ETSI EN 300 162-2 V1.2.1 (2006-12)
Harmonized European Standard (Telecommunications series)
Electromagnetic compatibility
and Radio spectrum Matters (ERM);
Radiotelephone transmitters and receivers for
the maritime mobile service operating in VHF bands;
Part 2: Harmonized EN covering essential requirements
of article 3.2 of the R&TTE Directive
---------------------- Page: 3 ----------------------
SIST EN 300 162-2 V1.2.1:2007
2 ETSI EN 300 162-2 V1.2.1 (2006-12)
Reference
REN/ERM-TG26-073-2
Keywords
EMC, GMDSS, maritime, radio, regulation,
telephony, VHF
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE
Tel.: +33 4 92 94 42 00 Fax: +33 4 93 65 47 16
Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88
Important notice
Individual copies of the present document can be downloaded from:
http://www.etsi.org
The present document may be made available in more than one electronic version or in print. In any case of existing or
perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF).
In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive
within ETSI Secretariat.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
http://portal.etsi.org/tb/status/status.asp
If you find errors in the present document, please send your comment to one of the following services:
http://portal.etsi.org/chaircor/ETSI_support.asp
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.
© European Telecommunications Standards Institute 2006.
All rights reserved.
TM TM TM
DECT , PLUGTESTS and UMTS are Trade Marks of ETSI registered for the benefit of its Members.
TM
TIPHON and the TIPHON logo are Trade Marks currently being registered by ETSI for the benefit of its Members.
TM
3GPP is a Trade Mark of ETSI registered for the benefit of its Members and of the 3GPP Organizational Partners.
ETSI
---------------------- Page: 4 ----------------------
SIST EN 300 162-2 V1.2.1:2007
3 ETSI EN 300 162-2 V1.2.1 (2006-12)
Contents
Intellectual Property Rights.5
Foreword.5
1 Scope.6
2 References.6
3 Definitions and abbreviations.7
3.1 Definitions.7
3.2 Abbreviations.7
4 Technical requirements specifications.7
4.1 Environmental profile.7
4.2 Conformance requirements.7
4.2.1 Frequency error.7
4.2.1.1 Definition.7
4.2.1.2 Limit.7
4.2.1.3 Conformance.7
4.2.2 Carrier power.8
4.2.2.1 Definition.8
4.2.2.2 Limit.8
4.2.2.3 Conformance.8
4.2.3 Frequency deviation.8
4.2.3.1 Definition.8
4.2.3.2 Limit.8
4.2.3.3 Conformance.8
4.2.4 Adjacent channel power.8
4.2.4.1 Definition.8
4.2.4.2 Limit.8
4.2.4.3 Conformance.8
4.2.5 Conducted spurious emissions conveyed to the antenna .8
4.2.5.1 Definition.8
4.2.5.2 Limit.8
4.2.5.3 Conformance.8
4.2.6 Cabinet radiation and conducted spurious emissions other than those conveyed to the antenna.9
4.2.6.1 Definition.9
4.2.6.2 Limit.9
4.2.6.3 Conformance.9
4.2.7 Transient frequency behaviour of the transmitter .9
4.2.7.1 Definition.9
4.2.7.2 Limit.9
4.2.7.3 Conformance.9
4.2.8 Maximum usable sensitivity.9
4.2.8.1 Definition.9
4.2.8.2 Limit.9
4.2.8.3 Conformance.9
4.2.9 Co-channel rejection.9
4.2.9.1 Definition.9
4.2.9.2 Limit.9
4.2.9.3 Conformance.10
4.2.10 Adjacent channel selectivity .10
4.2.10.1 Definition.10
4.2.10.2 Limit.10
4.2.10.3 Conformance.10
4.2.11 Spurious response rejection .10
4.2.11.1 Definition.10
4.2.11.2 Limit.10
4.2.11.3 Conformance.10
ETSI
---------------------- Page: 5 ----------------------
SIST EN 300 162-2 V1.2.1:2007
4 ETSI EN 300 162-2 V1.2.1 (2006-12)
4.2.12 Intermodulation response.10
4.2.12.1 Definition.10
4.2.12.2 Limit.10
4.2.12.3 Conformance.10
4.2.13 Blocking or desensitization.10
4.2.13.1 Definition.10
4.2.13.2 Limit.10
4.2.13.3 Conformance.11
4.2.14 Receiver conducted spurious emissions.11
4.2.14.1 Definition.11
4.2.14.2 Limit.11
4.2.14.3 Conformance.11
4.2.15 Receiver radiated spurious emissions .11
4.2.15.1 Definition.11
4.2.15.2 Limit.11
4.2.15.3 Conformance.11
4.2.16 Receiver desensitization with simultaneous transmission and reception (Equipment designed for
duplex operation) .11
4.2.16.1 Definition.11
4.2.16.2 Limit.11
4.2.16.3 Conformance.11
5 Testing for compliance with technical requirements.12
5.1 Test conditions, power supply and ambient temperatures.12
5.2 Interpretation of the measurement results .12
5.3 Essential radio test suites.13
5.3.1 Frequency error.13
5.3.2 Carrier power.13
5.3.3 Frequency deviation.13
5.3.4 Adjacent channel power.13
5.3.5 Conducted spurious emissions conveyed to the antenna .13
5.3.6 Cabinet radiation and conducted spurious emissions other than those conveyed to the antenna.13
5.3.7 Transient frequency behaviour of the transmitter .13
5.4 Other test specifications.13
5.4.1 General.13
5.4.2 Maximum usable sensitivity.13
5.4.3 Co-channel rejection.13
5.4.4 Adjacent channel selectivity .14
5.4.5 Spurious response rejection .14
5.4.6 Intermodulation response.14
5.4.7 Blocking or desensitization.14
5.4.8 Receiver conducted spurious emissions.14
5.4.9 Receiver radiated spurious emissions .14
5.4.10 Receiver desensitization with simultaneous transmission and reception (Duplex operation).14
Annex A (normative): HS Requirements & conformance Test specifications Table (HS-
RTT).15
Annex B (informative): The EN title in the official languages .18
Annex C (informative): Bibliography.20
History .21
ETSI
---------------------- Page: 6 ----------------------
SIST EN 300 162-2 V1.2.1:2007
5 ETSI EN 300 162-2 V1.2.1 (2006-12)
Intellectual Property Rights
IPRs essential or potentially essential to the present document may have been declared to ETSI. The information
pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found
in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in
respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web
server (http://webapp.etsi.org/IPR/home.asp).
Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee
can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web
server) which are, or may be, or may become, essential to the present document.
Foreword
This Harmonized European Standard (Telecommunications series) has been produced by ETSI Technical Committee
Electromagnetic compatibility and Radio spectrum Matters (ERM).
The present document has been produced by ETSI in response to a mandate from the European Commission issued
under Council Directive 98/34/EC (as amended) [4] laying down a procedure for the provision of information in the
field of technical standards and regulations.
The present document is intended to become a Harmonized Standard, the reference of which will be published in the
Official Journal of the European Communities referencing the Directive 1999/5/EC [1] of the European Parliament and
of the Council of 9 March 1999 on radio equipment and telecommunications terminal equipment and the mutual
recognition of their conformity ("the R&TTE Directive").
Technical specifications relevant to Directive 1999/5/EC [1] are given in annex A.
The present document is part 2 of a multi-part deliverable covering the radiotelephone transmitters and receivers for the
maritime mobile service operating in VHF bands, as identified below:
Part 1: "Technical characteristics and methods of measurement";
Part 2: "Harmonized EN covering essential requirements of article 3.2 of the R&TTE Directive";
Part 3: "Harmonized EN covering essential requirements of article 3.3 (e) of the R&TTE Directive".
National transposition dates
Date of adoption of this EN: 17 November 2006
Date of latest announcement of this EN (doa): 28 February 2007
Date of latest publication of new National Standard
or endorsement of this EN (dop/e): 31 August 2007
Date of withdrawal of any conflicting National Standard (dow): 31 August 2008
ETSI
---------------------- Page: 7 ----------------------
SIST EN 300 162-2 V1.2.1:2007
6 ETSI EN 300 162-2 V1.2.1 (2006-12)
1 Scope
The present document applies to shipborne Very High Frequency (VHF) transmitters and receivers capable of voice and
Digital Selective Calling (DSC), radio equipment.
The present document lays down minimum requirements for VHF radio transmitters and receivers operating in certain
frequency bands allocated to the maritime mobile service using both 25 kHz and 12,5 kHz channels, and incorporates
the requirements of the relevant recommendations of the International Maritime Organization (IMO).
The present document is intended to cover the provisions of Directive 1999/5/EC [1] (R&TTE Directive) Article 3.2,
which states that "…. radio equipment shall be so constructed that it effectively uses the spectrum allocated to
terrestrial/space radio communications and orbital resources so as to avoid harmful interference".
In addition to the present document, other ENs that specify technical requirements in respect of essential requirements
under other parts of Article 3 of the R&TTE Directive [1] may apply to equipment within the scope of the present
document.
2 References
The following documents contain provisions which, through reference in this text, constitute provisions of the present
document.
• References are either specific (identified by date of publication and/or edition number or version number) or
non-specific.
• For a specific reference, subsequent revisions do not apply.
• For a non-specific reference, the latest version applies.
Referenced documents which are not found to be publicly available in the expected location might be found at
http://docbox.etsi.org/Reference.
NOTE: While any hyperlinks included in this clause were valid at the time of publication ETSI cannot guarantee
their long term validity.
[1] Directive 1999/5/EC of the European Parliament and of the Council of 9 March 1999 on radio
equipment and telecommunications terminal equipment and the mutual recognition of their
conformity (R&TTE Directive).
[2] ETSI EN 300 162-1 (V1.4.1): "Electromagnetic compatibility and Radio spectrum Matters (ERM);
Radiotelephone transmitters and receivers for the maritime mobile service operating in VHF
bands; Part 1: Technical characteristics and methods of measurement".
[3] ETSI TR 100 028-1 (V1.4.1): "Electromagnetic compatibility and Radio spectrum Matters (ERM);
Uncertainties in the measurement of mobile radio equipment characteristics; Part 1".
[4] Directive 98/34/EC of the European Parliament and of the Council of 22 June 1998 laying down a
procedure for the provision of information in the field of technical standards and regulations.
[5] Commission Decision of 4 September 2003 on essential requirements relating to marine radio
communication equipment which is intended to be used on non-SOLAS vessels and to participate
in the Global Maritime Distress and Safety System (GMDSS) (2004/71/EC).
ETSI
---------------------- Page: 8 ----------------------
SIST EN 300 162-2 V1.2.1:2007
7 ETSI EN 300 162-2 V1.2.1 (2006-12)
3 Definitions and abbreviations
3.1 Definitions
For the purposes of the present document, the terms and definitions given in the R&TTE Directive [1] and the following
apply:
environmental profile: range of environmental conditions under which equipment within the scope of the present
document is required to comply with the provisions of the present document
3.2 Abbreviations
For the purposes of the present document, the following abbreviations apply:
DSC Digital Selective Calling
EMC Electro-Magnetic Compatibility
HS Harmonized Standard
LV Low Voltage
R&TTE Radio and Telecommunications Terminal Equipment
VHF Very High Frequency
4 Technical requirements specifications
4.1 Environmental profile
Tests defined in the present document shall be carried out at representative points within the boundary limits of the
declared operational environmental profile which, as a minimum, shall be that specified in the test conditions contained
in the present document.
As technical performance varies subject to environmental conditions, tests shall be carried out under a sufficient variety
of environmental conditions as specified in the present document to give confidence of compliance for the affected
technical requirements. These environmental conditions represent those required by Article 2 of EC decision
2004/71/EC [5] (which shall also be within the boundary limits of the declared operational environmental profile).
4.2 Conformance requirements
4.2.1 Frequency error
4.2.1.1 Definition
The frequency error is defined in EN 300 162-1 [2], clause 8.1.1.
4.2.1.2 Limit
The frequency error limit shall be as stated in EN 300 162-1 [2], clause 8.1.3.
4.2.1.3 Conformance
Conformance tests as defined in clause 5.3.1 shall be carried out.
ETSI
---------------------- Page: 9 ----------------------
SIST EN 300 162-2 V1.2.1:2007
8 ETSI EN 300 162-2 V1.2.1 (2006-12)
4.2.2 Carrier power
4.2.2.1 Definition
The carrier power is defined in EN 300 162-1 [2], clause 8.2.1.
4.2.2.2 Limit
The carrier power limit shall be as stated in EN 300 162-1 [2], clause 8.2.3.
4.2.2.3 Conformance
Conformance tests as defined in clause 5.3.2 shall be carried out.
4.2.3 Frequency deviation
4.2.3.1 Definition
The frequency deviation is defined in EN 300 162-1 [2], clause 8.3.1.
4.2.3.2 Limit
The frequency deviation limit shall be as stated in EN 300 162-1 [2], clauses 8.3.2.2 and 8.3.3.2.
4.2.3.3 Conformance
Conformance tests as defined in clause 5.3.3 shall be carried out.
4.2.4 Adjacent channel power
4.2.4.1 Definition
The adjacent channel power is defined in EN 300 162-1 [2], clause 8.7.1.
4.2.4.2 Limit
The adjacent channel power limit shall be as stated in EN 300 162-1 [2], clause 8.7.3.
4.2.4.3 Conformance
Conformance tests as defined in clause 5.3.4 shall be carried out.
4.2.5 Conducted spurious emissions conveyed to the antenna
4.2.5.1 Definition
The conducted spurious emissions conveyed to the antenna is defined in EN 300 162-1 [2], clause 8.8.1.
4.2.5.2 Limit
The conducted spurious emissions conveyed to the antenna limit shall be as stated in EN 300 162-1 [2], clause 8.8.3.
4.2.5.3 Conformance
Conformance tests as defined in clause 5.3.5 shall be carried out.
ETSI
---------------------- Page: 10 ----------------------
SIST EN 300 162-2 V1.2.1:2007
9 ETSI EN 300 162-2 V1.2.1 (2006-12)
4.2.6 Cabinet radiation and conducted spurious emissions other than
those conveyed to the antenna
4.2.6.1 Definition
The cabinet radiation and conducted spurious emissions other than those conveyed to the antenna is defined in
EN 300 162-1 [2], clause 8.9.1.
4.2.6.2 Limit
The cabinet radiation and conducted spurious emissions other than those conveyed to the antenna limit shall be as stated
in EN 300 162-1 [2], clause 8.9.3.
4.2.6.3 Conformance
Conformance tests as defined in clause 5.3.6 shall be carried out.
4.2.7 Transient frequency behaviour of the transmitter
4.2.7.1 Definition
The transient frequency behaviour of the transmitter is defined in EN 300 162-1 [2], clause 8.14.1.
4.2.7.2 Limit
The transient frequency behaviour of the transmitter limit shall be as stated in EN 300 162-1 [2], clause 8.14.3.
4.2.7.3 Conformance
Confo
...
Questions, Comments and Discussion
Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
