EN IEC 61169-1-9:2025

Radio-frequency connectors - Part 1-9: Mechanical test methods - Safety wire hole pull-out

IEC 61169-1-9:2025 specifies test methods for the safety wire hole pull-out of RF connectors. This document is applicable to the connectors with safety wire holes.

Hochfrequenz-Steckverbinder - Teil 1-9: Mechanische Prüfverfahren - Herausziehen von Sicherheitsdrahtlöchern

Connecteurs pour fréquences radioélectriques - Partie 1-9: Méthodes d’essais mécaniques - Extraction par le trou du fil de sécurité

L'IEC 61169-1-9:2025 spécifie les méthodes d'essai relatives à l’extraction par le trou du fil de sécurité des connecteurs RF. Ce document est applicable aux connecteurs comportant des trous pour les fils de sécurité.

Radiofrekvenčni konektorji - 1-9. del: Mehanske preskusne metode - Izvlečna luknja za varnostno žico (IEC 61169-1-9:2025)

Ta del standarda IEC 61169 določa preskusne metode za izvlečno luknjo za varnostno žico radiofrekvenčnih (RF) konektorjev.
Ta dokument se uporablja za konektorje z luknjami za varnostne žice.
2

General Information

• Status: Published
• Publication Date: 26-Jun-2025
• ICS: 33.120.30 - RF connectors
• Technical Committee: CLC/SR 46F - RF and microwave passive components
• Current Stage: 6060 - Document made available - Publishing
• Start Date: 27-Jun-2025
• Due Date: 06-Dec-2024
• Completion Date: 27-Jun-2025
• Ref Project: SIST EN IEC 61169-1-9:2025 - Radio-frequency connectors- Part 1-9: Mechanical test methods- Safety wire hole pull-out (IEC 61169-1-9:2025)

Overview

EN IEC 61169-1-9:2025 is a European Standard developed by CLC that specifies the mechanical test methods for safety wire hole pull-out in radio-frequency (RF) connectors. This standard focuses on verifying the mechanical robustness of safety wire holes in RF connectors, ensuring that they can endure specified pulling forces without damage or failure. Applicable to connectors featuring safety wire holes, this standard is part 1-9 of the IEC 61169 series, which governs RF connectors and their specifications.

The document was approved by CENELEC in June 2025 and aims to harmonize testing procedures across the industry for quality assurance, safety, and performance consistency of RF connectors used in various electrotechnical applications.

Key Topics

• Scope and Applicability
  Defines test methods exclusively for connectors with safety wire holes, as part of overall RF connector evaluation.

• Test Equipment
  Requires use of a pulling testing machine or device capable of applying controlled forces for the pull-out tests.

• Test Conditions
  Testing is performed under ambient room conditions or conditions specified by relevant product specifications.

• Test Procedure

  • Secure the device under test (DUT) in the testing fixture.
  • Loop a safety wire through the safety wire hole, secure it, and attach to the testing machine.
  • Apply a pulling force of 67 Newtons (N) for 30 seconds parallel to the connector axis.
  • Repeat with pulling force perpendicular to the connector axis.
  • Test all safety wire holes similarly.
  • Inspect the safety wire hole for breakage or tearing post-test.
  • Replace the safety wire if it breaks during testing and repeat.

• Specification Information
  The standard requires specifications to detail any deviations from the default force (67 N), duration (30 s), or method.

• Test Reporting
  Reports must document test conditions, force applied, duration, equipment used, sample details, results, operator, and date.

• Annex on Safety Wire Details
  Provides guidance on the typical location of safety wire holes, selection of corrosion-resistant steel safety wires (0.35 mm or 0.5 mm diameter), and installation procedures. Recommended wire sizes are aligned with common connector types such as SMA, TNC, N, SC, and 7-16 models.

Applications

This standard is critical for manufacturers, testing laboratories, and quality assurance teams involved in the production and evaluation of RF connectors with safety wire holes. The mechanical integrity of these holes is important for:

• Safety Assurance: Ensures safety wires function correctly to prevent loosening or accidental disconnection.
• Quality Control: Provides standardized test methods for repeatable and reliable connector performance assessments.
• Military and Aerospace: Where connector reliability under mechanical stress is vital.
• Telecommunications and Broadcast: Maintains secure RF connections in critical infrastructure.
• Industrial and Scientific Equipment: Used for durable RF connectors in harsh environments.

By implementing EN IEC 61169-1-9:2025, organizations can certify that RF connectors meet international quality standards and consistency requirements, reducing field failures and enhancing safety.

Related Standards

• IEC 61169-1 – Generic specification for RF connectors including general requirements and measuring methods, which forms the basic framework for connector specifications.
• Other parts of the IEC 61169 series covering electrical, climatic, mechanical, and environmental tests on RF connectors.
• ISO/IEC Directives governing standard development process, ensuring harmonization and compliance with international standardization best practices.
• Relevant national implementations of EN IEC 61169-1-9:2025 in CENELEC member countries.

---

Keywords: EN IEC 61169-1-9:2025, RF connectors, safety wire hole pull-out, mechanical test methods, CLC standard, radio-frequency connectors, connector testing, pull-out test, safety wire, IEC 61169 series, connector quality assurance, RF connector standards.
