EN 13322-1
EUROPEAN STANDARD
NORME EUROPÉENNE
May 2024
EUROPÄISCHE NORM
ICS 23.020.35 Supersedes EN 13322-1:2003,
EN 13322-1:2003/A1:2006
English Version
Transportable gas cylinders - Refillable welded steel gas
cylinders - Design and construction - Part 1: Carbon steel
Bouteilles à gaz transportables - Bouteilles à gaz Ortsbewegliche Gasflaschen - Wiederbefüllbare
rechargeables soudées en acier - Conception et geschweißte Flaschen aus Stahl - Auslegung und
construction - Partie 1 : Acier au carbone Herstellung - Teil 1: Flaschen aus Kohlenstoffstahl
This European Standard was approved by CEN on 5 May 2024.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this
European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references
concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN
member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by
translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management
Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia,
Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway,
Poland, Portugal, Republic of North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Türkiye and
United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATIO N
E U R OP ÄI S C H ES KOMITEE FÜR NORMUN G
CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels
© 2024 CEN All rights of exploitation in any form and by any means reserved Ref. No. EN 13322-1:2024 E
worldwide for CEN national Members.
Contents Page
European foreword . 3
Introduction . 5
1 Scope . 6
2 Normative references . 6
3 Terms and definitions . 7
4 Materials and heat treatment . 10
5 Design . 10
6 Construction and workmanship . 14
7 New design tests . 17
8 Batch tests . 20
9 Tests on every cylinder . 27
10 Failure to meet test requirements . 27
11 Records . 28
12 Marking . 28
Annex A (normative) Cylinder shells for acetylene service made from longitudinal seam high
frequency induction (HFI) welded tube by spinning of the end . 29
Annex B (normative) Radiographic examination of welds . 31
Annex C (normative) Description, evaluation of manufacturing defects and conditions for
rejection of welded steel gas cylinders at time of visual inspection . 34
Annex D (informative) Examples of design and batch test certificates . 37
Bibliography . 44
European foreword
This document (EN 13322-1:2024) has been prepared by Technical Committee CEN/TC 23
“Transportable gas cylinders”, the secretariat of which is held by BSI.
This European Standard shall be given the status of a national standard, either by publication of an
identical text or by endorsement, at the latest by November 2024, and conflicting national standards
shall be withdrawn at the latest by November 2024.
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. CEN shall not be held responsible for identifying any or all such patent rights.
This document supersedes EN 13322-1:2003 and EN 13322-1:2003/A1:2006.
In comparison with the previous edition, the following technical modifications have been made:
— updating of the normative references;
— removal of the limit of a minimal water capacity of 0,5 l;
— addition of a new Clause 8.4.4 “Requirements for ductility testing of small cylinders”;
— modification of term 3.1 from yield stress to yield strength;
— update according to the latest requirements on standards to be proposed for ADR;
— clarification of the verbal forms for expression of provisions;
— removal of Annex E.
This document has been submitted for reference in:
— the RID [5] and
— the technical annexes of the ADR [4].
NOTE Attention is drawn to possible national/international legislation in relation to this document. It is
emphasized that the the RID/ADR are being revised regularly at intervals of two years.
This document is one of a series of two standards concerning refillable welded steel gas cylinders of
water capacities up to and including 150 l for compressed, liquefied and dissolved gases:
— Part 1: Carbon steel
— Part 2: Stainless steel
Annexes A, B and C are normative. Annex D is informative.
Any feedback and questions on this document should be directed to the users’ national standards body.
A complete listing of these bodies can be found on the CEN website.
According to the CEN-CENELEC Internal Regulations, the national standards organisations of the
following countries are bound to implement this European Standard: Austria, Belgium, Bulgaria,
Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland,
Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Republic of
North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Türkiye and the
United Kingdom.
Introduction
The purpose of this document is to provide a specification for the design, manufacture, and testing of
refillable, transportable, welded steel gas cylinders.
The specifications given are based on knowledge of, and experience with, materials, design
requirements, manufacturing processes and control during manufacture, of cylinders in common use in
the countries of the CEN members.
This document is based on the traditional calculation method. It does not cover other methods such as
finite element analysis (F.E.A) methods or experimental methods.
1 Scope
This document specifies minimum requirements concerning material, design, construction and
workmanship, manufacturing processes and testing of refillable transportable welded carbon steel gas
cylinders of water capacities up to and including 150 l for compressed, liquefied and dissolved gases.
For acetylene service, additional requirements for the cylinder and basic requirements for the porous
material are given in EN ISO 3807. For cylinder shells for acetylene service manufactured from high
frequency induction (HFI) welded steel tubes by spinning of the end, the requirements are given in
Annex A.
This document is primarily applicable to industrial gases other than LPG but can also be applied for LPG.
However for dedicated LPG cylinders, see EN 1442.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
EN 10028-1, Flat products made of steels for pressure purposes - Part 1: General requirements
EN 10028-3, Flat products made of steels for pressure purposes - Part 3: Weldable fine grain steels,
normalized
EN 10028-5, Flat products made of steels for pressure purposes - Part 5: Weldable fine grain steels,
thermomechanically rolled
EN 10120, Steel sheet and strip for welded gas cylinders
EN 13445-2, Unfired pressure vessels - Part 2: Materials
EN ISO 148-1, Metallic materials - Charpy pendulum impact test - Part 1: Test method (ISO 148-1)
EN ISO 683-1, Heat-treatable steels, alloy steels and free-cutting steels - Part 1: Non-alloy steels for
quenching and tempering (ISO 683-1)
EN ISO 683-2, Heat-treatable steels, alloy steels and free-cutting steels - Part 2: Alloy steels for quenching
and tempering (ISO 683-2)
EN ISO 3183, Petroleum and natural gas industries - Steel pipe for pipeline transportation systems
(ISO 3183)
EN ISO 5173, Destructive tests on welds in metallic materials - Bend tests
EN ISO 5817, Welding - Fusion-welded joints in steel, nickel, titanium and their alloys (beam welding
excluded) - Quality levels for imperfections (ISO 5817)
EN ISO 6892-1, Metallic materials - Tensile testing - Part 1: Method of test at room temperature
(ISO 6892-1)
EN ISO 6892-2, Metallic materials - Tensile testing - Part 2: Method of test at elevated temperature
(ISO 6892-2)
EN ISO 9606-1, Qualification testing of welders - Fusion welding - Part 1: Steels (ISO 9606-1)
EN ISO 9712, Non-destructive testing - Qualification and certification of NDT personnel (ISO 9712)
EN ISO 9809-3:2019, Gas cylinders - Design, construction and testing of refillable seamless steel gas
cylinders and tubes - Part 3: Normalized steel cylinders and tubes (ISO 9809-3:2019)
EN ISO 10675-1, Non-destructive testing of welds - Acceptance levels for radiographic testing - Part 1:
Steel, nickel, titanium and their alloys (ISO 10675-1)
EN ISO 11114-1, Gas cylinders - Compatibility of cylinder and valve materials with gas contents - Part 1:
Metallic materials (ISO 11114-1)
EN ISO 11117:2019, Gas cylinders - Valve protection caps and guards - Design, construction and tests
(ISO 11117:2019)
EN ISO 13769, Gas cylinders - Stamp marking (ISO 13769)
EN ISO 15607, Specification and qualification of welding procedures for metallic materials - General rules
(ISO 15607)
EN ISO 15609-1, Specification and qualification of welding procedures for metallic materials - Welding
procedure specification - Part 1: Arc welding (ISO 15609-1)
EN ISO 15614-1, Specification and qualification of welding procedures for metallic materials - Welding
procedure test - Part 1: Arc and gas welding of steels and arc welding of nickel and nickel alloys
(ISO 15614-1)
EN ISO 17636-1:2022, Non-destructive testing of welds - Radiographic testing - Part 1: X- and gamma-ray
techniques with film (ISO 17636-1:2022)
EN ISO 17636-2:2022, Non-destructive testing of welds - Radiographic testing - Part 2: X- and gamma-ray
techniques with digital detectors (ISO 17636-2:2022)
EN ISO 17637, Non-destructive testing of welds - Visual testing of fusion-welded joints (ISO 17637)
3 Terms, definitions and symbols
For the purposes of this document, the terms and definitions given in EN ISO 10286 and the following
apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
• IEC Electropedia: available at https://www.electropedia.org/
• ISO Online browsing platform: available at https://www.iso.org/obp
3.1 Terms and definitions
3.1.1
yield strength
stress corresponding to the point reached during the test at which plastic deformation occurs without
any increase in the force, in case the metallic material exhibits a yield phenomenon
3.1.2
normalizing
heat treatment in which a cylinder is heated to a uniform temperature above the upper crit
...
