49 Annex A (informative) Calculation Example of the voltage change rate for load dump ................... 43

50 Annex B (informative) Operating temperature ranges ................................................................................ 44

51 Annex C (informative) Testing at Different Temperatures ......................................................................... 45

52 Annex D (informative) Applicable Table ........................................................................................................... 46

53 Annex X (tbd) Artificial Network .......................................................................................................................... 50

54 Bibliography ................................................................................................................................................................. 54

© ISO – All rights reserved 3
---------------------- Page: 3 ----------------------
ISO DIS 21498:2018
56 Foreword

57 ISO (the International Organization for Standardization) is a worldwide federation of national

58 standards bodies (ISO member bodies). The work of preparing International Standards is normally

59 carried out through ISO technical committees. Each member body interested in a subject for which a

60 technical committee has been established has the right to be represented on that committee.

61 International organizations, governmental and non-governmental, in liaison with ISO, also take part in

62 the work. ISO collaborates closely with the International Electrotechnical Commission (IEC) on all

63 matters of electrotechnical standardization.

64 The procedures used to develop this document and those intended for its further maintenance are

65 described in the ISO/IEC Directives, Part 1. In particular the different approval criteria needed for the

66 different types of ISO documents should be noted. This document was drafted in accordance with the

67 editorial rules of the ISO/IEC Directives, Part 2. www.iso.org/directives

68 Attention is drawn to the possibility that some of the elements of this document may be the subject of

69 patent rights. ISO shall not be held responsible for identifying any or all such patent rights. Details of

70 any patent rights identified during the development of the document will be in the Introduction and/or

71 on the ISO list of patent declarations received. www.iso.org/patents

72 Any trade name used in this document is information given for the convenience of users and does not

73 constitute an endorsement.

74 For an explanation on the meaning of ISO specific terms and expressions related to conformity

75 assessment, as well as information about ISO's adherence to the WTO principles in the Technical

76 Barriers to Trade (TBT) see the following URL: Foreword - Supplementary information

77 The committee responsible for this document is TC ISO/22/SC37.
© ISO – All rights reserved 5
---------------------- Page: 4 ----------------------
ISO DIS 21498:2018
78 Introduction

79 Nowadays, the market size of electric propulsion vehicles and their components is expanding over the

80 world. In accordance with this popularization, to establish various types of standards for developing the

81 equipment has gotten largely required. First specifications and requirements for sub-classes of voltage

82 class B are given in ISO PAS 19295. The existing Standard ISO 16750-2 on electrical tests of automotive

83 components covers only equipment used for voltage class A. It is not suitable to apply on components

84 for electric propulsion system operating at high voltage known as voltage class B because there are

85 differences of working conditions and requirements between low and high voltage systems.

86 This Standard provides electrical tests for electric and electronic components at voltage class B used for

87 electrically propelled road vehicles. The tests are described in a general way. Examples for optional
