This Technical Specification specifies Electronic Citizen Card (ECC) requirements.
The requirements described in this Technical Specification are used to:
1) define a plastic body card with associated physical and logical securities;
2) specify the electrical interface and data transport protocols for the ECC;
3) support the basic set of identification and authentication elements visible at the card surface;
4) provide guidance for the specification of the ECC Durability.
In addition to the above requirements, Informative Annex A in this document recommends different Physical Layouts for the ECC for two scenarios:
- when the ECC is issued to act as a travelling document;
- when the ECC is not issued to act as a travelling document.
