega vmesnika DECT in plast 2a protokolnega sklada DECT. Določa tri skupine storitev MAC:
- storitev za nadzor sporočil za oddajanje;
- storitev za nadzor sporočil brez povezave; in
- storitev za nadzor več nosilcev.
Prav tako določa logične kanale, ki jih uporabljajo zgoraj omenjene storitve, in način multipleksiranja in mapiranja v podatkovnih enotah storitev (SDU) ki se izmenjujejo z fizično plastjo (PHL).

General Information

• Status: Published
• Publication Date: 08-Sep-2010
• ICS: 33.070.30 - Digital Enhanced Cordless Telecommunications (DECT)
• Technical Committee: MOC - Mobile Communications
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 11-Aug-2010
• Due Date: 16-Oct-2010
• Completion Date: 09-Sep-2010
• Ref Project: ETSI EN 300 175-3 V2.3.1 (2010-06) - Digital Enhanced Cordless Telecommunications (DECT); Common Interface (CI); Part 3: Medium Access Control (MAC) layer

Overview

SIST EN 300 175-3 V2.3.1:2010 defines the Medium Access Control (MAC) layer for the Digital Enhanced Cordless Telecommunications (DECT) Common Interface (CI). As Part 3 of the DECT CI and layer 2a of the DECT protocol stack, this standard specifies MAC services, logical channels, and the multiplexing/mapping rules used to build Service Data Units (SDUs) exchanged with the Physical Layer (PHL). The document also incorporates New Generation DECT enhancements such as wideband speech, improved data services and new slot types.

Key Topics and Technical Requirements

The standard covers the following major technical areas:

• MAC service groups

  • Broadcast Message Control (BMC) - slow and continuous broadcast handling
  • Connectionless Message Control (CMC) - uplink/downlink connectionless messaging
  • Multi-Bearer Control (MBC) - connection-oriented multi-bearer services

• Logical channels and SAPs

  • Defines higher‑layer C‑plane and U‑plane logical channels (examples: C, I, G, CL, SI) and the broadcast channel (B)
  • Internal MAC control channels (Q, N, M, P) and their roles

• Multiplexing and mapping

  • CCF/CSF multiplexing functions and bit mapping formats (D‑MAP, A‑MAP, B‑MAP)
  • Tail multiplexer (T‑MUX), B‑field multiplexers (E/U‑MUX) and slot mode handling (E-type, E+U-type)
  • Mapping to physical packets and slot structures (document references physical packet types such as P80, P32, P00)

• Connection types and bearers

  • Basic and advanced connection structures, symmetric/asymmetric connections, connection identifiers and complementary connections
  • Bearer types and bearer operation

• Transmission integrity and security

  • Encryption, scrambling and error control mechanisms (R‑CRC, X‑CRC, B‑CRC)

• Frame and state management

  • Frame/multiframe structures, PP and RFP state definitions, cluster and cell site functions (CCF, CSF)

Practical Applications and Users

This standard is essential for:

• DECT equipment manufacturers (handsets, base stations, enterprise systems) implementing MAC layer functionality
• Chipset and firmware developers building MAC-side logic and multiplexers
• Test labs and interoperability teams conducting compliance and plug‑test activities
• Network integrators and product managers designing DECT solutions for voice and data, including New Generation DECT wideband voice and improved data services
• Regulators and standards specialists referencing MAC-level requirements for certification

Use cases include cordless telephony, enterprise DECT deployments, DECT-based IoT peripherals, and any application requiring reliable time‑division duplex (TDD) / TDMA MAC control in DECT radio systems.

Related Standards

• ETSI/EN DECT Common Interface series (other parts of EN 300 175)
• ETSI DECT specifications and national adoptions (SIST adoption shown in the document header)

Keywords: DECT MAC layer, Medium Access Control, DECT Common Interface, New Generation DECT, wideband speech, multiplexing, logical channels, TDMA, TDD, ETSI, SIST.

Standards Content (Sample)

Final draft ETSI EN 300 175-3 V2.3.0 (2010-02)
European Standard (Telecommunications series)

Digital Enhanced Cordless Telecommunications (DECT);
Common Interface (CI);
Part 3: Medium Access Control (MAC) layer

2 Final draft ETSI EN 300 175-3 V2.3.0 (2010-02)

Reference
REN/DECT-000254-3
Keywords
DECT, IMT-2000, MAC, mobility, radio, TDD,
TDMA
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE

Tel.: [phone]  Fax: [phone]

Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88

Important notice
Individual copies of the present document can be downloaded from:
http://www.etsi.org
The present document may be made available in more than one electronic version or in print. In any case of existing or
perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF).
In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive
within ETSI Secretariat.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
http://portal.etsi.org/tb/status/status.asp
If you find errors in the present document, please send your comment to one of the following services:
http://portal.etsi.org/chaircor/ETSI_support.asp
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.

© European Telecommunications Standards Institute 2010.
All rights reserved.
TM TM TM TM
DECT , PLUGTESTS , UMTS , TIPHON , the TIPHON logo and the ETSI logo are Trade Marks of ETSI registered
for the benefit of its Members.
TM
3GPP is a Trade Mark of ETSI registered for the benefit of its Members and of the 3GPP Organizational Partners.
LTE™ is a Trade Mark of ETSI currently being registered
for the benefit of its Members and of the 3GPP Organizational Partners.
GSM® and the GSM logo are Trade Marks registered and owned by the GSM Association.
ETSI
3 Final draft ETSI EN 300 175-3 V2.3.0 (2010-02)
Contents
Intellectual Property Rights . 13
Foreword . 13
1 Scope . 14
2 References . 14
2.1 Normative references . 15
2.2 Informative references . 15
3 Definitions, symbols and abbreviations . 16
3.1 Definitions . 16
3.2 Symbols and abbreviations . 16
4 Description of the MAC layer . 19
4.1 MAC layer reference model . 19
4.1.1 General . 20
4.1.2 Cluster Control Function (CCF) . 20
4.1.3 Cell Site Functions (CSF) . 20
4.1.4 Relationship to physical layer elements . 20
4.2 Frame and multiframe structures . 21
4.2.1 General . 21
4.2.2 Frame structure . 21
4.2.3 Multiframe structure . 23
4.3 State definitions . 23
4.3.1 PP states . 23
4.3.2 RFP states . 24
5 Overview of MAC layer services . 25
5.1 General . 25
5.1.1 Broadcast Message Control (BMC) . 25
5.1.2 Connectionless Message Control (CMC) . 25
5.1.3 Multi-Bearer Control . 25
5.2 Service descriptions . 25
5.2.1 Common functions . 25
5.2.2 BMC service . 26
5.2.3 CMC service . 26
5.2.4 MBC services. 26
5.3 Logical channels . 27
5.3.1 MBC connection endpoints (MC-SAP logical channels) . 27
5.3.1.1 The higher layer C-plane channels, C . 27
5.3.1.2 The higher layer U-Plane channels, I . 27
5.3.1.3 The higher layer U-Plane control channel, G . 28
F
5.3.1.4 The higher layer U-Plane channel in E+U type slots, I . 28
PF
5.3.2 CMC endpoints (MB-SAP logical channels) . 28
5.3.2.1 The connectionless C-Plane channels, CL . 28
5.3.2.2 The connectionless U-Plane channels, SI and SI . 29
N P
5.3.2.3 The connectionless U-Plane channel in E+U type slots, SI . 29
PF
5.3.3 BMC endpoint (MA-SAP logical channel) . 29
5.3.3.1 The slow broadcast channel, B . 29
S
5.3.4 Internal MAC control channels . 29
5.3.4.1 The system information channel, Q . 29
5.3.4.2 Identities channel, N. 30
5.3.4.3 The MAC control channel, M . 30
5.3.4.4 MAC paging channel, P . 30
5.4 SAP definitions . 30
5.4.1 MA SAP . 30
5.4.2 MB SAP . 31
5.4.3 MC SAP . 31
ETSI
4 Final draft ETSI EN 300 175-3 V2.3.0 (2010-02)
5.4.4 ME SAP . 32
5.4.5 Order of transmission. 32
5.5 Bearers . 32
5.5.1 Bearer types . 32
5.5.2 Bearer operation . 33
5.6 Connection oriented services . 33
5.6.1 Connection types . 33
5.6.1.1 Basic connections . 33
5.6.1.2 Advanced connections . 34
5.6.1.2.1 Rules for ECN selection in advanced connections . 34
5.6.1.3 Connection identifiers . 34
5.6.1.4 Complementary connections . 35
5.6.2 Symmetric and asymmetric connections . 35
5.6.2.1 Symmetric connections . 35
5.6.2.2 Asymmetric connections . 40
5.7 Broadcast and connectionless services . 48
5.7.1 The broadcast services . 49
5.7.1.1 The continuous broadcast service . 49
5.7.1.2 The non-continuous broadcast service . 49
5.7.2 The connectionless services . 50
5.7.2.1 Connectionless downlink services . 50
5.7.2.2 Connectionless uplink services . 50
6 Multiplexing . 51
6.1 CCF multiplexing functions . 51
6.2 CSF multiplexing functions . 51
6.2.1 Bit Mappings (MAP) . 56
6.2.1.1 D-field mapping (D-MAP) . 56
6.2.1.1.1 D-field mapping for the double slot structure (physical packet P80) . 57
6.2.1.1.2 D-field mapping for the full slot structure (physical packet P32) . 57
6.2.1.1.3 D-field mapping for the short slot structure (physical packet P00) . 58
6.2.1.1.4 D-field mapping for the variable slot structure (physical packet P00j) . 58
6.2.1.2 A-field Mapping (A-MAP) . 59
6.2.1.3 B-field Mapping (B-MAP) . 60
6.2.1.3.1 Unprotected format . 60
6.2.1.3.2 Encoded protected format . 62
6.2.1.3.3 Multisubfield protected format . 62
6.2.1.3.4 Singlesubfield protected format . 64
6.2.2 Time multiplexers . 66
6.2.2.1 Tail MUltipleXer (T-MUX) . 66
6.2.2.1.1 T-MUX algorithm for RFP transmissions . 66
6.2.2.1.2 T-MUX algorithm for PT transmissions . 67
6.2.2.2 B-field control multiplexer (E/U-MUX) . 68
6.2.2.3 B-field mode multiplexer E-type and E+U-type modes . 70
6.2.2.3.1 E-type and E+U-type modes for slots with more than one subfield . 70
6.2.2.3.2 Half slot (j=80) modes for 2-level modulation . 84
6.2.2.4 Priority scheme in E or E+U mode . 84
6.2.3 Encryption. 85
6.2.4 Scrambling . 86
6.2.5 Error control. 88
6.2.5.1 R-CRC overview . 88
6.2.5.2 R-CRC generation and checking . 88
6.2.5.3 X-CRC overvie w . 89
6.2.5.4 X-CRC generation and checking . 89
6.2.5.5 B-CRC generation and checking . 91
6.2.6 Broadcast controller . 92
7 Medium access layer messages . 92
7.1 Header field . 92
7.1.1 Overview/formatting . 92
7.1.2 Tail identification, TA, bits a to a . 93
0 2
7.1.3 The "Q1/BCK" bit, bit a . 93
ETSI
5 Final draft ETSI EN 300 175-3 V2.3.0 (2010-02)
7.1.4 B-field identification, BA, bits a to a . 94
4 6
7.1.5 The "Q2" bit, bit a . 95
7.2 Messages in the tail field . 95
7.2.1 Overview . 95
7.2.2 Identities information (N ) . 95
T
7.2.3 System information and multiframe marker (Q ) . 96
T
7.2.3.1 General . 96
7.2.3.2 Static system information . 97
7.2.3.2.1 General, Q = 0, 1 (hex) . 97
H
7.2.3.2.2 Q and Normal-Reverse (NR) . 97
H
7.2.3.2.3 Slot Number (SN) . 97
7.2.3.2.4 Start Position (SP) . 98
7.2.3.2.5 ESCape bit (ESC) . 98
7.2.3.2.6 Number of transceivers . 98
7.2.3.2.7 Extended RF carrier information available (Mc) . 98
7.2.3.2.8 RF carriers available (RF-cars) . 99
7.2.3.2.9 Spare bits (SPR) . 99
7.2.3.2.10 Carrier number. 99
7.2.3.2.11 Spare bits (SPR) . 99
7.2.3.2.12 Primary receiver Scan Carrier Number (PSCN) . 100
7.2.3.3 Extended RF carrier information part 1 . 100
7.2.3.3.1 General, Q = 2 (hex) . 100
H
7.2.3.3.2 Further RF carrier extensions . 101
7.2.3.3.3 Number of RF carriers . 101
7.2.3.4 Fixed part capabilities . 101
7.2.3.4.1 General, Q = 3 (hex) . 101
H
7.2.3.4.2 Standard capabilities . 101
7.2.3.5 Extended fixed part capabilities . 102
7.2.3.5.1 General, Q = 4 (hex) . 102
H
7.2.3.5.2 Extended Physical and MAC layer capabilities . 103
7.2.3.5.3 Extended higher layer capabilities . 104
7.2.3.6 Secondary access rights identities . 104
7.2.3.6.1 General, Q = 5 (hex) . 104
H
7.2.3.6.2 SARI message . 104
7.2.3.7 Multiframe number . 104
7.2.3.7.1 General, Q = 6 (hex) . 104
H
7.2.3.7.2 Multiframe number . 104
7.2.3.8 Escape . 105
7.2.3.8.1 General, Q = 7 (hex) . 105
H
7.2.3.8.2 Escape information . 105
7.2.3.9 Extended RF carrier information part 2 . 105
7.2.3.9.1 General, Q = 9 (hex) . 105
H
7.2.3.10 Transmit information . 105
7.2.3.10.1 General, Q = B (hex) . 105
H
7.2.3.11 Extended fixed part capabilities (part 2) . 106
7.2.3.11.1 General, Q = C (hex) . 106
H
7.2.3.11.2 Extended Physical and MAC layer capabilities (part 2) . 106
7.2.3.11.3 Extended higher layer capabilities (part 2) . 107
7.2.4 Paging Tail (P ) . 107
T
7.2.4.1 General format . 107
7.2.4.1.1 P format for full and long page messages . 107
T
7.2.4.1.2 P format for short page messages . 108
T
7.2.4.1.3 P format for zero length page messages . 108
T
7.2.4.1.4 P format for MAC_Resume_and_Control_page message . 108
T
7.2.4.2 P header format . 109
T
7.2.4.2.1 General format . 109
7.2.4.2.2 Bit a is the extend flag . 109
7.2.4.2.3 B SDU length indication . 109
S
7.2.4.3 MAC layer information for PT. 110
7.2.4.3.1 Information type . 110
7.2.4.3.2 Fill bits / Blind long slot (j=640 / j=672) information . 110
7.2.4.3.3 Blind full slot information . 111
ETSI
6 Final draft ETSI EN 300 175-3 V2.3.0 (2010-02)
7.2.4.3.4 Bearer description . 111
7.2.4.3.5 Escape . 112
7.2.4.3.6 Dummy or connectionless downlink bearer marker . 112
7.2.4.3.7 Bearer handover/replacement information . 112
7.2.4.3.8 RFP status and modulation types . 113
7.2.4.3.9 Active carriers . 114
7.2.4.3.10 RFP power level . 114
7.2.4.3.11 Blind double slot/RFP-FP interface resource information . 115
7.2.4.3.12 Extended modulation types . 115
7.2.5 MAC control (M ) . 116
T
7.2.5.1 General format and contents . 116
7.2.5.2 Basic connection control . 116
7.2.5.2.1 General . 116
7.2.5.2.2 Format for most messages . 117
7.2.5.2.3 WAIT . 117
7.2.5.2.4 ATTRIBUTES_T_{Req;Cfm} . 117
7.2.5.3 Advanced connection control . 118
7.2.5.3.1 General . 118
7.2.5.3.2 ACCESS_REQUEST . 118
7.2.5.3.3 BEARER_HANDOVER_REQUEST . 118
7.2.5.3.4 CONNECTION_HANDOVER_REQUEST . 118
7.2.5.3.5 UNCONFIRMED_ACCESS_REQUEST . 119
7.2.5.3.6 BEARER_CONFIRM . 119
7.2.5.3.7 WAIT . 119
7.2.5.3.8 ATTRIBUTES_T_{Req;Cfm} . 119
7.2.5.3.9 BANDWIDTH_T_{Req;Cfm} . 122
7.2.5.3.10 Channel_list . 122
7.2.5.3.11 Unconfirmed_dummy . 123
7.2.5.3.12 Unconfirmed_handover . 123
7.2.5.3.13 RELEASE . 123
7.2.5.4 MAC layer test messages . 124
7.2.5.4.1 Basic format . 124
7.2.5.4.2 FORCE_TRANSMIT . 125
7.2.5.4.3 LOOPBACK_DATA . 125
7.2.5.4.4 DEFEAT_ANTENNA_DIVERSITY. 126
7.2.5.4.5 ESCAPE . 127
7.2.5.4.6 NETWORK_TEST . 127
7.2.5.4.7 CLEAR_TEST_MODES. 127
7.2.5.4.8 CHANGE_MODULATION_SCHEME . 127
7.2.5.5 Quality control . 128
7.2.5.5.1 Prolonged preamble diversity . 129
7.2.5.6 Broadcast and connectionless services . 130
7.2.5.7 Encryption control . 130
7.2.5.8 B-field setup, first PT transmission . 131
7.2.5.9 Escape . 132
7.2.5.10 TARI message . 132
7.2.5.11 REP connection control . 132
7.2.5.11.1 General . 132
7.2.5.11.2 Format for most messages . 132
7.2.5.11.3 REP CHANNEL MAP REQUEST . 133
7.2.5.11.4 REP CHANNEL MAP CONFIRM . 133
7.3 Messages in the B-field . 133
7.3.1 Overview . 133
7.3.2 Advanced connection control . 134
7.3.2.1 General format . 134
7.3.2.2 BEARER_REQUEST . 135
7.3.2.3 BEARER_CONFIRM . 135
7.3.2.4 WAIT . 136
7.3.2.5 ATTRIBUTES_B_{Req;Cfm} . 136
7.3.2.6 BANDWIDTH_B_{Req;Cfm} . 137
7.3.2.7 CHANNEL_LIST . 137
7.3.2.8 UNCONFIRMED_DUMMY . 137
ETSI
7 Final draft ETSI EN 300 175-3 V2.3.0 (2010-02)
7.3.2.9 UNCONFIRMED_HANDOVER . 138
7.3.2.10 RELEASE . 138
7.3.3 Null or I segmentation info . 139
PF
7.3.3.1 Spare or I segmentation info . 140
PF
7.3.3.2 Extended NCF bits . 141
7.3.4 Quality control . 141
7.3.4.1 General format . 141
7.3.4.2 Bearer and connection control. 141
7.3.4.3 RESET . 143
7.3.4.4 Bearer quality in an asymmetric connection . 143
7.3.5 Extended system information . 144
7.3.5.1 General format . 144
7.3.5.2 TARI messages . 144
7.3.5.3 "no-emission" mode sync information . 144
7.3.6 G channel data packet . 145
F
7.3.7 Escape . 145
8 Medium access layer primitives . 145
8.1 Connection oriented service primitives . 146
8.1.1 Connection setup: MAC_CON {req;ind;cfm} . 146
8.1.2 Connection modification: MAC_MOD {req;ind;cfm} . 147
8.1.3 CO data transmit ready: MAC_CO_DTR {ind} . 148
8.1.4 CO data transfer: MAC_CO_DATA {req;ind} . 149
8.1.5 Restart DLC: MAC_RES_DLC {ind} . 149
8.1.6 Connection release: MAC_DIS {req;ind} . 149
8.1.7 MAC bandwidth: MAC_BW {ind;res} . 150
8.1.8 Encryption. 150
8.1.8.1 Load encryption key: MAC_ENC_KEY {req} . 150
8.1.8.2 Enable/disable encryption: MAC_ENC_EKS {req;ind;cfm} . 150
8.1.9 C-plane switching procedure . 151
8.1.9.1 C-plane switching procedure: MAC_C _C {req, cfm, ind, res} . 151
S F
8.1.9.2 C-plane switching procedure: MAC_C C _END {ind} . 151
S F
8.2 Connectionless and broadcast service primitives . 152
8.2.1 Paging: MAC_PAGE {req;ind} . 152
8.2.2 Downlink connectionless: MAC_DOWN_CON {req;ind} . 152
8.2.3 Uplink connectionless: MAC_UP_CON {req;ind;cfm} . 153
8.2.4 "no-emission" mode . 153
8.3 Management primitives . 153
8.3.1 Connection control .
...

European Standard (Telecommunications series)

Digital Enhanced Cordless Telecommunications (DECT);
Common Interface (CI);
Part 3: Medium Access Control (MAC) layer

2 ETSI EN 300 175-3 V2.3.1 (2010-06)

Reference
REN/DECT-000254-3
Keywords
DECT, IMT-2000, MAC, mobility, radio, TDD,
TDMA
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE

Tel.: [phone]  Fax: [phone]

Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88

Important notice
Individual copies of the present document can be downloaded from:
http://www.etsi.org
The present document may be made available in more than one electronic version or in print. In any case of existing or
perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF).
In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive
within ETSI Secretariat.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
http://portal.etsi.org/tb/status/status.asp
If you find errors in the present document, please send your comment to one of the following services:
http://portal.etsi.org/chaircor/ETSI_support.asp
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.

© European Telecommunications Standards Institute 2010.
All rights reserved.
TM TM TM TM
DECT , PLUGTESTS , UMTS , TIPHON , the TIPHON logo and the ETSI logo are Trade Marks of ETSI registered
for the benefit of its Members.
TM
3GPP is a Trade Mark of ETSI registered for the benefit of its Members and of the 3GPP Organizational Partners.
LTE™ is a Trade Mark of ETSI currently being registered
for the benefit of its Members and of the 3GPP Organizational Partners.
GSM® and the GSM logo are Trade Marks registered and owned by the GSM Association.
ETSI
3 ETSI EN 300 175-3 V2.3.1 (2010-06)
Contents
Intellectual Property Rights . 13
Foreword . 13
1 Scope . 14
2 References . 14
2.1 Normative references . 14
2.2 Informative references . 15
3 Definitions, symbols and abbreviations . 15
3.1 Definitions . 15
3.2 Symbols and abbreviations . 16
4 Description of the MAC layer . 18
4.1 MAC layer reference model . 18
4.1.1 General . 19
4.1.2 Cluster Control Function (CCF) . 19
4.1.3 Cell Site Functions (CSF) . 19
4.1.4 Relationship to physical layer elements . 19
4.2 Frame and multiframe structures . 20
4.2.1 General . 20
4.2.2 Frame structure . 20
4.2.3 Multiframe structure . 22
4.3 State definitions . 22
4.3.1 PP states . 22
4.3.2 RFP states . 23
5 Overview of MAC layer services . 24
5.1 General . 24
5.1.1 Broadcast Message Control (BMC) . 24
5.1.2 Connectionless Message Control (CMC) . 24
5.1.3 Multi-Bearer Control . 24
5.2 Service descriptions . 24
5.2.1 Common functions . 24
5.2.2 BMC service . 25
5.2.3 CMC service . 25
5.2.4 MBC services. 25
5.3 Logical channels . 26
5.3.1 MBC connection endpoints (MC-SAP logical channels) . 26
5.3.1.1 The higher layer C-plane channels, C . 26
5.3.1.2 The higher layer U-Plane channels, I . 26
5.3.1.3 The higher layer U-Plane control channel, G . 27
F
5.3.1.4 The higher layer U-Plane channel in E+U type slots, I . 27
PF
5.3.2 CMC endpoints (MB-SAP logical channels) . 28
5.3.2.1 The connectionless C-Plane channels, CL . 28
5.3.2.2 The connectionless U-Plane channels, SI and SI . 28
N P
5.3.2.3 The connectionless U-Plane channel in E+U type slots, SI . 28
PF
5.3.3 BMC endpoint (MA-SAP logical channel) . 28
5.3.3.1 The slow broadcast channel, B . 28
S
5.3.4 Internal MAC control channels . 29
5.3.4.1 The system information channel, Q . 29
5.3.4.2 Identities channel, N. 29
5.3.4.3 The MAC control channel, M . 29
5.3.4.4 MAC paging channel, P . 29
5.4 SAP definitions . 30
5.4.1 MA SAP . 30
5.4.2 MB SAP . 30
5.4.3 MC SAP . 30
ETSI
4 ETSI EN 300 175-3 V2.3.1 (2010-06)
5.4.4 ME SAP . 31
5.4.5 Order of transmission. 31
5.5 Bearers . 31
5.5.1 Bearer types . 31
5.5.2 Bearer operation . 32
5.6 Connection oriented services . 32
5.6.1 Connection types . 32
5.6.1.1 Basic connections . 33
5.6.1.2 Advanced connections . 33
5.6.1.2.1 Rules for ECN selection in advanced connections . 33
5.6.1.3 Connection identifiers . 34
5.6.1.4 Complementary connections . 34
5.6.2 Symmetric and asymmetric connections . 34
5.6.2.1 Symmetric connections . 35
5.6.2.2 Asymmetric connections . 40
5.7 Broadcast and connectionless services . 48
5.7.1 The broadcast services . 49
5.7.1.1 The continuous broadcast service . 49
5.7.1.2 The non-continuous broadcast service . 49
5.7.2 The connectionless services . 50
5.7.2.1 Connectionless downlink services . 50
5.7.2.2 Connectionless uplink services . 50
6 Multiplexing . 51
6.1 CCF multiplexing functions . 51
6.2 CSF multiplexing functions . 51
6.2.1 Bit Mappings (MAP) . 56
6.2.1.1 D-field mapping (D-MAP) . 56
6.2.1.1.1 D-field mapping for the double slot structure (physical packet P80) . 57
6.2.1.1.2 D-field mapping for the full slot structure (physical packet P32) . 57
6.2.1.1.3 D-field mapping for the short slot structure (physical packet P00) . 58
6.2.1.1.4 D-field mapping for the variable slot structure (physical packet P00j) . 58
6.2.1.2 A-field Mapping (A-MAP) . 59
6.2.1.3 B-field Mapping (B-MAP) . 60
6.2.1.3.1 Unprotected format . 60
6.2.1.3.2 Encoded protected format . 62
6.2.1.3.3 Multisubfield protected format . 62
6.2.1.3.4 Singlesubfield protected format . 64
6.2.2 Time multiplexers . 66
6.2.2.1 Tail MUltipleXer (T-MUX) . 66
6.2.2.1.1 T-MUX algorithm for RFP transmissions . 67
6.2.2.1.2 T-MUX algorithm for PT transmissions . 68
6.2.2.2 B-field control multiplexer (E/U-MUX) . 68
6.2.2.3 B-field mode multiplexer E-type and E+U-type modes . 70
6.2.2.3.1 E-type and E+U-type modes for slots with more than one subfield . 70
6.2.2.3.2 Half slot (j=80) modes for 2-level modulation . 84
6.2.2.4 Priority scheme in E or E+U mode . 85
6.2.3 Encryption. 86
6.2.4 Scrambling . 86
6.2.5 Error control. 88
6.2.5.1 R-CRC overview . 88
6.2.5.2 R-CRC generation and checking . 89
6.2.5.3 X-CRC overvie w . 89
6.2.5.4 X-CRC generation and checking . 89
6.2.5.5 B-CRC generation and checking . 91
6.2.6 Broadcast controller . 92
7 Medium access layer messages . 92
7.1 Header field . 93
7.1.1 Overview/formatting . 93
7.1.2 Tail identification, TA, bits a to a . 93
0 2
7.1.3 The "Q1/BCK" bit, bit a . 93
ETSI
5 ETSI EN 300 175-3 V2.3.1 (2010-06)
7.1.4 B-field identification, BA, bits a to a . 94
4 6
7.1.5 The "Q2" bit, bit a . 95
7.2 Messages in the tail field . 95
7.2.1 Overview . 95
7.2.2 Identities information (N ) . 95
T
7.2.3 System information and multiframe marker (Q ) . 96
T
7.2.3.1 General . 96
7.2.3.2 Static system information . 97
7.2.3.2.1 General, Q = 0, 1 (hex) . 97
H
7.2.3.2.2 Q and Normal-Reverse (NR) . 97
H
7.2.3.2.3 Slot Number (SN) . 97
7.2.3.2.4 Start Position (SP) . 98
7.2.3.2.5 ESCape bit (ESC) . 98
7.2.3.2.6 Number of transceivers . 98
7.2.3.2.7 Extended RF carrier information available (Mc) . 98
7.2.3.2.8 RF carriers available (RF-cars) . 99
7.2.3.2.9 Spare bits (SPR) . 99
7.2.3.2.10 Carrier number. 99
7.2.3.2.11 Spare bits (SPR) . 99
7.2.3.2.12 Primary receiver Scan Carrier Number (PSCN) . 100
7.2.3.3 Extended RF carrier information part 1 . 100
7.2.3.3.1 General, Q = 2 (hex) . 100
H
7.2.3.3.2 Further RF carrier extensions . 101
7.2.3.3.3 Number of RF carriers . 101
7.2.3.4 Fixed part capabilities . 101
7.2.3.4.1 General, Q = 3 (hex) . 101
H
7.2.3.4.2 Standard capabilities . 101
7.2.3.5 Extended fixed part capabilities . 102
7.2.3.5.1 General, Q = 4 (hex) . 102
H
7.2.3.5.2 Extended Physical and MAC layer capabilities . 103
7.2.3.5.3 Extended higher layer capabilities . 104
7.2.3.6 Secondary access rights identities . 104
7.2.3.6.1 General, Q = 5 (hex) . 104
H
7.2.3.6.2 SARI message . 104
7.2.3.7 Multiframe number . 104
7.2.3.7.1 General, Q = 6 (hex) . 104
H
7.2.3.7.2 Multiframe number . 104
7.2.3.8 Escape . 105
7.2.3.8.1 General, Q = 7 (hex) . 105
H
7.2.3.8.2 Escape information . 105
7.2.3.9 Extended RF carrier information part 2 . 105
7.2.3.9.1 General, Q = 9 (hex) . 105
H
7.2.3.10 Transmit information . 105
7.2.3.10.1 General, Q = B (hex) . 105
H
7.2.3.11 Extended fixed part capabilities (part 2) . 106
7.2.3.11.1 General, Q = C (hex) . 106
H
7.2.3.11.2 Extended Physical and MAC layer capabilities (part 2) . 106
7.2.3.11.3 Extended higher layer capabilities (part 2) . 107
7.2.4 Paging Tail (P ) . 107
T
7.2.4.1 General format . 107
7.2.4.1.1 P format for full and long page messages . 107
T
7.2.4.1.2 P format for short page messages . 108
T
7.2.4.1.3 P format for zero length page messages . 108
T
7.2.4.1.4 P format for MAC_Resume_and_Control_page message . 108
T
7.2.4.2 P header format . 109
T
7.2.4.2.1 General format . 109
7.2.4.2.2 Bit a is the extend flag . 109
7.2.4.2.3 B SDU length indication . 109
S
7.2.4.3 MAC layer information for PT. 110
7.2.4.3.1 Information type . 110
7.2.4.3.2 Fill bits / Blind long slot (j=640 / j=672) information . 110
7.2.4.3.3 Blind full slot information . 111
ETSI
6 ETSI EN 300 175-3 V2.3.1 (2010-06)
7.2.4.3.4 Bearer description . 111
7.2.4.3.5 Escape . 112
7.2.4.3.6 Dummy or connectionless downlink bearer marker . 112
7.2.4.3.7 Bearer handover/replacement information . 112
7.2.4.3.8 RFP status and modulation types . 113
7.2.4.3.9 Active carriers . 114
7.2.4.3.10 RFP power level . 114
7.2.4.3.11 Blind double slot/RFP-FP interface resource information . 115
7.2.4.3.12 Extended modulation types . 115
7.2.5 MAC control (M ) . 116
T
7.2.5.1 General format and contents . 116
7.2.5.2 Basic connection control . 116
7.2.5.2.1 General . 116
7.2.5.2.2 Format for most messages . 117
7.2.5.2.3 WAIT . 117
7.2.5.2.4 ATTRIBUTES_T_{Req;Cfm} . 117
7.2.5.3 Advanced connection control . 118
7.2.5.3.1 General . 118
7.2.5.3.2 ACCESS_REQUEST . 118
7.2.5.3.3 BEARER_HANDOVER_REQUEST . 118
7.2.5.3.4 CONNECTION_HANDOVER_REQUEST . 118
7.2.5.3.5 UNCONFIRMED_ACCESS_REQUEST . 119
7.2.5.3.6 BEARER_CONFIRM . 119
7.2.5.3.7 WAIT . 119
7.2.5.3.8 ATTRIBUTES_T_{Req;Cfm} . 119
7.2.5.3.9 BANDWIDTH_T_{Req;Cfm} . 122
7.2.5.3.10 Channel_list . 122
7.2.5.3.11 Unconfirmed_dummy . 123
7.2.5.3.12 Unconfirmed_handover . 123
7.2.5.3.13 RELEASE . 123
7.2.5.4 MAC layer test messages . 124
7.2.5.4.1 Basic format . 124
7.2.5.4.2 FORCE_TRANSMIT . 125
7.2.5.4.3 LOOPBACK_DATA . 125
7.2.5.4.4 DEFEAT_ANTENNA_DIVERSITY. 126
7.2.5.4.5 ESCAPE . 127
7.2.5.4.6 NETWORK_TEST . 127
7.2.5.4.7 CLEAR_TEST_MODES. 127
7.2.5.4.8 CHANGE_MODULATION_SCHEME . 127
7.2.5.5 Quality control . 128
7.2.5.5.1 Prolonged preamble diversity . 129
7.2.5.6 Broadcast and connectionless services . 130
7.2.5.7 Encryption control . 130
7.2.5.8 B-field setup, first PT transmission . 131
7.2.5.9 Escape . 132
7.2.5.10 TARI message . 132
7.2.5.11 REP connection control . 132
7.2.5.11.1 General . 132
7.2.5.11.2 Format for most messages . 132
7.2.5.11.3 REP CHANNEL MAP REQUEST . 133
7.2.5.11.4 REP CHANNEL MAP CONFIRM . 133
7.3 Messages in the B-field . 133
7.3.1 Overview . 133
7.3.2 Advanced connection control . 134
7.3.2.1 General format . 134
7.3.2.2 BEARER_REQUEST . 135
7.3.2.3 BEARER_CONFIRM . 135
7.3.2.4 WAIT . 136
7.3.2.5 ATTRIBUTES_B_{Req;Cfm} . 136
7.3.2.6 BANDWIDTH_B_{Req;Cfm} . 137
7.3.2.7 CHANNEL_LIST . 137
7.3.2.8 UNCONFIRMED_DUMMY . 137
ETSI
7 ETSI EN 300 175-3 V2.3.1 (2010-06)
7.3.2.9 UNCONFIRMED_HANDOVER . 138
7.3.2.10 RELEASE . 138
7.3.3 Null or I segmentation info . 139
PF
7.3.3.1 Spare or I segmentation info . 140
PF
7.3.3.2 Extended NCF bits . 141
7.3.4 Quality control . 141
7.3.4.1 General format . 141
7.3.4.2 Bearer and connection control. 141
7.3.4.3 RESET . 143
7.3.4.4 Bearer quality in an asymmetric connection . 143
7.3.5 Extended system information . 144
7.3.5.1 General format . 144
7.3.5.2 TARI messages . 144
7.3.5.3 "no-emission" mode sync information . 144
7.3.6 G channel data packet . 145
F
7.3.7 Escape . 145
8 Medium access layer primitives . 145
8.1 Connection oriented service primitives . 146
8.1.1 Connection setup: MAC_CON {req;ind;cfm} . 146
8.1.2 Connection modification: MAC_MOD {req;ind;cfm} . 147
8.1.3 CO data transmit ready: MAC_CO_DTR {ind} . 148
8.1.4 CO data transfer: MAC_CO_DATA {req;ind} . 149
8.1.5 Restart DLC: MAC_RES_DLC {ind} . 149
8.1.6 Connection release: MAC_DIS {req;ind} . 149
8.1.7 MAC bandwidth: MAC_BW {ind;res} . 150
8.1.8 Encryption. 150
8.1.8.1 Load encryption key: MAC_ENC_KEY {req} . 150
8.1.8.2 Enable/disable encryption: MAC_ENC_EKS {req;ind;cfm} . 150
8.1.9 C-plane switching procedure . 151
8.1.9.1 C-plane switching procedure: MAC_C _C {req, cfm, ind, res} . 151
S F
8.1.9.2 C-plane switching procedure: MAC_C C _END {ind} . 151
S F
8.2 Connectionless and broadcast service primitives . 152
8.2.1 Paging: MAC_PAGE {req;ind} . 152
8.2.2 Downlink connectionless: MAC_DOWN_CON {req;ind} . 152
8.2.3 Uplink connectionless: MAC_UP_CON {req;ind;cfm} . 153
8.2.4 "no-emission" mode . 153
8.3 Management primitives . 153
8.3.1 Connection control . 153
8.3.1.1 Connection se
...

SLOVENSKI STANDARD
01-oktober-2010
'LJLWDOQHL]EROMãDQHEUH]YUYLþQHWHOHNRPXQLNDFLMH'(&76NXSQLYPHVQLN&,
GHO3ODVWNUPLOMHQMDGRVWRSDGRSUHQRVQHJDPHGLMD0$&
Digital Enhanced Cordless Telecommunications (DECT) - Common Interface (CI) - Part
3: Medium Access Control (MAC) layer
Ta slovenski standard je istoveten z: EN 300 175-3 Version 2.3.1
ICS:
33.070.30 'LJLWDOQHL]EROMãDQH Digital Enhanced Cordless
EUH]YUYLþQHWHOHNRPXQLNDFLMH Telecommunications (DECT)
'(&7
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

European Standard (Telecommunications series)

Digital Enhanced Cordless Telecommunications (DECT);
Common Interface (CI);
Part 3: Medium Access Control (MAC) layer

2 ETSI EN 300 175-3 V2.3.1 (2010-06)

Reference
REN/DECT-000254-3
Keywords
DECT, IMT-2000, MAC, mobility, radio, TDD,
TDMA
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE

Tel.: [phone]  Fax: [phone]

Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88

Important notice
Individual copies of the present document can be downloaded from:
http://www.etsi.org
The present document may be made available in more than one electronic version or in print. In any case of existing or
perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF).
In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive
within ETSI Secretariat.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
http://portal.etsi.org/tb/status/status.asp
If you find errors in the present document, please send your comment to one of the following services:
http://portal.etsi.org/chaircor/ETSI_support.asp
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.

© European Telecommunications Standards Institute 2010.
All rights reserved.
TM TM TM TM
DECT , PLUGTESTS , UMTS , TIPHON , the TIPHON logo and the ETSI logo are Trade Marks of ETSI registered
for the benefit of its Members.
TM
3GPP is a Trade Mark of ETSI registered for the benefit of its Members and of the 3GPP Organizational Partners.
LTE™ is a Trade Mark of ETSI currently being registered
for the benefit of its Members and of the 3GPP Organizational Partners.
GSM® and the GSM logo are Trade Marks registered and owned by the GSM Association.
ETSI
3 ETSI EN 300 175-3 V2.3.1 (2010-06)
Contents
Intellectual Property Rights . 13
Foreword . 13
1 Scope . 14
2 References . 14
2.1 Normative references . 14
2.2 Informative references . 15
3 Definitions, symbols and abbreviations . 15
3.1 Definitions . 15
3.2 Symbols and abbreviations . 16
4 Description of the MAC layer . 18
4.1 MAC layer reference model . 18
4.1.1 General . 19
4.1.2 Cluster Control Function (CCF) . 19
4.1.3 Cell Site Functions (CSF) . 19
4.1.4 Relationship to physical layer elements . 19
4.2 Frame and multiframe structures . 20
4.2.1 General . 20
4.2.2 Frame structure . 20
4.2.3 Multiframe structure . 22
4.3 State definitions . 22
4.3.1 PP states . 22
4.3.2 RFP states . 23
5 Overview of MAC layer services . 24
5.1 General . 24
5.1.1 Broadcast Message Control (BMC) . 24
5.1.2 Connectionless Message Control (CMC) . 24
5.1.3 Multi-Bearer Control . 24
5.2 Service descriptions . 24
5.2.1 Common functions . 24
5.2.2 BMC service . 25
5.2.3 CMC service . 25
5.2.4 MBC services. 25
5.3 Logical channels . 26
5.3.1 MBC connection endpoints (MC-SAP logical channels) . 26
5.3.1.1 The higher layer C-plane channels, C . 26
5.3.1.2 The higher layer U-Plane channels, I . 26
5.3.1.3 The higher layer U-Plane control channel, G . 27
F
5.3.1.4 The higher layer U-Plane channel in E+U type slots, I . 27
PF
5.3.2 CMC endpoints (MB-SAP logical channels) . 28
5.3.2.1 The connectionless C-Plane channels, CL . 28
5.3.2.2 The connectionless U-Plane channels, SI and SI . 28
N P
5.3.2.3 The connectionless U-Plane channel in E+U type slots, SI . 28
PF
5.3.3 BMC endpoint (MA-SAP logical channel) . 28
5.3.3.1 The slow broadcast channel, B . 28
S
5.3.4 Internal MAC control channels . 29
5.3.4.1 The system information channel, Q . 29
5.3.4.2 Identities channel, N. 29
5.3.4.3 The MAC control channel, M . 29
5.3.4.4 MAC paging channel, P . 29
5.4 SAP definitions . 30
5.4.1 MA SAP . 30
5.4.2 MB SAP . 30
5.4.3 MC SAP . 30
ETSI
4 ETSI EN 300 175-3 V2.3.1 (2010-06)
5.4.4 ME SAP . 31
5.4.5 Order of transmission. 31
5.5 Bearers . 31
5.5.1 Bearer types . 31
5.5.2 Bearer operation . 32
5.6 Connection oriented services . 32
5.6.1 Connection types . 32
5.6.1.1 Basic connections . 33
5.6.1.2 Advanced connections . 33
5.6.1.2.1 Rules for ECN selection in advanced connections . 33
5.6.1.3 Connection identifiers . 34
5.6.1.4 Complementary connections . 34
5.6.2 Symmetric and asymmetric connections . 34
5.6.2.1 Symmetric connections . 35
5.6.2.2 Asymmetric connections . 40
5.7 Broadcast and connectionless services . 48
5.7.1 The broadcast services . 49
5.7.1.1 The continuous broadcast service . 49
5.7.1.2 The non-continuous broadcast service . 49
5.7.2 The connectionless services . 50
5.7.2.1 Connectionless downlink services . 50
5.7.2.2 Connectionless uplink services . 50
6 Multiplexing . 51
6.1 CCF multiplexing functions . 51
6.2 CSF multiplexing functions . 51
6.2.1 Bit Mappings (MAP) . 56
6.2.1.1 D-field mapping (D-MAP) . 56
6.2.1.1.1 D-field mapping for the double slot structure (physical packet P80) . 57
6.2.1.1.2 D-field mapping for the full slot structure (physical packet P32) . 57
6.2.1.1.3 D-field mapping for the short slot structure (physical packet P00) . 58
6.2.1.1.4 D-field mapping for the variable slot structure (physical packet P00j) . 58
6.2.1.2 A-field Mapping (A-MAP) . 59
6.2.1.3 B-field Mapping (B-MAP) . 60
6.2.1.3.1 Unprotected format . 60
6.2.1.3.2 Encoded protected format . 62
6.2.1.3.3 Multisubfield protected format . 62
6.2.1.3.4 Singlesubfield protected format . 64
6.2.2 Time multiplexers . 66
6.2.2.1 Tail MUltipleXer (T-MUX) . 66
6.2.2.1.1 T-MUX algorithm for RFP transmissions . 67
6.2.2.1.2 T-MUX algorithm for PT transmissions . 68
6.2.2.2 B-field control multiplexer (E/U-MUX) . 68
6.2.2.3 B-field mode multiplexer E-type and E+U-type modes . 70
6.2.2.3.1 E-type and E+U-type modes for slots with more than one subfield . 70
6.2.2.3.2 Half slot (j=80) modes for 2-level modulation . 84
6.2.2.4 Priority scheme in E or E+U mode . 85
6.2.3 Encryption. 86
6.2.4 Scrambling . 86
6.2.5 Error control. 88
6.2.5.1 R-CRC overview . 88
6.2.5.2 R-CRC generation and checking . 89
6.2.5.3 X-CRC overvie w . 89
6.2.5.4 X-CRC generation and checking . 89
6.2.5.5 B-CRC generation and checking . 91
6.2.6 Broadcast controller . 92
7 Medium access layer messages . 92
7.1 Header field . 93
7.1.1 Overview/formatting . 93
7.1.2 Tail identification, TA, bits a to a . 93
0 2
7.1.3 The "Q1/BCK" bit, bit a . 93
ETSI
5 ETSI EN 300 175-3 V2.3.1 (2010-06)
7.1.4 B-field identification, BA, bits a to a . 94
4 6
7.1.5 The "Q2" bit, bit a . 95
7.2 Messages in the tail field . 95
7.2.1 Overview . 95
7.2.2 Identities information (N ) . 95
T
7.2.3 System information and multiframe marker (Q ) . 96
T
7.2.3.1 General . 96
7.2.3.2 Static system information . 97
7.2.3.2.1 General, Q = 0, 1 (hex) . 97
H
7.2.3.2.2 Q and Normal-Reverse (NR) . 97
H
7.2.3.2.3 Slot Number (SN) . 97
7.2.3.2.4 Start Position (SP) . 98
7.2.3.2.5 ESCape bit (ESC) . 98
7.2.3.2.6 Number of transceivers . 98
7.2.3.2.7 Extended RF carrier information available (Mc) . 98
7.2.3.2.8 RF carriers available (RF-cars) . 99
7.2.3.2.9 Spare bits (SPR) . 99
7.2.3.2.10 Carrier number. 99
7.2.3.2.11 Spare bits (SPR) . 99
7.2.3.2.12 Primary receiver Scan Carrier Number (PSCN) . 100
7.2.3.3 Extended RF carrier information part 1 . 100
7.2.3.3.1 General, Q = 2 (hex) . 100
H
7.2.3.3.2 Further RF carrier extensions . 101
7.2.3.3.3 Number of RF carriers . 101
7.2.3.4 Fixed part capabilities . 101
7.2.3.4.1 General, Q = 3 (hex) . 101
H
7.2.3.4.2 Standard capabilities . 101
7.2.3.5 Extended fixed part capabilities . 102
7.2.3.5.1 General, Q = 4 (hex) . 102
H
7.2.3.5.2 Extended Physical and MAC layer capabilities . 103
7.2.3.5.3 Extended higher layer capabilities . 104
7.2.3.6 Secondary access rights identities . 104
7.2.3.6.1 General, Q = 5 (hex) . 104
H
7.2.3.6.2 SARI message . 104
7.2.3.7 Multiframe number . 104
7.2.3.7.1 General, Q = 6 (hex) . 104
H
7.2.3.7.2 Multiframe number . 104
7.2.3.8 Escape . 105
7.2.3.8.1 General, Q = 7 (hex) . 105
H
7.2.3.8.2 Escape information . 105
7.2.3.9 Extended RF carrier information part 2 . 105
7.2.3.9.1 General, Q = 9 (hex) . 105
H
7.2.3.10 Transmit information . 105
7.2.3.10.1 General, Q = B (hex) . 105
H
7.2.3.11 Extended fixed part capabilities (part 2) . 106
7.2.3.11.1 General, Q = C (hex) . 106
H
7.2.3.11.2 Extended Physical and MAC layer capabilities (part 2) . 106
7.2.3.11.3 Extended higher layer capabilities (part 2) . 107
7.2.4 Paging Tail (P ) . 107
T
7.2.4.1 General format . 107
7.2.4.1.1 P format for full and long page messages . 107
T
7.2.4.1.2 P format for short page messages . 108
T
7.2.4.1.3 P format for zero length page messages . 108
T
7.2.4.1.4 P format for MAC_Resume_and_Control_page message . 108
T
7.2.4.2 P header format . 109
T
7.2.4.2.1 General format . 109
7.2.4.2.2 Bit a is the extend flag . 109
7.2.4.2.3 B SDU length indication . 109
S
7.2.4.3 MAC layer information for PT. 110
7.2.4.3.1 Information type . 110
7.2.4.3.2 Fill bits / Blind long slot (j=640 / j=672) information . 110
7.2.4.3.3 Blind full slot information . 111
ETSI
6 ETSI EN 300 175-3 V2.3.1 (2010-06)
7.2.4.3.4 Bearer description . 111
7.2.4.3.5 Escape . 112
7.2.4.3.6 Dummy or connectionless downlink bearer marker . 112
7.2.4.3.7 Bearer handover/replacement information . 112
7.2.4.3.8 RFP status and modulation types . 113
7.2.4.3.9 Active carriers . 114
7.2.4.3.10 RFP power level . 114
7.2.4.3.11 Blind double slot/RFP-FP interface resource information . 115
7.2.4.3.12 Extended modulation types . 115
7.2.5 MAC control (M ) . 116
T
7.2.5.1 General format and contents . 116
7.2.5.2 Basic connection control . 116
7.2.5.2.1 General . 116
7.2.5.2.2 Format for most messages . 117
7.2.5.2.3 WAIT . 117
7.2.5.2.4 ATTRIBUTES_T_{Req;Cfm} . 117
7.2.5.3 Advanced connection control . 118
7.2.5.3.1 General . 118
7.2.5.3.2 ACCESS_REQUEST . 118
7.2.5.3.3 BEARER_HANDOVER_REQUEST . 118
7.2.5.3.4 CONNECTION_HANDOVER_REQUEST . 118
7.2.5.3.5 UNCONFIRMED_ACCESS_REQUEST . 119
7.2.5.3.6 BEARER_CONFIRM . 119
7.2.5.3.7 WAIT . 119
7.2.5.3.8 ATTRIBUTES_T_{Req;Cfm} . 119
7.2.5.3.9 BANDWIDTH_T_{Req;Cfm} . 122
7.2.5.3.10 Channel_list . 122
7.2.5.3.11 Unconfirmed_dummy . 123
7.2.5.3.12 Unconfirmed_handover . 123
7.2.5.3.13 RELEASE . 123
7.2.5.4 MAC layer test messages . 124
7.2.5.4.1 Basic format . 124
7.2.5.4.2 FORCE_TRANSMIT . 125
7.2.5.4.3 LOOPBACK_DATA . 125
7.2.5.4.4 DEFEAT_ANTENNA_DIVERSITY. 126
7.2.5.4.5 ESCAPE . 127
7.2.5.4.6 NETWORK_TEST . 127
7.2.5.4.7 CLEAR_TEST_MODES. 127
7.2.5.4.8 CHANGE_MODULATION_SCHEME . 127
7.2.5.5 Quality control . 128
7.2.5.5.1 Prolonged preamble diversity . 129
7.2.5.6 Broadcast and connectionless services . 130
7.2.5.7 Encryption control . 130
7.2.5.8 B-field setup, first PT transmission . 131
7.2.5.9 Escape . 132
7.2.5.10 TARI message . 132
7.2.5.11 REP connection control . 132
7.2.5.11.1 General . 132
7.2.5.11.2 Format for most messages . 132
7.2.5.11.3 REP CHANNEL MAP REQUEST . 133
7.2.5.11.4 REP CHANNEL MAP CONFIRM . 133
7.3 Messages in the B-field . 133
7.3.1 Overview . 133
7.3.2 Advanced connection control . 134
7.3.2.1 General format . 134
7.3.2.2 BEARER_REQUEST . 135
7.3.2.3 BEARER_CONFIRM . 135
7.3.2.4 WAIT . 136
7.3.2.5 ATTRIBUTES_B_{Req;Cfm} . 136
7.3.2.6 BANDWIDTH_B_{Req;Cfm} . 137
7.3.2.7 CHANNEL_LIST . 137
7.3.2.8 UNCONFIRMED_DUMMY . 137
ETSI
7 ETSI EN 300 175-3 V2.3.1 (2010-06)
7.3.2.9 UNCONFIRMED_HANDOVER . 138
7.3.2.10 RELEASE . 138
7.3.3 Null or I segmentation info . 139
PF
7.3.3.1 Spare or I segmentation info . 140
PF
7.3.3.2 Extended NCF bits . 141
7.3.4 Quality control . 141
7.3.4.1 General format . 141
7.3.4.2 Bearer and connection control. 141
7.3.4.3 RESET . 143
7.3.4.4 Bearer quality in an asymmetric connection . 143
7.3.5 Extended system information . 144
7.3.5.1 General format . 144
7.3.5.2 TARI messages . 144
7.3.5.3 "no-emission" mode sync information . 144
7.3.6 G channel data packet . 145
F
7.3.7 Escape . 145
8 Medium access layer primitives . 145
8.1 Connection oriented service primitives . 146
8.1.1 Connection setup: MAC_CON {req;ind;cfm} . 146
8.1.2 Connection modification: MAC_MOD {req;ind;cfm} . 147
8.1.3 CO data transmit ready: MAC_CO_DTR {ind} . 148
8.1.4 CO data transfer: MAC_CO_DATA {req;ind} . 149
8.1.5 Restart DLC: MAC_RES_DLC {ind} . 149
8.1.6 Connection release: MAC_DIS {req;ind} . 149
8.1.7 MAC bandwidth: MAC_BW {ind;res} . 150
8.1.8 Encryption. 150
8.1.8.1 Load encryption key: MAC_ENC_KEY {req} . 150
8.1.8.2 Enable/disable encryption: MAC_ENC_EKS {req;ind;cfm} . 150
8.1.9 C-plane switching procedure . 151
8.1.9.1 C-plane switching procedure: MAC_C _C {req, cfm, ind, res} . 151
S F
8.1.9.2 C-plane switching procedure: MAC_C C _END {ind} . 151
S F
8.2 Connectionless and broad
...
