IEC 61730-2:2023

Photovoltaic (PV) module safety qualification - Part 2: Requirements for testing

IEC 61730-2:2023 lists the tests a PV module is required to fulfil for safety qualification. This document applies for safety qualification only in conjunction with IEC 61730-1. The objective of this document is to provide the testing sequence intended to verify the safety of PV modules whose construction has been assessed by IEC 61730-1. The test sequence and pass criteria are designed to detect the potential breakdown of internal and external components of PV modules that would result in fire, electric shock, and/or personal injury. This document defines the basic safety test requirements and additional tests that are a function of the PV module end-use applications. The additional testing requirements outlined in relevant ISO documents, or the national or local codes which govern the installation and use of these PV modules in their intended locations, are considered in addition to the requirements contained within this document.
The content of the corrigendum 1 (2024-10) has been included in this copy.

Qualification pour la sûreté de fonctionnement des modules photovoltaïques (PV) - Partie 2: Exigences pour les essais

L'IEC 61730-2:2023 définit les exigences de construction, le présent document répertorie les essais auxquels un module PV doit satisfaire à des fins de qualification pour la sûreté de fonctionnement. Le présent document n'est appliqué à des fins de qualification pour la sûreté de fonctionnement que conjointement à l'IEC 61730-1. L'objectif du présent document est de fournir la séquence d'essais destinée à vérifier la sûreté des modules PV dont la construction a été évaluée par l'IEC 61730-1. La séquence d'essais et les critères d'acceptation sont conçus pour détecter le claquage éventuel de composants internes et externes des modules PV, qui peut entraîner des incendies, des chocs électriques et/ou des dommages corporels. Le présent document définit les exigences de base relatives aux essais de sécurité, ainsi que des essais supplémentaires qui dépendent des applications finales du module PV. Outre les exigences contenues dans le présent document, les exigences d'essai supplémentaires suivantes sont prises en considération: exigences indiquées dans les documents ISO appropriés ou exigences spécifiées dans les codes nationaux ou locaux qui régissent l'installation et l'utilisation de ces modules PV dans leurs emplacements destinés.
Le contenu du corrigendum 1 (2024-10) a été pris en considération dans cet exemplaire.

General Information

• Status: Published
• Publication Date: 11-Sep-2023
• ICS: 27.160 - Solar energy engineering
• Technical Committee: TC 82 - Solar photovoltaic energy systems
• Drafting Committee: WG 2 - TC 82/WG 2
• Current Stage: PPUB - Publication issued
• Start Date: 11-Aug-2023
• Completion Date: 12-Sep-2023

Relations

• Corrected By: IEC 61730-2:2023/COR1:2024 - Corrigendum 1- Photovoltaic (PV) module safety qualification - Part 2: Requirements for testing
• Effective Date: 19-Jul-2024
• Revises: IEC 61730-2:2016 - Photovoltaic (PV) module safety qualification - Part 2: Requirements for testing
• Effective Date: 05-Sep-2023

Standards Content (Sample)
