IEC 60335-2-4:2023
(Main)Household and similar electrical appliances - Safety - Part 2-4: Particular requirements for spin extractors
Household and similar electrical appliances - Safety - Part 2-4: Particular requirements for spin extractors
IEC 60335-2-4:2023 deals with the safety of:
- stand-alone electric spin extractors, and
- spin extractors incorporated in washing machines that have separate containers for washing and spin extraction
for household and similar purposes that have a capacity not exceeding 10 kg of dry cloth and a drum peripheral speed not exceeding 50 m/s, their rated voltages being not more than 250 V for single-phase appliances and 480 V for other appliances including direct current (DC) supplied appliances and battery-operated appliances.
Appliances not intended for normal household use but which nevertheless can be a source of danger to the public, such as spin extractors intended to be used by laymen in shops, in light industry and on farms and spin extractors for communal use in blocks of flats or in launderettes, are within the scope of this standard.
As far as is practicable, this standard deals with the reasonably foreseeable hazards presented by appliances that are encountered by all persons. However, in general, it does not take into account:
- persons (including children) whose physical, sensory or mental capabilities; or lack of experience and knowledge prevents them from using the appliance safely without supervision or instruction;
- children playing with the appliance.
Attention is drawn to the fact that:
- for appliances intended to be used in vehicles or on board ships or aircraft, additional requirements can be necessary;
- in many countries, additional requirements are specified by the national health authorities, the national authorities responsible for the protection of labour, the national water supply authorities and similar authorities.
This standard does not apply to:
- appliances intended exclusively for industrial purposes;
- appliances intended to be used in locations where special conditions prevail, such as the presence of a corrosive or explosive atmosphere (dust, vapour or gas).
This eighth edition cancels and replaces the seventh edition published in 2021. This edition constitutes a technical revision.
This edition includes the following significant technical changes with respect to the previous edition:
a) alignment with IEC 60335-1:2020;
b) conversion of some notes to normative text (20.103, 20.104, 22.101);
c) addition of test probe 19 for accessibility of live parts and moving parts (8.1.1, 20.2);
d) addition of accessible surface temperature limits (11.3, 11.8);
e) specified operating conditions for battery operated appliances (B.11.1).
This part 2 is to be used in conjunction with the latest edition of IEC 60335-1 and its amendments unless that edition precludes it; in that case, the latest edition that does not preclude it is used. It was established on the basis of the sixth edition (2020) of that standard.
Appareils électrodomestiques et analogues - Sécurité - Partie 2-4: Exigences particulières pour les essoreuses centrifuges
L'IEC 60335-2-4:2023 traite de la sécurité:
- des essoreuses centrifuges électriques indépendantes; et
- des essoreuses centrifuges incorporées à des machines à laver le linge qui comportent des tambours distincts pour le lavage et l'essorage
pour usages domestiques et analogues dont la capacité ne dépasse pas 10 kg de linge sec, dont la vitesse périphérique du tambour ne dépasse pas 50 m/s et dont la tension assignée n'est pas supérieure à 250 V pour les appareils monophasés et à 480 V pour les autres appareils, y compris les appareils alimentés en courant continu et les appareils alimentés par batteries.
Les appareils non destinés à un usage domestique normal, mais qui peuvent néanmoins constituer une source de danger pour le public, tels que les essoreuses centrifuges destinées à être utilisées par des usagers non avertis dans des magasins, chez des artisans et dans des fermes, ainsi que les essoreuses centrifuges destinées à un usage collectif dans des immeubles d'habitation ou dans des laveries automatiques, relèvent du domaine d'application de la présente norme.
Dans la mesure du possible, la présente norme traite des dangers raisonnablement prévisibles que présentent les appareils pour toutes les personnes. Cependant, elle ne tient pas compte en général:
- des personnes (y compris des enfants) dont les capacités physiques, sensorielles ou mentales; ou le manque d'expérience et de connaissance les empêchent d'utiliser l'appareil en toute sécurité sans surveillance ou instruction;
- des enfants qui jouent avec l'appareil.
L'attention est attirée sur le fait que:
- pour les appareils destinés à être utilisés dans des véhicules ou à bord de navires ou d'avions, des exigences supplémentaires peuvent être nécessaires;
- dans de nombreux pays, des exigences supplémentaires sont spécifiées par les organismes nationaux de la santé, par les organismes nationaux responsables de la protection des travailleurs, par les organismes nationaux responsables de l'alimentation en eau et par des organismes similaires.
La présente norme ne s'applique pas:
- aux appareils prévus exclusivement pour des usages industriels;
- aux appareils destinés à être utilisés dans des locaux qui présentent des conditions particulières, telles que la présence d'une atmosphère corrosive ou explosive (poussière, vapeur ou gaz).
Cette huitième édition annule et remplace la septième édition parue en 2021. Cette édition constitue une révision technique.
Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente:
a) le texte a été aligné sur l'IEC 60335-1:2020;
b) certaines notes ont été converties en texte normatif (20.103, 20.104, 22.101);
c) le calibre d'essai 19 a été ajouté pour l'accès aux parties actives et aux parties mobiles (8.1.1, 20.2);
d) des limites de température ont été ajoutées pour les surfaces accessibles (11.3, 11.8);
e) des conditions de fonctionnement ont été spécifiées pour les appareils alimentés par batteries (B.11.1).
La présente partie 2 doit être utilisée conjointement avec la dernière édition de l'IEC 60335-1 et ses amendements sauf si cette édition l'exclut. Dans ce cas, la dernière édition qui n'exclut pas la présente partie 2 est utilisée. Elle a été établie sur la base de la sixième édition (2020) de cette norme.
