VHF air-ground Digital Link (VDL) Mode 4 radio equipment - Technical characteristics and methods of measurement for ground-based equipment - Part 5: Harmonised Standard covering the essential requirements of article 3.2 of the Directive 2014/53/EU

The present document applies to Very High Frequency (VHF) Digital Link (VDL) Mode 4 ground-based radio
transmitters and receivers for air-ground communications operating in the VHF band, using Gaussian-filtered
Frequency Shift Keying (GFSK) Modulation with 25 kHz channel spacing and capable of tuning to any of the 25 kHz
channels from 112,000 MHz to 136,975 MHz as defined in ICAO VHF Digital Link (VDL) Standards and
Recommended Practices (SARPs) [i.5].
Manufacturers should note that in future the tuning range for the ground transceivers may also cover any 25 kHz
channel from 108,000 MHz to 111,975 MHz.
The present document contains requirements to demonstrate that "... Radio equipment shall be so constructed that it
both effectively uses and supports the efficient use of radio spectrum in order to avoid harmful interference" [i.2].
In addition to the present document, other ENs that specify technical requirements in respect of essential requirements
under other parts of Article 3 of the Directive 2014/53/EU [i.2] as well as essential requirements under the Single
European Sky Interoperability Regulation 552/2004 [i.10] and related implementing rules and/or essential requirements
under the EASA basic regulation No 216/2008 [i.3] as amended by Regulation No 1108/2009 [i.4] may apply to
equipment within the scope of the present document.

Radijska oprema za digitalno povezavo VHF zrak-tla, 4. način - Tehnične karakteristike in merilne metode za talno opremo - 5. del: Harmonizirani standard, ki zajema bistvene zahteve člena 3.2 direktive 2014/53/EU

Ta dokument se uporablja za talne radijske oddajnike in sprejemnike za zelo visokofrekvenčno (VHF) digitalno povezavo (VDL) za komunikacije zrak-tla, 4. način, ki delujejo v pasu VHF z uporabo modulacije frekvenčnega premičnega kodiranja prek filtra Gaussian (GFSK) z razmikom 25 kHz med kanali in so zmožni uravnavati na katerem koli izmed kanalov 25 kHz
od 112,000 MHz do 136,975 MHz, kot je opredeljeno v standardih in priporočenih praksah (SARP) [i.5] za digitalne povezave ICAO VHF.
Proizvajalci naj upoštevajo, da lahko razpon uravnavanja za talne oddajnike-sprejemnike v prihodnje zajema tudi kateri koli kanal 25 kHz od 108,000 MHz do 111,975 MHz.
Ta dokument vsebuje zahteve, s katerimi se dokazuje, da »... mora biti radijska oprema sestavljena tako, da učinkovito uporablja in tudi podpira učinkovito rabo radijskega spektra z namenom preprečevanja škodljivih motenj« [i.2].
Poleg tega dokumenta se za opremo na področju uporabe tega dokumenta uporabljajo tudi drugi standardi EN, ki določajo tehnične zahteve v zvezi z bistvenimi zahtevami iz drugih delov člena 3 direktive 2014/53/EU [i.2], ter tudi bistvene zahteve iz uredbe o interoperabilnosti enotnega evropskega neba 552/2004 [i.10] in zadevna izvedbena pravila in/ali bistvene zahteve iz uredbe EASA št. 216/2008 [i.3], kakor je bila spremenjena z uredbo št. 1108/2009 [i.4].
