ASTM F2057-23

Standard Safety Specification for Clothing Storage Units

ABSTRACT
This safety specification is intended to reduce injuries and deaths of children from hazards associated with tipover of clothing storage units, it covers chests, drawer chests, chests of drawers, dressers, and bureaus only. The procedures for stability testing of the drawer are presented in details. During the test, the unit shall not tip over or be supported only by an opened drawer, opened door, or opened or unopened flap.
SCOPE
1.1 This safety specification is intended to reduce injuries and deaths of children from hazards associated with tipover of free-standing clothing storage units, including but not limited to chests, chests of drawers, drawer chests, armoires, chifferobes, bureaus, door chests, and dressers, which are 27 in. (686 mm) or greater in height, 30 lb (13.6 kg) or greater in mass, and contain 3.2 ft3 (90.6 dm3) or greater of enclosed storage volume.
1.2 This safety specification does not cover shelving units, such as bookcases or entertainment furniture, office furniture, dining room furniture, jewelry armoires, underbed drawer storage units, occasional/accent furniture not intended for bedroom use, laundry storage/sorting units, or built-in units intended to be permanently attached to the building, nor does it cover “Clothing Storage Chests” as defined in Consumer Safety Specification F2598.
1.3 This safety specification is intended to cover children up to 72 months. See Note 1.
Note 1: The majority (approximately 80 %) of deaths relate to children 5 years or younger.
1.4 The values stated in inch-pound units are to be regarded as standard. The values given in parentheses are mathematical conversions to SI units that are provided for information only and are not considered standard.
1.5 The following safety hazards caveat pertains only to the test procedure portion, Section 9, of this safety specification:  This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of regulatory limitations prior to use.
1.6 This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.

General Information

• Status: Published
• Publication Date: 31-Jan-2023
• ICS: 97.140 - Furniture
• ICS: 97.190 - Equipment for children
• Technical Committee: F15 - Consumer Products
• Drafting Committee: F15.42 - Furniture Safety

Relations

• Refers: ASTM D3359-09e1 - Standard Test Methods for Measuring Adhesion by Tape Test
• Effective Date: 01-Jun-2009
• Refers: ASTM F2598-09 - Standard Consumer Safety Specification for Clothing Storage Chests
• Effective Date: 15-Feb-2009
• Refers: ASTM D3359-07 - Standard Test Methods for Measuring Adhesion by Tape Test
• Effective Date: 01-Nov-2007
• Refers: ASTM D3359-02 - Standard Test Methods for Measuring Adhesion by Tape Test
• Effective Date: 10-Aug-2002

Overview

ASTM F2057-23: Standard Safety Specification for Clothing Storage Units provides essential safety requirements to help reduce injuries and fatalities among children resulting from tipover incidents involving free-standing clothing storage units. Developed by ASTM International, this standard targets hazards associated specifically with chests, dressers, bureaus, armoires, and similar units 27 inches or greater in height, 30 pounds or more in weight, and with a minimum enclosed storage volume of 3.2 cubic feet. The specification outlines detailed stability testing procedures, marking and labeling requirements, and the use of anti-tip devices for both manufacturers and consumers in compliance and safety assurance.

Key Topics

• Scope and Coverage
  • Applies to free-standing clothing storage units such as dressers, chests of drawers, bureaus, armoires, and more meeting specific size and weight criteria.
  • Does not cover shelving units, office furniture, built-in units, jewelry chests, or units covered by other applicable standards.
  • Intended to safeguard children up to 72 months (6 years), as the majority of tipover fatalities involve children aged 5 or younger.
• Stability Testing
  • Units must be able to withstand specific simulated forces without tipping over, with tests performed on units placed on hard, level surfaces.
  • Testing simulates common real-world situations such as carpet placement, loaded drawers, and dynamic forces (children pulling or climbing).
  • Includes testing of interlock mechanisms, when present, to prevent multiple drawers from opening simultaneously and reducing tipover risk.
• Anti-Tip and Restraint Requirements
  • Every unit within scope must be sold with a compliant anti-tip device and instructions for proper installation and use.
  • Tipover restraints must meet the requirements of ASTM F3096.
• Marking and Labeling
  • Safety warnings and instructions are required in conspicuous locations on the unit, formatted according to ANSI Z535.4 and ISO 3864-1/2 standards.
  • Permanent warnings must detail risks, installation mandates, and instructions on safe usage (e.g., only open one drawer at a time, never allow children to climb).
  • Products must clearly indicate that the label is permanent and should not be removed.

Applications

ASTM F2057-23 is invaluable for a range of stakeholders in the furniture industry and consumer safety landscape:

• Manufacturers use this standard to design, test, and label compliant clothing storage units, ensuring products are less likely to tip over and injure children.
• Retailers rely on certified products to enhance consumer trust and demonstrate social responsibility in offering safe home furnishings.
• Testing Laboratories follow the detailed test methodologies to evaluate and certify products for compliance with tipover prevention requirements.
• Regulatory Agencies reference ASTM F2057-23 for enforcement and educational campaigns aimed at minimizing furniture tipover hazards in homes.
• Consumers benefit from clear instructions and permanent safety labels, promoting the correct use of tip restraints and safe furniture practices in households with children.

Related Standards

• ASTM F3096: Specification for Tipover Restraints Used with Clothing Storage Units
• ASTM F2598: Consumer Safety Specification for Sealed Storage Chests
• ANSI Z535.4: Specification for Product Safety Signs and Labels
• ISO 3864-1/2: Standards for Graphical Symbols and Product Safety Labels

By adopting ASTM F2057-23, organizations and consumers can mitigate the risk of tipovers, ensure regulatory compliance, and promote safer environments for families and children. For more detailed information and updates, always consult the latest approved edition from ASTM International.

Keywords: Clothing storage unit safety, tipover prevention, furniture standard, ASTM F2057-23, anti-tip device, dresser safety, child injury prevention, labeling requirements, furniture tipover, consumer product safety.

Standards Content (Sample)

This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the
Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
Designation: F2057 − 23
Standard Safety Specification for
1,2
Clothing Storage Units
This standard is issued under the fixed designation F2057; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
INTRODUCTION
This consumer safety specification is intended to address incidents reported by the U.S. Consumer
Product Safety Commission (CPSC) relating to clothing storage units. In response to the incident data
compiled by the CPSC, this consumer safety specification attempts to minimize the hazards associated
with these products. Test methods in this safety specification are intended to simulate the reaction of
a clothing storage unit on carpet, loaded drawers, multiple open drawers, and a dynamic force from
possible interaction of a child up to 72 months.
This consumer safety specification does not apply to products that are blatantly misused, nor does
it apply to products used by consumers in a careless manner that violate normal practice or disregard
the instructions or warnings provided with the product, or both.
1. Scope 1.4 The values stated in inch-pound units are to be regarded
as standard. The values given in parentheses are mathematical
1.1 This safety specification is intended to reduce injuries
conversions to SI units that are provided for information only
and deaths of children from hazards associated with tipover of
and are not considered standard.
free-standing clothing storage units, including but not limited
1.5 The following safety hazards caveat pertains only to the
to chests, chests of drawers, drawer chests, armoires,
test procedure portion, Section 9, of this safety specification:
chifferobes, bureaus, door chests, and dressers, which are 27 in.
This standard does not purport to address all of the safety
(686 mm) or greater in height, 30 lb (13.6 kg) or greater in
3 3
concerns, if any, associated with its use. It is the responsibility
mass, and contain 3.2 ft (90.6 dm ) or greater of enclosed
of the user of this standard to establish appropriate safety,
storage volume.
health, and environmental practices and determine the appli-
1.2 This safety specification does not cover shelving units,
cability of regulatory limitations prior to use.
such as bookcases or entertainment furniture, office furniture,
1.6 This international standard was developed in accor-
dining room furniture, jewelry armoires, underbed drawer
dance with internationally recognized principles on standard-
storage units, occasional/accent furniture not intended for
ization established in the Decision on Principles for the
bedroom use, laundry storage/sorting units, or built-in units
Development of International Standards, Guides and Recom-
intended to be permanently attached to the building, nor does
mendations issued by the World Trade Organization Technical
it cover “Clothing Storage Chests” as defined in Consumer
Barriers to Trade (TBT) Committee.
Safety Specification F2598.
1.3 This safety specification is intended to cover children up
2. Referenced Documents
to 72 months. See Note 1.
2.1 ASTM Standards:
NOTE 1—The majority (approximately 80 %) of deaths relate to
D3359 Test Methods for Rating Adhesion by Tape Test
children 5 years or younger.
F2598 Consumer Safety Specification for Sealed Storage
Chests such as Cedar Chests, Hope Chests, Blanket
Chests, Keepsake Chests
This safety specification is under the jurisdiction of ASTM Committee F15 on
Consumer Products and is the direct responsibility of Subcommittee F15.42 on
Furniture Safety.
Current edition approved Feb. 1, 2023. Published February 2023. Originally For referenced ASTM standards, visit the ASTM website, www.astm.org, or
approved in 2000. Last previous edition approved in 2019 as F2057 – 19. DOI: contact ASTM Customer Service at [e-mail]. For Annual Book of ASTM
10.1520/F2057-23. Standards volume information, refer to the standard’s Document Summary page on
This safety specification replaces PS 110 – 98. the ASTM website.
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
