International Standard ISO 6518-2:2024(en)
Road vehicles — Ignition systems —
Part 2:
Electrical performance and function test methods
1 Scope
This document specifies the design and/or evaluation with the specific equipment, conditions and methods
for distributorless battery ignition systems intended for use in various internal combustion engines
including automotive, marine, motorcycle and utility engine applications. The test procedures listed in this
document are limited to measurements performed on a test bench only and do not include measurements
made directly on engines or vehicles. This document is not intended to supply information for battery
ignition systems used in aircraft applications of any type.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content constitutes
requirements of this document. For dated references, only the edition cited applies. For undated references,
the latest edition of the referenced document (including any amendments) applies.
ISO 6518-1, Road vehicles — Ignition systems — Part 1: Vocabulary
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 6518-1 apply.
ISO and IEC maintain terminology databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at https:// www .electropedia .org/
4 Ignition system description
This document applies to single ended coil on plug (COP) and coil near plug (CNP). This document does not
propose methods to measure any advanced ignition technologies. Those advanced technologies may require
advanced methodologies for collection of performance characteristics.
The ignition system as defined for the tests tabulated in this document shall consist of:
a) A coil. This can be the conventional induction coil or an air or magnetic core transformer.
b) High voltage, metal conductor ignition cables which are specified to eliminate the varying effects of the
different kinds of cable with high impedance conductors. Resistance per foot, as well as inductance of
spark plug cables built to suppress radiation, can be quite different from manufacturer to manufacturer.
NOTE It is possible that some ignition systems do not function properly with metallic secondary cables due
to EMI and can require low resistance inductance cables.
c) The standard switching device used in modern systems is the insulated gate bipolar transistor (IGBT).
Other transistorized switches can be utilized too.
The preceding devices shall be interconnected as the manufacturer recommends or similar to the
conventional system see Figure 15 in 7.7.
5 System load
For the purposes of this document, the assumed loads for the ignition coil are capacitance, resi
...
