SIST EN 16068:2012

Packaging - Rigid plastic containers - PET finish 38

This European Standard specifies the dimensions of the 38 mm screw finish with three (3) thread starts for flat waters and non-carbonated beverages.
This finish can be used for aseptic filling and filling with introduction of nitrogen (0,7 bar max.).
This finish is designed to take a tamper evident plastic closure only. During first opening, the tamper evident band will separate from the closure shell and stay on a one way bottle neck or like bottles in the returnable market, the tamper evident band will tear but will remain connected to the closure shell.
This finish is for non crystallized necks only.

Verpackung - Kunststoffbehältnisse - PET-Verschlussmundstück 38

Diese Europäische Norm legt die Maße und Anforderungen für ein 38-mm-Schraubverschlussmundstück mit drei (3) Gewinde¬gängen für stilles Wasser und kohlensäurefreie Getränke fest.
Dieses Verschlussmundstück kann zur aseptischen Befüllung und zur Befüllung mit Stickstoffeinleitung (höchstens 0,7 bar) verwendet werden.
Dieses Verschlussmundstück ist dafür ausgelegt, ausschließlich Kunststoffverschlüsse mit Originalitäts-sicherung aufzunehmen. Während des ersten Öffnens wird das Originalitätssicherungsband von der Verschlusskappe getrennt und bleibt bei einer Einwegflasche auf dem Flaschenhals zurück oder es reißt bei Mehrwegflaschen, bleibt aber mit der Verschlusskappe verbunden.
Dieses Verschlussmundstück ist ausschließlich für nicht kristallisierte Hälse bestimmt.

Emballage - Récipients en plastique rigide - Bague PET 38

La présente Norme européenne définit les dimensions de la bague à vis de 38 mm à trois (3) filets pour le bouchage des eaux plates et boissons non carbonatées.
La bague peut être utilisée pour le conditionnement en milieu aseptique et/ou avec injection d'azote (0,7 bar max.).
Cette bague est prévue pour recevoir uniquement une capsule plastique avec témoin d’inviolabilité, ou bande de garantie. Lors de la première ouverture, soit le témoin d’inviolabilité se déchirera et restera sur la bouteille, dans le cas d'utilisation d'une bouteille jetable, soit le témoin d’inviolabilité se déchirera mais restera solidaire de la capsule, dans le cas des bouteilles retournables.
Cette bague est prévue seulement pour les cols non cristallisés.

Embalaža - Toge plastične posode - PET-grla 38

Ta dokument določa mere za navojno grlo s premerom 30 mm in trojnim začetkom navoja za negazirano vodo in negazirane napitke. To grlo se lahko uporablja za aseptično polnjenje in polnjenje z dodajanjem dušika (največ 0,7 bara). Grlu se lahko doda le plastičen čep, ki varuje pred nedovoljenim odpiranjem. Pri prvem odpiranju se obroček, ki varuje pred nedovoljenim odpiranjem, loči od lupine čepa in ostane na grlu steklenice ali pa se, kot pri povratnih steklenicah, pretrga, vendar ostane pritrjen na lupino čepa. To grlo se uporablja le za nekristalizirane vratove steklenic.

General Information

• Status: Published
• Public Enquiry End Date: 19-Jun-2010
• Publication Date: 17-Jan-2012
• ICS: 55.100 - Bottles. Pots. Jars
• Technical Committee: EPO - Packaging - sales and grouped
• Current Stage: 6060 - National Implementation/Publication (Adopted Project)
• Start Date: 17-Jan-2012
• Due Date: 23-Mar-2012
• Completion Date: 18-Jan-2012
• Ref Project: EN 16068:2011 - Packaging - Rigid plastic containers - PET finish 38

Overview

EN 16068:2011 is a CEN European standard that defines the 38 mm PET screw finish (three thread starts) for rigid plastic containers used for flat waters and non‑carbonated beverages. Prepared by CEN/TC 261 (secretariat AFNOR) and based on CETIE data sheet GME 30.25, this standard specifies finish geometry, tolerances and performance requirements for use with tamper‑evident plastic closures and for filling processes including aseptic filling and nitrogen introduction (up to 0.7 bar).

Key topics and technical requirements

• Finish type: 38 mm screw finish with three (3) thread starts, 120° apart.
• Thread geometry: 180° of full depth thread per lead; lead (travel per turn) = 9 mm.
• Thread lead‑in / run‑out radii: R 7.5 mm.
• Tolerances: general radii tolerance ±0.05 mm.
• Weights (height 16.5 mm, density 1.335):
  • ØZ = 41.0 mm → Weight 4.18 g
  • ØZ = 44.0 mm → Weight 4.57 g
• Sealing and surface requirements:
  • Finish is a top, side and inside seal; surface must be smooth and free of defects that cause leaks.
  • Flash must not exceed 0.13 mm per side and shall not be continuous.
  • Control diameter C must be free of defects up to 4 mm down the internal bore and across the sealing surface.
  • Out‑of‑parallel sealing surface may be up to 0.13 mm with neck support ledge.
  • Thread offset / vertical mismatch at mould seam ≤ 0.10 mm.
  • ØT not measured in depressed area; variations in ØE should uniformly follow ØT.
• Use limitations: For non‑crystallized necks only; designed to accept tamper‑evident plastic closures. On first opening the tamper band separates from the closure shell (stays on one‑way bottles or tears but remains attached in returnables).

Applications and who uses it

EN 16068:2011 is used in the design, manufacture and quality control of PET bottles and closures for:

• Beverage bottlers (flat water, non‑carbonated drinks)
• Closure and cap manufacturers (design and compatibility checks)
• Blow‑moulder and injection mould designers (mould seams, thread form)
• Filling line and aseptic process engineers (closure sealing, N2 filling up to 0.7 bar)
• Quality assurance and regulatory teams ensuring compliance with European packaging standards

Related standards

• Based on CETIE data sheet GME 30.25 (PET finish 38 – 2009).
• Published by CEN - see CEN/TC 261 packaging committee for related container and closure standards.

Keywords: EN 16068:2011, PET finish 38, 38 mm screw finish, packaging standard, tamper evident closure, aseptic filling, rigid plastic containers, PET bottle neck dimensions.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Verpackung - Kunststoffbehältnisse - PET-Verschlussmundstück 38Emballage - Récipients en plastique rigide - Bague PET 38Packaging - Rigid plastic containers - PET finish 3855.100Steklenice. Lonci. KozarciBottles. Pots. JarsICS:Ta slovenski standard je istoveten z:EN 16068:2011SIST EN 16068:2012en,fr,de01-marec-2012SIST EN 16068:2012SLOVENSKI
STANDARD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 16068
November 2011 ICS 55.100 English Version
Packaging - Rigid plastic containers - PET finish 38
Emballage - Récipients en plastique rigide - Bague PET 38 Verpackung - Kunststoffbehältnisse - PET-Verschlussmundstück 38 This European Standard was approved by CEN on 29 October 2011.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2011 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 16068:2011: ESIST EN 16068:2012
...
