ISO/FDIS 20816-1

• Abstract:

  ISO 20816-1:2016 establishes general conditions and procedures for the measurement and evaluation of vibration using measurements made on rotating, non-rotating and non-reciprocating parts of complete machines. It is applicable to measurements of both absolute and relative radial shaft vibration with regard to the monitoring of radial clearances, but excludes axial shaft vibration. The general evaluation criteria, which are presented in terms of both vibration magnitude and change of vibration, relate to both operational monitoring and acceptance testing. They have been provided primarily with regard to securing reliable, safe, long-term operation of the machine while minimizing adverse effects on associated equipment. Guidelines are also presented for setting operational limits. NOTE 1 The evaluation criteria for different classes of machinery will be included in other parts of ISO 20816 when they become available. In the meantime, guidelines are given in Clause 6. NOTE 2 The term "shaft vibration" is used throughout ISO 20816 because, in most cases, measurements are made on machine shafts. However, the ISO 20816 series is also applicable to measurements made on other rotating elements if such elements are found to be more suitable, provided that the guidelines are respected. For the purposes of ISO 20816, operational monitoring is considered to be those vibration measurements made during the normal operation of a machine. The ISO 20816 series permits the use of different measurement quantities and methods, provided that they are well-defined and their limitations are set out, so that the interpretation of the measurements is well-understood. The evaluation criteria relate only to the vibration produced by the machine itself and not the vibration transmitted to it from outside. ISO 20816-1:2016 does not include consideration of torsional vibration. NOTE 3 For torsional vibration, see, for example, ISO 3046‑5, ISO 22266‑1 or VDI 2039.

• Status: Not Published
• ICS: 17.160 - Vibrations, shock and vibration measurements
• Technical Committee: ISO/TC 108/SC 2 - Measurement and evaluation of mechanical vibration and shock as applied to machines, vehicles and structures
• Drafting Committee: ISO/TC 108/SC 2/WG 1 - Rotordynamics and vibration of machines
• Current Stage: 5020 - FDIS ballot initiated: 2 months. Proof sent to secretariat
• Start Date: 11-Aug-2026
• Completion Date: 11-Aug-2026

• Revises: ISO 20816-1:2016 - Mechanical vibration — Measurement and evaluation of machine vibration — Part 1: General guidelines
• Effective Date: 29-Jun-2024

Overview

ISO/FDIS 20816-1:2026 sets out essential guidelines for the measurement and evaluation of mechanical vibration in machines. As the foundational part of the ISO 20816 series, this standard is indispensable for professionals tasked with operational monitoring, acceptance testing, and long-term maintenance of rotating and non-rotating machine components. The document is applicable to vibration measurements on non-rotating parts and both absolute and relative radial shaft vibration, focusing exclusively on radial clearances. By offering generalized evaluation criteria, ISO/FDIS 20816-1 facilitates safer, more reliable, and efficient machine operation, while helping to minimize adverse effects on connected equipment.

Key Topics

• Measurement Types: The standard addresses vibration measurements on both rotating components (such as shafts) and structural, non-rotating parts (e.g., bearing housings).
• Measurement Parameters: Emphasis is placed on absolute and relative radial vibration, including measurement of displacement (µm), velocity (mm/s), and acceleration (m/s²).
• Preferred Locations: Guidance is provided for optimal sensor placement, including positions on bearing housings, pedestals, and rotating shafts, to capture the most meaningful vibration data.
• Support Structure Classification: Machines are classified as having rigid or flexible support structures based on the relationship of natural frequencies to the machine’s operational frequencies.
• Instrumentation Requirements: Specifies that both the measurement devices and their mounting arrangements comply with referenced ISO documents to ensure data accuracy and reliability.
• Evaluation Criteria: Outlines how to interpret measurement results in the context of operational monitoring and acceptance testing, considering both vibration magnitude and changes over time.
• Selection of Measurement Methods: Offers guidance on choosing the appropriate measurement technique based on machine type, bearing design, shaft flexibility, and operational experience.
• Operational Limits: Recommendations are included for setting vibration limits to maintain safe machine operation.

Applications

ISO/FDIS 20816-1 is valuable across a broad range of industries, including energy, manufacturing, chemical processing, and transportation, where machinery health is critical. Typical applications involve:

• Operational Monitoring: Continuous vibration monitoring during machine operation enables early detection of faults, reducing downtime and preventing catastrophic failures.
• Acceptance Testing: Standardized vibration tests during commissioning or after major overhauls verify that machines meet performance and safety specifications before entering service.
• Maintenance Planning: Trending vibration data and evaluating changes in vibration levels support predictive maintenance strategies and optimize resource allocation.
• Machine Diagnostics: The guidelines facilitate thorough diagnostic investigations to pinpoint causes of increased vibration, supporting root cause analysis and corrective action planning.

Related Standards

Implementation and interpretation of ISO/FDIS 20816-1 are enhanced by reference to several related international standards:

• ISO 2041 - Mechanical vibration, shock and condition monitoring - Vocabulary
• ISO 10817-1 - Rotating shaft vibration measuring systems - Part 1: Relative and absolute sensing of radial vibration
• ISO 2954 - Requirements for instruments for measuring vibration severity
• ISO 13373 series - Condition monitoring and diagnostics of machines
• ISO 17359 - Condition monitoring and diagnostics of machines - General guidelines
• ISO 10816/20816 series - Additional parts with criteria tailored to specific machine types (e.g., pumps, compressors, turbines)
• ISO 5348 - Methods for mounting accelerometers for vibration measurement
• For torsional vibration: ISO 3046-5, ISO 22266-1, and VDI 2039 recommendations

Practical Value

By following the general guidelines and evaluation criteria set forth in ISO/FDIS 20816-1, organizations benefit from:

• Consistent, comparable vibration data for better benchmarking and decision-making
• Enhanced machine reliability and safety, reducing costly breakdowns
• Streamlined compliance with relevant regulatory and tender requirements
• Informed maintenance and asset management strategies driven by standardized diagnostic insights

Staying aligned with ISO/FDIS 20816-1 is a best practice for professionals involved in machine condition monitoring, testing, and maintenance planning, ensuring machinery operates smoothly and efficiently.
