ISO/FDIS 16911-1

• Abstract:

  ISO 16911-1:2013 specifies a method for periodic determination of the axial velocity and volume flow rate of gas within emissions ducts and stacks. It is applicable for use in circular or rectangular ducts with measurement locations meeting the requirements of EN 15259. Minimum and maximum duct sizes are driven by practical considerations of the measurement devices described within ISO 16911-1:2013. ISO 16911-1:2013 requires all flow measurements to have demonstrable metrological traceability to national or international primary standards. To be used as a standard reference method, the user is required to demonstrate that the performance characteristics of the method are equal to or better than the performance criteria defined in ISO 16911-1:2013 and that the overall uncertainty of the method, expressed with a level of confidence of 95 %, is determined and reported. The results for each method defined in ISO 16911-1:2013 have different uncertainties within a range of 1 % to 10 % at flow velocities of 20 m/s. Methods further to these can be used provided that the user can demonstrate equivalence, based on the principles of CEN/TS 14793.

• Status: Not Published
• ICS: 13.040.40 - Stationary source emissions
• Technical Committee: ISO/TC 146/SC 1 - Stationary source emissions
• Drafting Committee: ISO/TC 146/SC 1 - Stationary source emissions
• Current Stage: 5020 - FDIS ballot initiated: 2 months. Proof sent to secretariat
• Start Date: 16-Sep-2026
• Completion Date: 16-Sep-2026

• Consolidates: FprEN ISO 16911-1 - Stationary source emissions - Manual and automatic determination of velocity and volume flow rate of waste gas in ducts - Part 1: Manual reference method (ISO/FDIS 16911-1:2026)
• Effective Date: 12-Feb-2026
• Revises: ISO 16911-1:2013 - Stationary source emissions — Manual and automatic determination of velocity and volume flow rate in ducts — Part 1: Manual reference method
• Effective Date: 01-Oct-2022

ISO/FDIS 16911-1 is an ISO standard for stationary source emissions. It specifies a manual reference method for determining the axial velocity and volume flow rate of waste gas in ducts and stacks, and it also describes tracer-based and calculation-based alternatives for volume flow rate. It is written for users who need periodic measurements with stated uncertainty and metrological traceability, such as emission monitoring, calibration work, and regulatory reporting.

What does ISO/FDIS 16911-1 specify?

ISO/FDIS 16911-1 specifies how to measure gas velocity and waste gas volume flow rate in circular or rectangular ducts, provided the measurement location meets ISO 15259. The document covers direct point-velocity measurements, plus tracer dilution, tracer transit time, and energy-consumption-based methods for volume flow rate.

The standard is organized into clauses on principle, method selection, equipment, performance characteristics, field procedure, calculations, uncertainty, and method evaluation. It then adds normative annexes for the main measurement methods and informative annexes for supporting topics.

Annex	What it covers
Annex A	Measurement of velocity using differential pressure-based techniques, including Pitot tube designs
Annex B	Vane anemometer
Annex C	Tracer gas dilution method for volume flow rate and average velocity
Annex D	Transit time tracer gas method for average velocity
Annex E	Calculation of waste gas volume flow rate from energy consumption
Annex F	Use of time-of-flight instruments based on modulated laser light
Annex G	Example uncertainty budget for velocity and volume flow rate measurements by Pitot tube
Annex H	Validation studies
Annex I	Check of validity of Pitot tube calibration
Annex J	Differential pressure measurement
Annex K	Example method for degree of swirl determination

What are the key requirements of ISO/FDIS 16911-1?

ISO/FDIS 16911-1 requires the user to choose a measurement method that matches the monitoring objective, the needed uncertainty, and the physical conditions of the duct. In practice, the standard is as much about selecting and controlling the measurement as it is about the arithmetic.

Monitoring objectives drive quality control

ISO/FDIS 16911-1 groups work into two monitoring objectives, MO1 and MO2. MO1 covers periodic measurements for regulatory applications such as pollution inventory reporting and support of isokinetic sampling, while MO2 covers more demanding work such as Emission Trading Schemes and calibration of an automated measuring system (AMS).

This matters because the document ties the amount of quality control, the accepted performance characteristics, and the uncertainty target to the chosen monitoring objective. A user needs to define the objective before measuring, otherwise the result may not be acceptable for the intended use.

Point velocity may be measured by Pitot tubes or vane anemometers

ISO/FDIS 16911-1 allows point flow velocity to be measured with differential pressure devices, including Pitot tubes, or with a vane anemometer. Annex A covers L-type, S-type, 2D and 3D Pitot designs, and Annex B covers vane anemometers.

This matters in practice because the choice depends on duct conditions. The standard notes, for example, that an S-type Pitot tube can suit small ports or dusty gas, while vane anemometers are not recommended where fibres or droplets are present.

Volume flow rate can be obtained by several routes

ISO/FDIS 16911-1 lets users determine volume flow rate either from a grid of point velocity measurements or by alternative methods in Annex C, Annex D, and Annex E. The tracer methods can also support calibration of an AMS, while the energy-consumption approach is for combustion or similar processes where the process inputs are known.

This matters because the document separates methods that measure the duct directly from methods that infer flow from tracer behavior or plant energy data. It also warns that the calculation approach is not for AMS calibration.

The measurement plane and duct area must be controlled

ISO/FDIS 16911-1 requires the measurement plane to comply with ISO 15259 and the internal duct area to be determined by direct dimensions where possible. The expanded uncertainty of the duct area at the measurement plane has to meet the acceptance criterion given in the standard, and port length and wall thickness also have to be measured.

This matters because a flow result is only as good as the area used to turn average velocity into flow rate. The standard also explains when engineering drawings may support direct measurement and when a wall correction factor should be used.

Device performance and calibration are part of the method

ISO/FDIS 16911-1 sets performance checks for differential pressure readout devices, Pitot tubes, temperature and pressure instruments, and vane anemometers. It requires traceable calibration, regular repeatability and linearity checks, and use of equipment ranges that suit the expected flow.

This matters because the standard treats instrument quality as part of the measurement uncertainty. For example, it gives explicit acceptance criteria for readout repeatability, lack-of-fit, calibration uncertainty, and the lowest usable range for the measuring device.

Field procedure includes leak checks, alignment, and averaging

ISO/FDIS 16911-1 requires checks before sampling, quality control during measurement, and a post-measurement leak check for Pitot tube work. It also requires the probe angle and sensor alignment to stay within the stated limits, and it calls for averaging differential pressure over at least one minute from at least three instantaneous readings.

This matters because the method is not just a single reading at each point. The user has to control leaks, misalignment, and time variation in the gas flow, especially when MO2 applies.

Results may need wall correction and condition conversion

ISO/FDIS 16911-1 calculates mean velocity from equal-area point measurements and then derives volume flow rate from mean velocity times duct area. It also provides wall adjustment factors for circular and rectangular ducts and methods for converting results to standard conditions, dry conditions, and reference oxygen content.

This matters because the reported flow must match the purpose of the measurement. For example, flow used with concentration data should be expressed under the same wet or dry basis to avoid extra uncertainty from unnecessary conversions.

Uncertainty has to be estimated and reported

ISO/FDIS 16911-1 requires an uncertainty budget based on ISO/IEC Guide 98-3 and ISO 20988. The user has to combine uncertainty sources from calibration, duct area, conversion to reported conditions, and, where relevant, wall effects and swirl, then report the overall uncertainty at 95 % confidence.

This matters because the standard is explicit about measurement quality. A result is not complete until its uncertainty is worked out and reported for the actual measurement conditions.

What terms does ISO/FDIS 16911-1 define?

• monitoring objective (MO) - The regulatory framework that sets the measurement task and the uncertainty requirement.
• measurement task - The practical scope of the measurement programme derived from the monitoring objective.
• Pitot tube - A point-velocity device that works by measuring differential pressure between stagnation and static pressure.
• measurement plane - The plane normal to the duct centreline where flow velocity or volume flow rate is measured.
• volume flow rate - The axial flow of gas through the duct, expressed as cubic metres per second or cubic metres per hour.
• expanded uncertainty - The uncertainty interval reported in this document with k = 2 and a 95 % confidence level.
• metrological traceability - The documented calibration chain linking a result to a national or international primary standard.
• automated measuring system (AMS) - A permanently installed system for continuous flow measurement; the document points to ISO 16911-2 for its determination.

Who uses ISO/FDIS 16911-1?

ISO/FDIS 16911-1 is used by laboratories, plant operators, environmental compliance teams, and calibration specialists who measure stack or duct flow. It is relevant in stationary source emissions work, especially where mass emissions, isokinetic sampling support, flow profile characterization, or AMS calibration are involved.

The standard also suits buyers and quality managers who need to specify the acceptable method for field measurements, because it links method choice to uncertainty, equipment checks, and reporting conditions. It is particularly relevant to combustion plants, emission trading work, waste incineration, and other installations with measurable exhaust ducts.

What changed in ISO/FDIS 16911-1 from the previous edition?

ISO/FDIS 16911-1 is the second edition and it replaces ISO 16911-1:2013. The foreword states that the document was technically revised.

The stated changes are:

• monitoring objectives with different uncertainty needs were clarified
• the quality control level was clarified in relation to those uncertainty needs
• the monitoring objectives were grouped by required quality control
• the measurement techniques and their requirements were described in more detail
• performance characteristics for differential pressure devices and vane anemometers were updated to reflect current practice
• the example uncertainty calculations were improved and corrected

Which standards are used with ISO/FDIS 16911-1?

Standard	What it contributes
ISO 15259:2023	Requirements for measurement sections and sites, the measurement objective, plan, and report
ISO 20988:2007	Guidance for estimating measurement uncertainty
ISO/IEC Guide 98-3:2008	The GUM approach used for uncertainty expression and combination
ISO/IEC 17025	Competence framework for testing and calibration laboratories
EN 12952-15:2003	Acceptance tests for water-tube boilers and auxiliary installations
ISO 16911-2	Flow measurement with AMS, referenced for calibration of automated systems
EN 14793	Equivalence principles for using alternative methods
ISO 3966	Pitot-tube-based flow measurement principles cited for differential pressure methods
ISO 10780	Flow measurement methods cited alongside Pitot-tube practice

What does the ISO/FDIS 16911-1 document contain?

ISO/FDIS 16911-1 contains selection guidance, measurement procedures, device performance criteria, and the calculations needed to turn local readings into a reported flow result. It also includes formulas for mean velocity, wall correction, volume flow rate, standard-condition conversion, and reference oxygen correction.

The annexes provide the practical methods behind the main clause text: Pitot tube use, vane anemometer use, tracer dilution, tracer transit time, and energy-based flow calculation. Supporting annexes add a calibration check for Pitot tubes, uncertainty examples, differential pressure guidance, swirl checking, and validation-study summaries.

The document therefore serves both field users and technical reviewers. It tells the operator what to measure, what to check, how to calculate the result, and how to support the uncertainty claim with traceable data.
