EN IEC 61169-1-3:2026
(Main)Radio-frequency connectors - Part 1-3: Electrical test methods - Surge withstand - Surge protective devices built in a coaxial connector - Performance requirements and testing methods
- Abstract
IEC 61169-1-3:2026 is applicable to built-in devices (hereinafter referred to as "SPD" - surge protective device) or surge protection of telecommunications and signalling networks against indirect and direct effects of lightning or other transient over voltages. An SPD is intended to protect the electrical apparatus from transient over voltages and to divert surge currents. The SPD built in the coaxial connector can be a gas discharge tube type, a ¼ wavelength short stub type, a flash-off gap type, and a hybrid type thereof. The purpose of these built-in SPD is to protect modern electronic equipment connected to telecommunications and signalling networks with nominal system voltages up to 1 000 V (RMS) AC and 1 500 V DC.
- Status
- Published
- Publication Date
- 02-Jul-2026
- Technical Committee
- CLC/SR 46F - RF and microwave passive components
- Current Stage
- 6060 - Document made available - Publishing
- Start Date
- 03-Jul-2026
- Due Date
- 31-Jul-2025
- Completion Date
- 03-Jul-2026
EN IEC 61169-1-3:2026 is the CENELEC European Standard for radio-frequency connectors with built-in surge protective devices (SPD). It specifies electrical test methods, performance requirements and testing methods for coaxial-connector SPDs used on telecommunications and signalling networks to protect equipment from lightning-related and other transient overvoltages. It is written for manufacturers, test laboratories, and anyone specifying or verifying these connectors in practice.
What does EN IEC 61169-1-3:2026 specify?
EN IEC 61169-1-3:2026 applies to built-in SPD in coaxial connectors for surge protection of telecommunications and signalling networks. The document covers devices intended to protect electrical apparatus from transient overvoltages and divert surge currents, including gas discharge tube, ¼ wavelength short stub, flash-off gap, and hybrid types.
The scope places these built-in SPD in modern electronic equipment connected to networks with nominal system voltages up to 1 000 V AC and 1 500 V DC. In practice, that tells the reader which protection devices and network voltages are in scope for design, test and specification.
The document is organized into Clauses 1 to 7, followed by Annexes A, B and C for example measurement setups and Annex ZA for European normative references.
| Annex | What it covers |
|---|---|
| Annex A | Example equipment and layouts for DC sparkover voltage testing |
| Annex B | Example equipment and layouts for impulse sparkover voltage testing |
| Annex C | Example equipment and layouts for impulse durability testing |
What are the key requirements of EN IEC 61169-1-3:2026?
EN IEC 61169-1-3:2026 sets minimum electrical and test requirements for SPD built into coaxial connectors, and it links those requirements to specific test methods. The practical focus is on how the connector behaves before surge testing, during surge testing, and after surge testing.
Service and test conditions
Clause 4 defines the service environment and how tests are to be carried out. The standard distinguishes normal and abnormal service conditions, and it asks the manufacturer to consider abnormal conditions where they matter to the design or application.
For testing, Clause 4 allows a temperature of 23 °C ± 2 °C with controlled humidity only when the device technology is known to be insensitive to temperature for the characteristic under test. Otherwise, testing is done at the extreme temperatures relevant to the intended application, with gradual heating or cooling and enough time for thermal equilibrium. In practice, this means the test lab must choose the right climate condition for the device technology, not just a convenient room condition.
Clause 4 also says the SPD shall be tested with the same connections or terminations used in field installation. If a base or connector is part of the intended use, it is part of the test setup too. That matters because the result has to reflect real installation performance, not just the bare device.
Electrical performance before and after surge testing
Clause 5 treats all electrical requirements as minimum requirements, while allowing users to specify different values where needed. The initial sparkover voltage between connector terminals must meet the limits referenced from IEC 61643-311, and the specified return loss, insertion loss and insulation resistance are taken from the detail specification.
Clause 5 also requires impulse durability testing with a specified surge peak current applied a specified number of times. After that loading, the current-limiting element must still meet the detail specification. In practice, this checks that the SPD still performs its protective function after repeated surge stress.
After the impulse durability test, Clause 5 requires discharge inception voltage, return loss (VSWR), insertion loss and insulation resistance to remain within the ranges set for the connector. This is the key pass-fail point for users who need both surge protection and continued RF performance.
Test and measurement methods
Clause 6 gives the test methods for DC sparkover voltage, impulse sparkover voltage, impulse durability, return loss (VSWR), insertion loss and insulation resistance. For the sparkover tests, the GDT specimen is left in a dark place for at least 15 min before voltage is applied and the discharge inception voltage is measured using the circuits shown in the standard.
Clause 6 requires the impulse durability test to use the Figure 5 circuit arrangement, with further details referenced to IEC 61643-21:2025. It also states that return loss (VSWR) shall follow IEC 61169-1:2013, insertion loss shall follow IEC 61169-1-2, and insulation resistance shall follow IEC 61169-1:2013.
The measurement equipment must be suitable for the method used, and oscilloscopes must comply with IEC 61083-1. For users, this means the results depend not only on the specimen but also on the correctness of the test instrumentation and setup.
What has to be stated in the detail specification
Clause 7 requires the relevant specification to state the measurement range of sparkover voltage and the impulse durability levels. It also has to state any test fixture requirement and any difference from the test methods in this document.
That clause is important for procurement and quality control because it is where product-specific values, fixtures and deviations are fixed. Without those details, different suppliers could be testing to different assumptions.
What terms does EN IEC 61169-1-3:2026 define?
- Surge protective device (SPD) - A device that limits voltage at a designated port so the protected circuit sees less surge-induced overvoltage.
- Gas discharge tube (GDT) - A voltage-switching protective element used in some coaxial SPD designs.
- ¼ wavelength short stub - A coaxial protection design that uses a short stub of specific length to provide surge protection.
- Return loss (VSWR) - The RF matching performance metric used here to show how much signal is reflected by the connector assembly.
- Insertion loss - The loss introduced by the connector path, which matters for signal attenuation in the protected line.
- Insulation resistance - The resistance between relevant terminals, used to confirm electrical isolation after manufacture and after surge stress.
- Impulse durability - The ability of the SPD to withstand a specified number of surge current impulses of specified waveform.
Who uses EN IEC 61169-1-3:2026?
EN IEC 61169-1-3:2026 is used by manufacturers of radio-frequency connectors with built-in SPD, especially coaxial connector assemblies for telecommunications and signalling networks. Test laboratories use it to set up DC sparkover, impulse sparkover and impulse durability testing in a repeatable way.
It is also relevant to design engineers, quality managers and buyers who need to define the required surge protection level, the RF performance limits, and the test fixture to be used. In practice, it supports product specification, incoming verification, type testing and supplier comparison for surge-protected coaxial connectors.
Which standards are used with EN IEC 61169-1-3:2026?
| Standard | How it contributes |
|---|---|
| IEC 61083-1 | Gives requirements for instruments and software used in impulse test measurements |
| IEC 61169-1:2013 | Provides the generic radio-frequency connector requirements and measuring methods, including return loss and insulation resistance references |
| IEC 61169-1-2 | Provides the insertion loss test method used by this part |
| IEC 61643-311:2013 | Gives sparkover voltage performance requirements and test circuits for gas discharge tubes |
| IEC 61643-21:2025 | Is referenced for further details on impulse durability testing |
| IEC 61643-12 | Appears in the bibliography as a related surge protective device application standard |
| IEC 62305-4 | Appears in the bibliography as a related lightning protection standard |
What does the EN IEC 61169-1-3:2026 document contain?
EN IEC 61169-1-3:2026 contains the service conditions, electrical requirements, and test and measurement procedures for built-in SPD in coaxial connectors. It also includes the specification items that the relevant product document must state, so the standard can be applied to a particular connector design.
The figures show example connector types and the test circuits for DC sparkover voltage, impulse sparkover voltage, and impulse durability. Annexes A, B and C provide example equipment, layouts and result views for the three main test families, which helps laboratories build the test setup and understand what to record.
Relations
- Effective Date
- 02-Jun-2026
- Effective Date
- 02-Jun-2026
- Effective Date
- 02-Jun-2026
Get Certified
Connect with accredited certification bodies for this standard
ANCE
Mexican certification and testing association.
Intertek Slovenia
Intertek testing, inspection, and certification services in Slovenia.
LNE (Laboratoire National de Métrologie et d'Essais)
French national laboratory for metrology and testing.
Sponsored listings
Frequently Asked Questions
EN IEC 61169-1-3:2026 is a standard published by CLC. Its full title is "Radio-frequency connectors - Part 1-3: Electrical test methods - Surge withstand - Surge protective devices built in a coaxial connector - Performance requirements and testing methods". This standard covers: IEC 61169-1-3:2026 is applicable to built-in devices (hereinafter referred to as "SPD" - surge protective device) or surge protection of telecommunications and signalling networks against indirect and direct effects of lightning or other transient over voltages. An SPD is intended to protect the electrical apparatus from transient over voltages and to divert surge currents. The SPD built in the coaxial connector can be a gas discharge tube type, a ¼ wavelength short stub type, a flash-off gap type, and a hybrid type thereof. The purpose of these built-in SPD is to protect modern electronic equipment connected to telecommunications and signalling networks with nominal system voltages up to 1 000 V (RMS) AC and 1 500 V DC.
IEC 61169-1-3:2026 is applicable to built-in devices (hereinafter referred to as "SPD" - surge protective device) or surge protection of telecommunications and signalling networks against indirect and direct effects of lightning or other transient over voltages. An SPD is intended to protect the electrical apparatus from transient over voltages and to divert surge currents. The SPD built in the coaxial connector can be a gas discharge tube type, a ¼ wavelength short stub type, a flash-off gap type, and a hybrid type thereof. The purpose of these built-in SPD is to protect modern electronic equipment connected to telecommunications and signalling networks with nominal system voltages up to 1 000 V (RMS) AC and 1 500 V DC.
EN IEC 61169-1-3:2026 is classified under the following ICS (International Classification for Standards) categories: 33.120.30 - RF connectors. The ICS classification helps identify the subject area and facilitates finding related standards.
EN IEC 61169-1-3:2026 has the following relationships with other standards: It is inter standard links to EN 61169-1:2013, EN 61643-311:2013, EN IEC 61169-1-2:2019. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.
EN IEC 61169-1-3:2026 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
Standards Content (Sample)
SLOVENSKI STANDARD
01-september-2026
Radiofrekvenčni konektorji - 1-3. del: Električne preskusne metode - Odpornost na
prenapetost - Prenapetostna zaščitna naprava z vgrajenim koaksialnim
konektorjem - Zahtevane lastnosti in preskusne metode (IEC 61169-1-3:2026)
Radio-frequency connectors - Part 1-3: Electrical test methods - Surge withstand - Surge
protective devices built-in coaxial connector - Performance requirements and testing
methods (IEC 61169-1-3:2026)
Hochfrequenz-Steckverbinder - Teil 1-3: Elektrische Prüfverfahren -
Überspannungsschutz - Überspannungsschutzgeräte mit eingebautem Koaxialstecker -
Leistungsanforderungen und Prüfverfahren (IEC 61169-1-3:2026)
Connecteurs pour fréquences radioélectriques - Partie 1-3: Méthodes d'essais
électriques - Tenue aux tensions de choc - Connecteurs coaxiaux intégrés pour
parafoudres - Exigences de performance et méthodes d'essai (IEC 61169-1-3:2026)
Ta slovenski standard je istoveten z: EN IEC 61169-1-3:2026
ICS:
33.120.30 Radiofrekvenčni konektorji RF connectors
(RF)
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.
EUROPEAN STANDARD EN IEC 61169-1-3
NORME EUROPÉENNE
EUROPÄISCHE NORM July 2026
ICS 33.120.30
English Version
Radio-frequency connectors - Part 1-3: Electrical test methods -
Surge withstand - Surge protective devices built in a coaxial
connector - Performance requirements and testing methods
(IEC 61169-1-3:2026)
Connecteurs pour fréquences radioélectriques - Partie 1-3: Hochfrequenz-Steckverbinder - Teil 1-3: Elektrische
Méthodes d'essais électriques - Tenue aux tensions de Prüfverfahren - Überspannungsschutz -
choc - Dispositifs de protection contre les surtensions Überspannungsschutzgeräte mit eingebautem
intégrés dans un connecteur coaxial - Exigences de Koaxialstecker - Leistungsanforderungen und Prüfverfahren
performance et méthodes d'essai (IEC 61169-1-3:2026)
(IEC 61169-1-3:2026)
This European Standard was approved by CENELEC on 2026-06-01. CENELEC members are bound to comply with the CEN/CENELEC
Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration.
Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC
Management Centre or to any CENELEC member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation
under the responsibility of a CENELEC member into its own language and notified to the CEN-CENELEC Management Centre has the
same status as the official versions.
CENELEC members are the national electrotechnical committees of Austria, Belgium, Bulgaria, Croatia, Cyprus, the Czech Republic,
Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, the
Netherlands, Norway, Poland, Portugal, Republic of North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland,
Türkiye and the United Kingdom.
European Committee for Electrotechnical Standardization
Comité Européen de Normalisation Electrotechnique
Europäisches Komitee für Elektrotechnische Normung
CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels
© 2026 CENELEC All rights of exploitation in any form and by any means reserved worldwide for CENELEC Members.
Ref. No. EN IEC 61169-1-3:2026 E
European foreword
The text of document 46F/738/FDIS, future edition 1 of IEC 61169-1-3, prepared by SC 46F "RF and
microwave passive components" of IEC/TC 46 "Cables, wires, waveguides, RF connectors, RF and
microwave passive components and accessories" was submitted to the IEC-CENELEC parallel vote
and approved by CENELEC as EN IEC 61169-1-3:2026.
The following dates are fixed:
• latest date by which the document has to be implemented at national (dop) 2027-07-31
level by publication of an identical national standard or by endorsement
• latest date by which the national standards conflicting with the (dow) 2029-07-31
document have to be withdrawn
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. CENELEC shall not be held responsible for identifying any or all such patent rights.
Any feedback and questions on this document should be directed to the users’ national committee. A
complete listing of these bodies can be found on the CENELEC website.
Endorsement notice
The text of the International Standard IEC 61169-1-3:2026 was approved by CENELEC as a
European Standard without any modification.
In the official version, for Bibliography, the following notes have to be added for the standard indicated:
IEC 60060-2:2025 NOTE Approved as EN IEC 60060-2:2025 (not modified)
IEC 60068-1:2013 NOTE Approved as EN 60068-1:2014 (not modified)
IEC 60068-2-38:2021 NOTE Approved as EN IEC 60068-2-38:2021 (not modified)
IEC 60364-5-51:2005 NOTE Approved as HD 60364-5-51:2009 +A11:2013
IEC 61643-12 NOTE Approved as CLC/TS 61643-12
IEC 61643-21:2025 NOTE Approved as EN IEC 61643-21:2026 (not modified)
IEC 62305-4 NOTE Approved as EN IEC 62305-4
Annex ZA
(normative)
Normative references to international publications
with their corresponding European publications
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments)
applies.
NOTE 1 Where an International Publication has been modified by common modifications, indicated by (mod),
the relevant EN/HD applies.
NOTE 2 Up-to-date information on the latest versions of the European Standards listed in this annex is available
here: www.cencenelec.eu.
Publication Year Title EN/HD Year
IEC 61083-1 - Instruments and software used for - -
measurements in high-voltage and high-
current tests - Part 1: Requirements for
instruments for impulse tests
IEC 61169-1 2013 Radio frequency connectors - Part 1: EN 61169-1 2013
Generic specification - General
requirements and measuring methods
IEC 61169-1-2 - Radio-frequency connectors - Part 1-2: EN IEC 61169-1-2 -
Electrical test methods - Insertion loss
IEC 61643-311 2013 Components for low-voltage surge EN 61643-311 2013
protective devices - Part 311: Performance
requirements and test circuits for gas
discharge tubes (GDT)
IEC 61169-1-3 ®
Edition 1.0 2026-04
INTERNATIONAL
STANDARD
Radio-frequency connectors -
Part 1-3: Electrical test methods - Surge withstand - Surge protective devices
built in a coaxial connector - Performance requirements and testing methods
ICS 33.120.30 ISBN 978-2-8327-1219-1
IEC 61169-1-3:2026-04(en)
IEC 61169-1-3:2026 © IEC 2026
CONTENTS
FOREWORD . 3
1 Scope . 5
2 Normative references . 5
3 Terms and definitions . 5
4 Service and test conditions . 8
4.1 Service conditions . 8
4.1.1 Normal service conditions . 8
4.1.2 Abnormal service conditions . 8
4.2 Temperature and humidity test . 8
4.3 SPD testing . 9
5 Electrical requirements . 9
5.1 General . 9
5.2 Initial values . 9
5.2.1 Sparkover voltages . 9
5.2.2 Return loss (VSWR) . 9
5.2.3 Insertion loss . 9
5.2.4 Insulation resistance . 9
5.3 Test measurements and requirements – Impulse durability . 10
5.4 Requirements after application of load . 10
5.4.1 General . 10
5.4.2 Sparkover voltages . 10
5.4.3 Return loss (VSWR) . 10
5.4.4 Insertion loss . 10
5.4.5 Insulation resistance . 10
6 Test and measurement procedures and circuits . 10
6.1 DC sparkover voltage. 10
6.2 Impulse sparkover voltage . 11
6.3 Impulse durability . 11
6.4 Return loss (VSWR) . 12
6.5 Insertion loss . 12
6.6 Insulation resistance . 12
7 Details to be specified . 12
Annex A (informative) Measurement equipment examples of DC sparkover voltage
test . 13
A.1 Applicable tools . 13
A.2 Test overview . 14
A.3 Test procedure and method . 14
A.4 Test results . 16
Annex B (informative) Measurement equipment examples of impulse sparkover
voltage test . 17
B.1 Applicable tools . 17
B.2 Test overview . 17
B.3 Test results . 18
Annex C (informative) Measurement equipment examples of impulse durability test . 20
C.1 Impulse durability (applicable to signal and communication SPDs) . 20
IEC 61169-1-3:2026 © IEC 2026
C.2 Impulse durability category C2 (applicable to signal and communication
SPDs) . 20
C.3 Impulse durability category D1 (applicable to signal and communication
SPDs) . 20
C.4 Applicable tools and overview . 20
Bibliography . 24
Figure 1 – Coaxial adapter for surge protection device with gas discharge tube . 6
Figure 2 – Coaxial adapter for surge protection device with ¼ wavelength short stub. 7
Figure 3 – Circuit for DC sparkover voltage test at 100 V/s . 11
Figure 4 – Circuit for impulse sparkover voltage at 1 000 V/μs . 11
Figure 5 – Test circuits for impulse durability and overstressed fault mode . 12
Figure A.1 – Withstand voltage tester . 13
Figure A.2 – Oscilloscope . 13
Figure A.3 – High-voltage probe . 14
Figure A.4 – Test equipment overview . 15
Figure A.5 – Test results . 16
Figure B.1 – Lightning surge tester . 17
Figure B.2 – Test overview . 18
Figure B.3 – Test results . 19
Figure C.1 – Direct lightning impulse generator . 20
Figure C.2 – Names of the parts of the direct lightning impulse generator . 21
Figure C.3 – Impulse durability measurement layout . 22
Figure C.4 – Connector setup example . 23
IEC 61169-1-3:2026 © IEC 2026
INTERNATIONAL ELECTROTECHNICAL COMMISSION
____________
Radio-frequency connectors -
Part 1-3: Electrical test methods - Surge withstand -
Surge protective devices built in a coaxial connector -
Performance requirements and testing methods
FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of IEC is to promote international
co-operation on all questions concerning standardization in the electrical and electronic fields. To this end and
in addition to other activities, IEC publishes International Standards, Technical Specifications, Technical Reports,
Publicly Available Specifications (PAS) and Guides (hereafter referred to as "IEC Publication(s)"). Their
preparation is entrusted to technical committees; any IEC National Committee interested in the subject dealt with
may participate in this preparatory work. International, governmental and non-governmental organizations liaising
with the IEC also participate in this preparation. IEC collaborates closely with the International Organization for
Standardization (ISO) in accordance with conditions determined by agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all
interested IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence between
any IEC Publication and the corresponding national or regional publication shall be clearly indicated in the latter.
5) IEC itself does not provide any attestation of conformity. Independent certification bodies provide conformity
assessment services and, in some areas, access to IEC marks of conformity. IEC is not responsible for any
services carried out by independent certification bodies.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and
expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC
Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
9) IEC draws attention to the possibility that the implementation of this document may involve the use of (a)
patent(s). IEC takes no position concerning the evidence, validity or applicability of any claimed patent rights in
respect thereof. As of the date of publication of this document, IEC had not received notice of (a) patent(s), which
may be required to implement this document. However, implementers are cautioned that this may not represent
the latest information, which may be obtained from the patent database available at https://patents.iec.ch. IEC
shall not be held responsible for identifying any or all such patent rights.
IEC 61169-1-3 has been prepared by subcommittee 46F: RF and microwave passive
components, of IEC technical committee 46: Cables, wires, waveguides, RF connectors, RF
and microwave passive components and accessories. It is an International Standard.
The text of this International Standard is based on the following documents:
Draft Report on voting
46F/738/FDIS 46F/741/RVD
Full information on the voting for its approval can be found in the report on voting indicated in
the above table.
The language used for the development of this International Standard is English.
IEC 61169-1-3:2026 © IEC 2026
This document was drafted in accordance with ISO/IEC Directives, Part 2, and developed in
accordance with ISO/IEC Directives, Part 1 and ISO/IEC Directives, IEC Supplement, available
at www.iec.ch/members_experts/refdocs. The main document types developed by IEC are
described in greater detail at www.iec.ch/publications.
A list of all parts in the IEC 61169 series, published under the general title Radio-frequency
connectors, can be found on the IEC website.
The committee has decided that the contents of this document will remain unchanged until the
stability date indicated on the IEC website under webstore.iec.ch in the data related to the
specific document. At this date, the document will be
– reconfirmed,
– withdrawn, or
– revised.
IEC 61169-1-3:2026 © IEC 2026
1 Scope
This part of IEC 61169 is applicable to built-in devices (hereinafter referred to as "SPD" – surge
protective device) or surge protection of telecommunications and signalling networks against
indirect and direct effects of lightning or other transient over voltages.
An SPD is intended to protect the electrical apparatus from transient over voltages and to divert
surge currents.
The SPD built in the coaxial connector can be a gas discharge tube type, a ¼ wavelength short
stub type, a flash-off gap type, and a hybrid type thereof.
The purpose of these built-in SPD is to protect modern electronic equipment connected to
telecommunications and signalling networks with nominal system voltages up to 1 000 V (RMS)
AC and 1 500 V DC.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies.
For undated references, the latest edition of the referenced document (including any
amendments) applies.
IEC 61083-1, Instruments and software used for measurements in high-voltage and high-
current tests - Part 1: Requirements for instruments for impulse tests
IEC 61169-1:2013, Radio frequency connectors - Part 1: Generic speci
...
