SIST ES 202 740 V1.8.2:2022
(Main)Speech and multimedia Transmission Quality (STQ) - Transmission requirements for wideband VoIP loudspeaking and handsfree terminals from a QoS perspective as perceived by the user
Speech and multimedia Transmission Quality (STQ) - Transmission requirements for wideband VoIP loudspeaking and handsfree terminals from a QoS perspective as perceived by the user
The present document provides speech transmission performance requirements for 8 kHz wideband VoIP loudspeaking
and hands-free terminals; it addresses all types of IP based terminals, including wireless, softphones and group audio
terminals. DECT terminals are covered in ETSI EN 300 175-8 [i.6] and ETSI EN 300 176-2 [i.7].
In contrast to other standards which define minimum performance requirements it is the intention of the present
document to specify terminal equipment requirements which enable manufacturers and service providers to enable good
quality end-to-end speech performance as perceived by the user.
In addition to basic testing procedures, the present document describes advanced testing procedures taking into account
further quality parameters as perceived by the user.
NOTE: The present document does not concern headset terminals.
Kakovost prenosa govora in večpredstavnih vsebin (STQ) - Prenosne zahteve za širokopasovne zvočniške in prostoročne terminale VoIP glede na kakovost storitev (QoS), kot jo dojema uporabnik
V tem dokumentu so podane zahteve glede učinkovitosti prenosa govora za 8-kHz širokopasovne zvočniške in prostoročne terminale VoIP; obravnava vse vrste terminalov na podlagi naslova IP, vključno z brezžičnimi terminali, programskimi telefoni in terminali za skupinske zvočne klice. Terminali digitalnih izboljšanih brezvrvičnih telekomunikacij (DECT) so zajeti v dokumentih ETSI EN 300 175-8 [i.6] in ETSI EN 300 176-2 [i.7]. V nasprotju z drugimi standardi, ki opredeljujejo minimalne zahteve glede učinkovitosti, je namen tega dokumenta določiti zahteve za terminalsko opremo, ki proizvajalcem in ponudnikom storitev omogočajo, da zagotavljajo dobro kakovost govora od začetka do konca, kot jo dojema uporabnik. Poleg osnovnih preskusnih postopkov ta dokument opisuje napredne preskusne postopke, ki upoštevajo tudi druge parametre kakovosti, kot jih dojema uporabnik. OPOMBA: Ta dokument se ne navezuje na naglavne terminale.
