Steel wire ring net panels -- Definitions and specifications

ISO 17745:2016 specifies the characteristics of steel wire ring net panel for retaining of unstable slopes controlling and preventing rockfalls and loose debris flow along roads, highways and railway, urban areas, mines and quarries, and for snow avalanche protection produced from metallic-coated steel wire or advanced metallic coating. It is not applicable to anchors or soil nails for fixing of steel mesh to an unstable slope.

Panneaux de filet en anneaux de fil d'acier -- Définitions et spécifications

General Information

Status
Published
Publication Date
14-Apr-2016
Current Stage
9020 - International Standard under periodical review
Start Date
15-Apr-2021
Ref Project

Buy Standard

Standard
ISO 17745:2016 - Steel wire ring net panels -- Definitions and specifications
English language
16 pages
sale 15% off
Preview
sale 15% off
Preview

Standards Content (sample)

INTERNATIONAL ISO
STANDARD 17745
First edition
2016-05-01
Steel wire ring net panels —
Definitions and specifications
Panneaux de filet en anneaux de fil d’acier — Définitions et
spécifications
Reference number
ISO 17745:2016(E)
ISO 2016
---------------------- Page: 1 ----------------------
ISO 17745:2016(E)
COPYRIGHT PROTECTED DOCUMENT
© ISO 2016, Published in Switzerland

All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized otherwise in any form

or by any means, electronic or mechanical, including photocopying, or posting on the internet or an intranet, without prior

written permission. Permission can be requested from either ISO at the address below or ISO’s member body in the country of

the requester.
ISO copyright office
Ch. de Blandonnet 8 • CP 401
CH-1214 Vernier, Geneva, Switzerland
Tel. +41 22 749 01 11
Fax +41 22 749 09 47
copyright@iso.org
www.iso.org
ii © ISO 2016 – All rights reserved
---------------------- Page: 2 ----------------------
ISO 17745:2016(E)
Contents Page

Foreword ........................................................................................................................................................................................................................................iv

1 Scope ................................................................................................................................................................................................................................. 1

2 Normative references ...................................................................................................................................................................................... 1

3 Terms and definitions ..................................................................................................................................................................................... 1

4 Description of use and applications ................................................................................................................................................. 2

5 Wire ring net panels ......................................................................................................................................................................................... 2

6 Properties of wire ................................................................................................................................................................................................ 3

6.1 Ageing and corrosion resistance ............................................................................................................................................. 3

6.1.1 Zn class A ................................................................................................................................................................................ 3

6.1.2 Zn95Al5 class B ................................................................................................................................................................. 4

6.1.3 Zn95Al5 class A ................................................................................................................................................................. 4

6.1.4 Advanced metallic coatings (as Zn90Al10) class B ............................................................................ 4

6.1.5 Advanced metallic coatings (as Zn90Al10) class A ............................................................................ 4

7 Wire net properties ........................................................................................................................................................................................... 4

8 Wire ring net properties (longitudinal tensile test with no lateral contraction and

load bearing capacity test) ......................................................................................................................................................................... 4

9 Sampling and testing ........................................................................................................................................................................................ 4

10 Inspection and documentation ............................................................................................................................................................. 5

Annex A (informative) Possible metallic coating options ............................................................................................................... 6

Annex B (informative) Load bearing capacity tests .............................................................................................................................. 8

Annex C (informative) Net tensile strength (longitudinal tensile test with no

lateral contraction) .........................................................................................................................................................................................13

Annex D (informative) Methods for measuring the dimensions of a ring net panel .......................................15

Bibliography .............................................................................................................................................................................................................................16

© ISO 2016 – All rights reserved iii
---------------------- Page: 3 ----------------------
ISO 17745:2016(E)
Foreword

ISO (the International Organization for Standardization) is a worldwide federation of national standards

bodies (ISO member bodies). The work of preparing International Standards is normally carried out

through ISO technical committees. Each member body interested in a subject for which a technical

committee has been established has the right to be represented on that committee. International

organizations, governmental and non-governmental, in liaison with ISO, also take part in the work.

ISO collaborates closely with the International Electrotechnical Commission (IEC) on all matters of

electrotechnical standardization.

The procedures used to develop this document and those intended for its further maintenance are

described in the ISO/IEC Directives, Part 1. In particular the different approval criteria needed for the

different types of ISO documents should be noted. This document was drafted in accordance with the

editorial rules of the ISO/IEC Directives, Part 2 (see www.iso.org/directives).

Attention is drawn to the possibility that some of the elements of this document may be the subject of

patent rights. ISO shall not be held responsible for identifying any or all such patent rights. Details of

any patent rights identified during the development of the document will be in the Introduction and/or

on the ISO list of patent declarations received (see www.iso.org/patents).

Any trade name used in this document is information given for the convenience of users and does not

constitute an endorsement.

For an explanation on the meaning of ISO specific terms and expressions related to conformity

assessment, as well as information about ISO’s adherence to the WTO principles in the Technical

Barriers to Trade (TBT) see the following URL: Foreword - Supplementary information

The committee responsible for this document is ISO/TC 17, Steel, Subcommittee SC 17, Steel wire rod and

wire products.
iv © ISO 2016 – All rights reserved
---------------------- Page: 4 ----------------------
INTERNATIONAL STANDARD ISO 17745:2016(E)
Steel wire ring net panels — Definitions and specifications
1 Scope

This International Standard specifies the characteristics of steel wire ring net panel for retaining of

unstable slopes controlling and preventing rockfalls and loose debris flow along roads, highways and

railway, urban areas, mines and quarries, and for snow avalanche protection produced from metallic-

coated steel wire or advanced metallic coating.

It is not applicable to anchors or soil nails for fixing of steel mesh to an unstable slope.

2 Normative references

The following documents, in whole or in part, are normatively referenced in this document and are

indispensable for its application. For dated references, only the edition cited applies. For undated

references, the latest edition of the referenced document (including any amendments) applies.

ISO 7500-1, Metallic materials — Calibration and verification of static uniaxial testing machines — Part 1:

Tension/compression testing machines — Calibration and verification of the force-measuring system

ISO 7989-2:2007, Steel wire and wire products — Non-ferrous metallic coatings on steel wire — Part 2:

Zinc or zinc-alloy coating
ISO 10474, Steel and steel products — Inspection documents
ISO 22034-1, Steel wire and wire products — Part 1: General test methods

ISO 22034-2:2007, Steel wire and wire products — Part 2: Tolerances on wire dimensions

3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
3.1
wire ring

steel ring obtained by looping a single steel wire with ends inserted into the thread or secured by one

or more than one ferrules
3.2
nominal wire diameter
diameter used to designate the wire
Note 1 to entry: It is expressed in millimetres (mm).
3.3
real wire diameter

average value of the minimal and the maximal diameter, measured in the same section of a straight

piece of wire, by means of a micrometer to 0,01 mm
3.4
wire ring size
average value of the diameter of the single ring
Note 1 to entry: See Figure 1.
© ISO 2016 – All rights reserved 1
---------------------- Page: 5 ----------------------
ISO 17745:2016(E)
Figure 1 — Ring size
3.5
wire ring net panel
structure of the panel net, made by rings connected with the contiguous rings
3.6
advanced metallic coating

metallic coating with a non-specified composition and having a superior corrosion resistance

3.7
dimensions of a panel
length and width expressed in metres or in number of rings
Note 1 to entry: See Annex D.
3.8
ring structure
way that the ring is manufactured and constituted
4 Description of use and applications

The typical use for the considered products is retaining of unstable slopes, controlling and preventing

rockfalls and loose debris flow along roads, highways and railway, urban areas, mines and quarries,

and for snow avalanche protection.
5 Wire ring net panels

Wire ring net panels are ring panels where each ring is made by several loop bindings, each one obtained

by looping a single steel wire. Each ring is connected with four or six contiguous rings in order to create

a net as shown in Figure 2.

For the connection of the panels, shackles or wire rope shall be used. The strength of the connection

formed shall be equal to or greater than the tensile strength of the ring net panel.

2 © ISO 2016 – All rights reserved
---------------------- Page: 6 ----------------------
ISO 17745:2016(E)
a) Four contiguous rings b) Six contiguous rings
Figure 2 — Example of ring wire net panel layout
The wire ring net panels shall comply with the specifications given in Table 1.
Table 1 — Properties and possible combinations of wire ring net panels
a b c,d
Standard ring diameter Standard windings Wire diameter
mm n mm
300 9 3
350 12 4
420 16

Other ring diameters and wire diameters are possible, in accordance with project design requirements.

Other number of windings are possible, in accordance with project design requirements.

By agreement, other values should be provided.

Tolerances of metallic coated wire diameter are in accordance with class T1 in ISO 22034-2:2007, Table 1.

6 Properties of wire

The wires shall comply with the diameter and tolerances as specified in Table 1, with the coating as

specified in Table A.1, and with the coating weight as specified in ISO 7989-2.

Method of assessment and acceptance criteria for zinc and zinc alloy coating weight are described in

ISO 7989-2:2007, Clause 5.

The tensile strength of the wire used for rings shall be minimum 1 380 MPa. The tensile strength of the

wire used for rings shall be tested in accordance with ISO 22034-1.
6.1 Ageing and corrosion resistance
6.1.1 Zn class A

When subjected to the neutral salt spray test according to the procedures given in ISO 9227, after a

period of 500 h of exposure, the ring samples shall not show more than 5 % of DBR.

© ISO 2016 – All rights reserved 3
---------------------- Page: 7 ----------------------
ISO 17745:2016(E)
6.1.2 Zn95Al5 class B

When subjected to the neutral salt spray test according to the procedures given in ISO 9227, after a

period of 500 h of exposure, the ring samples shall not show more than 5 % of DBR.

6.1.3 Zn95Al5 class A

When subjected to the neutral salt spray test according to the procedures given in ISO 9227, after a

period of 1 000 h of exposure, the ring samples shall not show more than 5 % of DBR.

6.1.4 Advanced metallic coatings (as Zn90Al10) class B

When subjected to the neutral salt spray test according to the procedures given in ISO 9227, after a

period of 1 000 h of exposure, the ring samples shall not show more than 5 % of DBR.

6.1.5 Advanced metallic coatings (as Zn90Al10) class A

When subjected to the neutral salt spray test according to the procedures given in ISO 9227, after a

period of 2 000 h of exposure, the ring samples shall not show more than 5 % of DBR.

7 Wire net properties

The chain of three rings is mounted in a calibrated test traction rig and it is connected to the machine

with two circular elements of 50 mm diameter, not less than four times the diameter of the strand.

Before the test, a slight tension is given to stabilize the system, then the force is reduced again to zero

before the test starts.

The chain of three rings is tensioned by the test machine with a recommended displacement speed of

2 mm/s, until breaking (see Figure 2).

The chain of three rings breaking load is reached when the chain is no longer able to support any

increase of the applied force. Tests shall be performed on a minimum number of three samples.

The tensile test machine shall be of class 1 according to ISO 7500-1.
Figure 3 — Scheme of the test on net rings

8 Wire ring net properties (longitudinal tensile test with no lateral contraction

and load bearing capacity test)

Tensile strength and load bearing capacity tests are described in Annex B and Annex C.

Tensile strength and load bearing capacity tests are indications of product performance and quality.

The use of the results for design purposes shall be based on an engineering judgement in accordance

with the experience and the current practice and site conditions.
9 Sampling and testing
The manufacturer is responsible for the control of product quality.
4 © ISO 2016 – All rights reserved
---------------------- Page: 8 ----------------------
ISO 17745:2016(E)
10 Inspection and documentation

If agreed at the time of ordering, a certificate according to ISO 10474 shall be supplied containing the

following data:
— product description;
— manufacturer’s name and address;
— quantity of products supplied;
— wire coating (type and class);
— ma
...

Questions, Comments and Discussion

Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
