EUROPEAN STANDARD EN IEC 63522-37
NORME EUROPÉENNE
EUROPÄISCHE NORM June 2025
ICS 29.120.70
English Version
Electrical relays - Tests and measurements - Part 37: Terminal
temperature rise at rated load
(IEC 63522-37:2025)
Relais électriques - Essais et mesurages - Partie 37: Elektrische Relais - Mess- und Prüfverfahren - Teil 37:
Échauffement des bornes à la charge assignée Klemmentemperaturanstieg bei Nennlast
(IEC 63522-37:2025) (IEC 63522-37:2025)
This European Standard was approved by CENELEC on 2025-05-28. CENELEC members are bound to comply with the CEN/CENELEC
Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration.
Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC
Management Centre or to any CENELEC member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation
under the responsibility of a CENELEC member into its own language and notified to the CEN-CENELEC Management Centre has the
same status as the official versions.
CENELEC members are the national electrotechnical committees of Austria, Belgium, Bulgaria, Croatia, Cyprus, the Czech Republic,
Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, the
Netherlands, Norway, Poland, Portugal, Republic of North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland,
Türkiye and the United Kingdom.
European Committee for Electrotechnical Standardization
Comité Européen de Normalisation Electrotechnique
Europäisches Komitee für Elektrotechnische Normung
CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels
© 2025 CENELEC All rights of exploitation in any form and by any means reserved worldwide for CENELEC Members.
Ref. No. EN IEC 63522-37:2025 E
European foreword
The text of document 94/1131/FDIS, future edition 1 of IEC 63522-37, prepared by TC 94 "Electrical
relays" was submitted to the IEC-CENELEC parallel vote and approved by CENELEC as
The following dates are fixed:
• latest date by which the document has to be implemented at national (dop) 2026-06-30
level by publication of an identical national standard or by endorsement
• latest date by which the national standards conflicting with the (dow) 2028-06-30
document have to be withdrawn
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. CENELEC shall not be held responsible for identifying any or all such patent rights.
This document is read in conjunction with EN 63522-0:– .
Any feedback and questions on this document should be directed to the users’ national committee. A
complete listing of these bodies can be found on the CENELEC website.
Endorsement notice
The text of the International Standard IEC 63522-37:2025 was approved by CENELEC as a European
Standard without any modification.
In the official version, for Bibliography, the following notes have to be added for the standard indicated:
IEC 60664-1 NOTE Approved as EN IEC 60664-1
IEC 61810-7:2006 NOTE Approved as EN 61810-7:2006 (not modified)
Under preparation: Stage at the time of publication: prEN IEC 63522-0:2024.
Annex ZA
(normative)
Normative references to international publications
with their corresponding European publications
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments)
applies.
NOTE 1 Where an International Publication has been modified by common modifications, indicated by (mod),
the relevant EN/HD applies.
NOTE 2 Up-to-date information on the latest versions of the European Standards listed in this annex is available
here: www.cencenelec.eu.
Publication Year Title EN/HD Year
IEC 60584-1 - Thermocouples - Part 1: EMF EN 60584-1 -
specifications and tolerances
IEC 60998-1 - Connecting devices for low-voltage circuits EN 60998-1 -
for household and similar purposes - Part
1: General requirements
IEC 60999-1 - Connecting devices - Electrical copper EN 60999-1 -
conductors - Safety requirements for
screw-type and screwless-type clamping
units - Part 1: General requirements and
particular requirements for clamping units
for conductors from 0,2 mm2 up to 35 mm2
(included)
IEC 61810-1 2015 Electromechanical elementary relays - Part EN 61810-1 2015
1: General and safety requirements
2 3
IEC 63522-0 — Electrical relays - Tests and Measurements EN IEC 63522-0 —
- Part 0: General and Guidance
IEC 63522-7 - Electrical relays - Tests and measurements EN IEC 63522-7 -
- Part 7: Functional tests
Under preparation: Stage at the time of publication: IEC CDV 63522-0:2024.
Under preparation: Stage at the time of publication: prEN IEC 63522-0:2024.
IEC 63522-37 ®
Edition 1.0 2025-04
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
Electrical relays – Tests and measurements –
Part 37: Terminal temperature rise at rated load
Relais électriques – Essais et mesurages –
Partie 37: Échauffement des bornes à la charge assignée
INTERNATIONAL
ELECTROTECHNICAL
COMMISSION
COMMISSION
ELECTROTECHNIQUE
INTERNATIONALE
ICS 29.120.70 ISBN 978-2-8327-0359-5
