oSIST prEN IEC 60794-1-135:2025

Optical fibre cables - Part 1-135: Generic specification - Basic optical cable test procedures - Mechanical tests methods - Sheave test, Method E35

Lichtwellenleiterkabel – Teil 1-135: Fachgrundspezifikationen - Grundlegende Prüfverfahren für Lichtwellenleiterkabel - Mechanische Prüfverfahren - Seilscheibenprüfung, Verfahren E35

Câbles à fibres optiques - Partie 1-135: Spécification générique - Procédures fondamentales d’essais des câbles optiques - Méthodes d’essais mécaniques - Essai des poulies, Méthode E35

Optični kabli - 1-135. del: Splošna specifikacija - Osnovni preskusni postopki za optične kable - Mehanske preskusne metode - Preskus z jermenico, metoda E35

General Information

• Status: Not Published
• Public Enquiry End Date: 30-Oct-2025
• ICS: 33.180.10 - Fibres and cables
• Technical Committee: MOC - Mobile Communications
• Current Stage: 4020 - Public enquire (PE) (Adopted Project)
• Start Date: 18-Aug-2025
• Due Date: 05-Jan-2026
• Completion Date: 21-Oct-2025
• Ref Project: prEN IEC 60794-1-135:2025 - Optical fibre cables - Part 1-135: Generic specification - Basic optical cable test procedures - Mechanical tests methods - Sheave test, Method E35

Relations

• Splited From: SIST EN 60794-1-21:2015 - Optical fibre cables -- Part 1-21: Generic specification - Basic optical cable test procedures - Mechanical tests methods (IEC 60794-1-21:2015)
• Effective Date: 09-Sep-2025
• Splited From: SIST EN 60794-1-21:2015/A1:2020 - Optical fibre cables - Part 1-21: Generic specification - Basic optical cable test procedures - Mechanical tests methods (IEC 60794-1-21:2015/A1:2020)
• Effective Date: 09-Sep-2025

Overview

prEN IEC 60794-1-135:2025 - "Optical fibre cables - Part 1-135: Generic specification - Basic optical cable test procedures - Mechanical test methods - Sheave test, Method E35" defines a standardized sheave (pulley) bending test for aerial optical fibre cables. The method determines the ability of OPGW, OPPC, OPAC and ADSS cables to withstand bending over sheaves or bows under a specified load during installation. The document is part of the IEC 60794 series and replaces the earlier Method E18B in IEC 60794-1-21.

Key topics and technical requirements

• Test scope and objectives
  • Simulate bending stresses experienced during aerial installation to assess mechanical and optical performance.
• Two procedures
  • Procedure 1: Single sheave bend (specified radius R and bending angle θ). Typical angles: 30° for OPGW/OPPC; 45°±15° or 70° commonly used for ADSS.
  • Procedure 2: S–Z bend using three inline sheaves with fixed relative positions.
• Sample and marking
  • Samples taken from a finished cable end, terminated to apply load, marked at points A and B. Distance A–B ≥ three times maximum lay length for helically stranded cables.
• Apparatus
  • Tensile device (maximum error ±3 %).
  • Semi-circular sheave groove sized to allow free cable motion.
  • Optional optical test equipment per IEC 60793-1-46 (attenuation) and IEC 60793-1-22 (fibre elongation) when optical measurements are required.
• Procedure elements
  • Apply specified tension, cycle the cable between A and B (or move sheaves relative to cable), record number of cycles and speed as specified.
  • Measure attenuation before loading and after unloading (recommended rest ≥ 10 minutes unless otherwise specified).
  • If required, measure cable/metallic unit diameters and calculate ovality per IEC 60794-1-1.
• Pass/fail criteria
  • No visible sheath or element damage under unaided visual inspection.
  • Any permanent change in attenuation, fibre strain, or ovality must not exceed values specified in the relevant product specification.

Applications

• Used by manufacturers and test laboratories to qualify aerial cables for installation stresses.
• Guides acceptance testing for telecom utilities, power utilities (OPGW/OPPC), contractors, and network planners.
• Useful during product development, type approval, and quality control to ensure cables meet installation- and service-related bending requirements.

Who should use this standard

• Cable designers and manufacturers
• Independent testing laboratories
• Telecom and power utility specification writers
• Field installation engineers and qualification teams

Related standards

• IEC 60794-1-1 (general terms and requirements)
• IEC 60794-1-2 (test guidance and atmospheric conditions)
• IEC 60793-1-22 (fibre length/elongation measurement)
• IEC 60793-1-46 (attenuation monitoring)

Keywords: prEN IEC 60794-1-135:2025, sheave test, optical fibre cables, OPGW, OPPC, ADSS, mechanical test, attenuation, ovality, bending test.

Standards Content (Sample)

SLOVENSKI STANDARD
01-oktober-2025
Optični kabli - 1-135. del: Splošna specifikacija - Osnovni preskusni postopki za
optične kable - Mehanske preskusne metode - Preskus z jermenico, metoda E35
Optical fibre cables - Part 1-135: Generic specification - Basic optical cable test
procedures - Mechanical tests methods - Sheave test, Method E35
Câbles à fibres optiques - Partie 1-135: Spécification générique - Procédures
fondamentales d’essais des câbles optiques - Méthodes d’essais mécaniques - Essai
des poulies, Méthode E35
Ta slovenski standard je istoveten z: prEN IEC 60794-1-135:2025
ICS:
33.180.10 (Optična) vlakna in kabli Fibres and cables
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

86A/2601/CDV
COMMITTEE DRAFT FOR VOTE (CDV)
PROJECT NUMBER:
IEC 60794-1-135 ED1
DATE OF CIRCULATION: CLOSING DATE FOR VOTING:
2025-08-08 2025-10-31
SUPERSEDES DOCUMENTS:
86A/2454/CD, 86A/2598/CC
IEC SC 86A : FIBRES AND CABLES
SECRETARIAT: SECRETARY:
France Mr Laurent Gasca
OF INTEREST TO THE FOLLOWING COMMITTEES: HORIZONTAL FUNCTION(S):

ASPECTS CONCERNED:
SUBMITTED FOR CENELEC PARALLEL VOTING NOT SUBMITTED FOR CENELEC PARALLEL VOTING
Attention IEC-CENELEC parallel voting
The attention of IEC National Committees,
members of CENELEC, is drawn to the fact that
this Committee Draft for Vote (CDV) is submitted
for parallel voting.
The CENELEC members are invited to vote
through the CENELEC online voting system.

This document is still under study and subject to change. It should not be used for reference purposes.
