EN 17412-1:2020
(Main)Building Information Modelling - Level of Information Need - Part 1: Concepts and principles
Building Information Modelling - Level of Information Need - Part 1: Concepts and principles
This document specifies concepts and principles to establish a methodology for specifying level of information need and information deliveries in a consistent way when using building information modelling (BIM).
This document specifies the characteristics of different levels used for defining the detail and extent of information required to be exchanged and delivered throughout the life cycle of built assets. It gives guidelines for principles required to specify information needs.
The concepts and principles in this document can be applied for a general information exchange and whilst in progress, for a generally agreed way of information exchange between parties in a collaborative work process, as well as for an appointment with specified information delivery.
The level of information need provides methods for describing information to be exchanged according to exchange information requirements. The exchange information requirements specify the wanted information exchange. The result of this process is an information delivery.
This document is applicable to the whole life cycle of any built asset, including strategic planning, initial design, engineering, development, documentation and construction, day-to-day operation, maintenance, refurbishment, repair and end-of-life.
Bauwerksinformationsmodellierung - Informationsbedarfstiefe - Teil 1: Konzepte und Grundsätze
Dieses Dokument legt Konzepte und Grundsätze fest, um eine Methodik für die Festlegung der Informationsbedarfstiefe und von Informationsbereitstellungen für die Anwendung von Building Information Modeling (BIM) in einer konsistenten Weise aufzustellen.
Dieses Dokument legt die Ausprägung verschiedener Stufen fest, die bei der Definition der Detaillierung und des Umfangs von Informationen angewendet werden, die über den gesamten Lebenszyklus von Bauwerken ausgetauscht und geliefert werden müssen. Es gibt Leitlinien für Grundsätze, die für die Festlegung des Informationsbedarfs erforderlich sind.
Die Konzepte und Grundsätze in diesem Dokument können für den allgemeinen Informationsaustausch angewendet werden und sorgen für eine im Allgemeinen vereinbarte Weise des Informationsaustauschs zwischen den Parteien in einem kollaborativen Arbeitsprozess sowie für eine vertraglich festgelegte Informationsbereitstellung.
Die Informationsbedarfstiefe bietet Methoden, um die auszutauschenden Informationen in Übereinstimmung mit den Austausch-Informationsanforderungen zu beschreiben. Die Austausch-Informationsanforderungen legen den gewünschten Informationsaustausch fest. Das Ergebnis dieses Prozesses ist eine Informationsbereitstellung.
Dieses Dokument gilt während des gesamten Lebenszyklus eines Gebäudes, einschließlich der strategischen Planung, des Erstentwurfs, der Ingenieurtechnik, der Entwicklung, der Dokumentation und der Konstruktion, des Betriebs im Alltag, der Instandhaltung, der Modernisierung, der Instandsetzung und des Lebensdauerendes.
Modélisation des informations de la construction - Niveau du besoin d’information - Partie 1 : Concepts et principes
Le présent document spécifie les concepts et les principes permettant d’établir une méthodologie de spécification cohérente du niveau du besoin d’information et des livraisons d’information à l’aide de la modélisation des informations de la construction (BIM).
Le présent document spécifie les caractéristiques des différents niveaux utilisés pour définir le détail et l’étendue des informations qu’il est nécessaire d’échanger et de livrer tout au long du cycle de vie des actifs bâtis. Il donne des lignes directrices sur les principes requis pour spécifier les besoins d’information.
Les concepts et les principes énoncés dans le présent document peuvent s’appliquer à un échange général d’informations et, dans le même temps, à un mode communément accepté d’échange d’informations entre des parties dans le cadre d’un processus de travail collaboratif, ainsi qu’à une désignation accompagnée d’une livraison d’informations spécifiée.
Le niveau du besoin d’information fournit des méthodes pour décrire les informations à échanger conformément aux exigences d’échange d’informations. Les exigences d’échange d’informations spécifient l’échange d’informations souhaité. Le résultat de ce processus est une livraison d’informations.
Le présent document s’applique à la totalité du cycle de vie d’un actif bâti, y compris la planification stratégique, la conception initiale, l’ingénierie, le développement, la documentation et la construction, l’exploitation quotidienne, la maintenance, la réhabilitation, la réparation et la fin de vie.
Informacijsko modeliranje gradenj - Raven informacijskih potreb - 1. del: Pojmi in načela
General Information
Relations
Standards Content (Sample)
SLOVENSKI STANDARD
01-februar-2021
Informacijsko modeliranje gradenj - Raven informacijskih potreb - 1. del: Pojmi in
načela
Building Information Modelling - Level of Information Need - Part 1: Concepts and
principles
Modélisation des Informations pour la Construction (BIM) - Niveau d’Information Requis -
Concepts et Principes
Ta slovenski standard je istoveten z: EN 17412-1:2020
ICS:
35.240.67 Uporabniške rešitve IT v IT applications in building
gradbeništvu and construction industry
91.010.01 Gradbeništvo na splošno Construction industry in
general
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
EN 17412-1
EUROPEAN STANDARD
NORME EUROPÉENNE
November 2020
EUROPÄISCHE NORM
ICS 35.240.67
English Version
Building Information Modelling - Level of Information
Need - Part 1: Concepts and principles
Modélisation des informations de la construction - Building Information Modelling -
Niveau du besoin d'information - Partie 1 : Concepts et Informationsbedarfstiefe - Konzepte und Definitionen
principes
This European Standard was approved by CEN on 18 October 2020.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this
European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references
concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN
member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by
translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management
Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia,
Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway,
Poland, Portugal, Republic of North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and
United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION
EUROPÄISCHES KOMITEE FÜR NORMUNG
CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels
© 2020 CEN All rights of exploitation in any form and by any means reserved Ref. No. EN 17412-1:2020 E
worldwide for CEN national Members.
Contents Page
European foreword . 3
Introduction . 4
1 Scope . 5
2 Normative references . 5
3 Terms and definitions . 5
4 General. 8
5 Framework to specify the level of information need . 8
5.1 General. 8
5.2 Consider the purposes . 8
5.3 Consider the information delivery milestones . 9
5.4 Consider the actors . 9
5.5 Consider the objects within a breakdown structure. 9
6 Definition of level of information need and its subdivision . 10
6.1 General. 10
6.2 Geometrical information . 11
6.2.1 General. 11
6.2.2 Detail . 11
6.2.3 Dimensionality . 13
6.2.4 Location . 14
6.2.5 Appearance . 14
6.2.6 Parametric behaviour . 15
6.2.7 Relationships of aspects of geometrical information and prerequisites . 16
6.3 Alphanumerical information . 16
6.3.1 General. 16
6.3.2 Identification . 17
6.3.3 Information content . 17
6.4 Documentation . 17
6.5 Relationship diagram on level of information need . 18
7 Verification and validation . 19
Annex A (informative) Overview of the main concepts related to information exchange . 20
Annex B (informative) Example of method to specify level of information need . 21
Bibliography . 25
European foreword
This document (EN 17412-1:2020) has been prepared by Technical Committee CEN/TC 442 “Building
Information Modelling (BIM)”, the secretariat of which is held by SN.
This European Standard shall be given the status of a national standard, either by publication of an
identical text or by endorsement, at the latest by May 2021, and conflicting national standards shall be
withdrawn at the latest by May 2021.
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. CEN shall not be held responsible for identifying any or all such patent rights.
According to the CEN-CENELEC Internal Regulations, the national standards organisations of the
following countries are bound to implement this European Standard: Austria, Belgium, Bulgaria,
Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland,
Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Republic of
North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and the
United Kingdom.
Introduction
This document sets out the concepts and principles for defining the level of information need and
information deliveries being part of the information exchange processes during the life cycle of built
assets when using building information modelling (BIM). Those concepts and principles can deliver
clear benefits to all participants in the various life cycle phases of built assets as they provide a common
understanding on the right level of information needed at a certain time. One purpose of defining the
level of information need is to prevent delivery of too much information. Information exchange should
ensure the right information to be delivered for the agreed purpose to facilitate verification and
validation processes.
This document provides methods for describing information to be exchanged according to exchange
information requirements. The exchange information requirements specify the wanted information
exchange. The result of this process is an information delivery.
There is a need that these concepts and principles are described in a common and comparable way to
allow services related to building information modelling to be procured and offered on a European
scale. The need has arisen by the fact that there are several conflicting terms, concepts and usages in
place, both internationally and across Europe, that hinder the objective of having a common
understanding and practise in describing the level of information need for a common European market.
It is therefore helpful not to use an acronym to refer to level of information need as this can
oversimplify these concepts.
The concepts and principles contained in this document are aimed at all those involved in the asset life
cycle. This includes, but is not limited to, the asset owner/operator, the client, the asset manager, the
design team, the construction team, an equipment manufacturer, a technical specialist, a regulatory
authority, an investor, an insurer and an end-user.
The information exchange, as well as related topics such as the exchange information requirements and
the information delivery are defined and explained in context of two related standards:
EN ISO 19650-1, Organization and digitization of information about buildings and civil engineering
works, including building information modelling (BIM) — Information management using building
information modelling — Part 1: Concepts and principles; and
EN ISO 29481-1, Building information models — Information delivery manual — Part 1: Methodology and
format.
1 Scope
This document specifies concepts and principles to establish a methodology for specifying level of
information need and information deliveries in a consistent way when using building information
modelling (BIM).
This document specifies the characteristics of different levels used for defining the detail and extent of
information required to be exchanged and delivered throughout the life cycle of built assets. It gives
guidelines for principles required to specify information needs.
The concepts and principles in this document can be applied for a general information exchange and
whilst in progress, for a generally agreed way of information exchange between parties in a
collaborative work process, as well as for an appointment with specified information delivery.
The level of information need provides methods for describing information to be exchanged according
to exchange information requirements. The exchange information requirements specify the wanted
information exchange. The result of this process is an information delivery.
This document is applicable to the whole life cycle of any built asset, including strategic planning, initial
design, engineering, development, documentation and construction, day-to-day operation, maintenance,
refurbishment, repair and end-of-life.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
EN ISO 29481-1:2017, Building information models —Information delivery manual — Part 1:
Methodology and format (ISO 29481-1:2016)
ISO 6707-1, Buildings and civil engineering works — Vocabulary — Part 1: General terms
3 Terms and definitions
For the purposes of this document, the terms and definitions given in EN ISO 29481-1:2017, ISO 6707-1
and the following apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— IEC Electropedia: available at http://www.electropedia.org/
— ISO Online browsing platform: available at https://www.iso.org/obp
3.1
information container
named persistent set of information (3.11) retrievable from within a file, system or application storage
hierarchy
EXAMPLE Including sub-directory, information file (including model, document, table, schedule), or distinct
sub-set of an information file such as a chapter or section, layer or symbol.
Note 1 to entry: Persistent information exists over a timescale long enough for it to have to be managed, i.e. this
excludes transient information such as internet search results.
Note 2 to entry: Naming of an information contai
...
