1.1 General (ncpt) PL.1 Scope of application This NNA applies to designing and constructing of new overhead lines with nominal system voltages exceeding 1 kV AC. "New overhead line" means a totally new line between two points, A and B, built up with new components. The standard PN-EN 50341-1 (Part 1) with this NNA does not apply to modernisation, reconstruction and renovation of the existing lines, unless otherwise specified in the Project Specification. 1.2 Field of application (ncpt) PL.1 All Dielectric Self Supporting (ADSS) cables This NNA applies to All Dielectric Self Supporting (ADSS) cables only within the scope of their impact on the supports and minimum clearances which shall be taken as for insulated cable systems. (ncpt) PL.2 Telecommunication equipment This NNA relates to the telecommunication equipment mounted on the new overhead line supports.

Nadzemni električni vodi za izmenične napetosti nad 1 kV - 2-22. del: Nacionalna normativna določila (NNA) za Poljsko (na podlagi EN 50341-1:2012)

1.1 Splošno
(ncpt)   PL.1 Področje uporabe
To nacionalno normativno določilo se uporablja za načrtovanje in gradnjo novih nadzemnih vodov z nazivno izmenično napetostjo sistema, ki presega 1 kV.
»Nov nadzemni vod« pomeni popolnoma nov vod med točkama A in B, izdelan z novimi komponentami.
Standard PN-EN 50341-1 (1. del) s tem nacionalnim normativnim določilom se ne uporablja za posodobitev, rekonstrukcijo in obnovo obstoječih vodov, razen če je v specifikaciji projekta določeno drugače.
1.2 Področje uporabe
(ncpt)   PL.1 Popolnoma dielektrični samonosni kabli (ADSS)
To nacionalno normativno določilo se uporablja za vse kable ADSS samo v okviru njihovega vpliva na nosilce in minimalne razdalje, ki se upoštevajo za izolirane kabelske sisteme.
(ncpt)   PL.2 Telekomunikacijska oprema
To nacionalno normativno določilo se navezuje na telekomunikacijsko opremo, nameščeno na nove nosilce nadzemnih vodov.
