IEC 61169-74:2025

Radio-frequency connectors - Part 74: Sectional specification for HN series RF coaxial connectors with screw coupling - Characteristic impedance 50 Ω

IEC 61169-74:2025, which is a Sectional Specification (SS), provides information and rules for the preparation of Detail Specifications (DS) for series HN RF coaxial connectors with screw coupling with a characteristic impedance of 50 Ω.
This document prescribes mating face dimensions for high performance connectors (grade 2), dimensional details of standard test connectors (grade 0), gauging information and tests selected from IEC 61169-1, applicable to all Detail Specifications relating to series HN RF connectors.
This document indicates recommended performance characteristics which are considered when writing a Detail Specification and it covers test schedules and inspection requirements for assessment levels M and H.
The series HN connectors are intended to be used in microwave transmission systems and can be connected with all kinds of RF cables and microstrips. The operating frequency is up to 6 GHz.

Connecteurs pour fréquences radioélectriques - Partie 74: Spécification intermédiaire pour connecteurs RF coaxiaux de série HN avec couplage à vis - Impédance caractéristique 50 Ω

L'IEC 61169-74:2025, qui est une spécification intermédiaire (SS, Sectional Specification), fournit des informations et des règles pour l'élaboration des spécifications particulières (DS, Detail Specification) relatives aux connecteurs RF coaxiaux de la série HN, à couplage à vis et ayant une impédance caractéristique de 50 Ω.
Le présent document décrit les dimensions des faces d'accouplement pour les connecteurs à usage général (grade 2), les détails dimensionnels des connecteurs d'essai normalisés (grade 0), les informations relatives aux calibres et les essais choisis à partir de l'IEC 61169-1, applicables à toutes les spécifications particulières relatives aux connecteurs RF de série HN.
Le présent document indique les caractéristiques de performance recommandées prises en considération pour la rédaction d'une spécification particulière et elle couvre les programmes d'essai et les exigences de contrôle pour les niveaux d'assurance M et H.
Les connecteurs de série HN sont destinés à être utilisés dans les systèmes de transmission à hyperfréquences et peuvent être connectés à tous types de câbles RF et de microrubans. La fréquence de fonctionnement s'étend jusqu'à 6 GHz.

General Information

• Status: Published
• Publication Date: 06-Nov-2025
• ICS: 33.120.30 - RF connectors
• Technical Committee: SC 46F - RF and microwave passive components
• Drafting Committee: WG 1 - TC 46/SC 46F/WG 1
• Current Stage: PPUB - Publication issued
• Start Date: 07-Nov-2025
• Completion Date: 10-Dec-2025

Overview

IEC 61169-74:2025 is a Sectional Specification (SS) that defines rules and guidance for preparing Detail Specifications (DS) for HN series RF coaxial connectors with screw coupling and a characteristic impedance of 50 Ω. Intended for microwave transmission systems, this standard covers mating face dimensions, gauging, test selection, and recommended performance characteristics for HN connectors that operate up to 6 GHz. The document supports consistent design, testing and quality assessment of high‑performance HN RF coaxial connectors.

Key topics and technical requirements

• Scope and purpose: Framework for Detail Specifications for HN series RF coaxial connectors (screw coupling), 50 Ω.
• Mating face dimensions: Prescribes mating face dimensional requirements for Grade 2 (high performance) connectors and dimensional details of Grade 0 (standard test connectors).
• Gauging information: Includes gauges such as the gauge pin for socket centre contacts and gauges for the outer contact to verify sizing, insertion and retention.
• Test selection and procedures: References tests selected from IEC 61169-1 and provides recommended test schedules including acceptance tests and periodic tests.
• Quality assessment and inspection: Defines inspection requirements and test schedules for assessment levels M and H, plus procedures for quality conformance.
• Detail Specification guidance: Instructions and a blank DS pro forma to help manufacturers and spec writers define component identification, performance, marking and ordering information.
• Performance boundaries: Design and test guidance tailored for microwave use, compatible with RF cables and microstrips, and targeting reliable operation to 6 GHz.

Practical applications

• Ensures interchangeability and performance of HN series RF connectors across suppliers and systems.
• Used when creating or verifying Detail Specifications for connectors in microwave communication equipment, test fixtures, cable assemblies and microstrip interfaces.
• Supports development and verification for applications requiring controlled 50 Ω impedance, repeatable mating characteristics and robust gauging and test regimes.

Who uses IEC 61169-74:2025

• RF/microwave connector designers and manufacturers preparing Detail Specifications.
• Quality, test and metrology laboratories performing acceptance and periodic testing.
• Procurement and specification engineers in telecommunications, RF test equipment, and microwave system integration.
• Regulatory and conformity assessors referencing standardized test schedules and inspection levels.

Related standards (normative references)

• IEC 61169-1 - Generic specification: general requirements and measuring methods.
• IEC 62037-3 - Passive intermodulation measurement for coaxial connectors.
• IEC 62153-4-7 - Test methods for transfer impedance and screening attenuation.

Keywords: IEC 61169-74, HN series, RF coaxial connectors, screw coupling, 50 Ω, mating face dimensions, gauging, test schedules, assessment level M H, microwave up to 6 GHz.
