Methods for Testing and Specification (MTS) - The Testing and Test Control Notation version 3 - Part 1: TTCN-3 Core Language

The present document defines the Core Language of TTCN-3. TTCN-3 can be used for the specification of all types of
reactive system tests over a variety of communication ports. Typical areas of application are protocol testing (including
mobile and Internet protocols), service testing (including supplementary services), module testing, testing of CORBA®
based platforms, APIs, etc. TTCN-3 is not restricted to conformance testing and can be used for many other kinds of
testing including interoperability, robustness, regression, system and integration testing. The specification of test suites
for physical layer protocols is outside the scope of the present document.
TTCN-3 is intended to be used for the specification of test suites which are independent of test methods, layers and
protocols. In addition to the textual format defined in the present document, while GFT (ETSI ES 201 873-3 [i.2])
defines a graphical presentation format for TTCN-3. The specification of these formats is outside the scope of the
present document.
While the design of TTCN-3 has taken the eventual implementation of TTCN-3 translators and compilers into
consideration the means of realization of Executable Test Suites (ETS) from Abstract Test Suites (ATS) is outside the
scope of the present document.

Metode za preskušanje in specificiranje (MTS) - 3. različica zapisa preskušanja in krmiljenja preskusov - 1. del: Jedrni jezik TTCN-3

Ta dokument določa jedrni jezik TTCN-3. TTCN-3 je mogoče uporabiti za specificiranje vseh vrst reaktivnih sistemskih preskusov v okviru različnih komunikacijskih vrat. Običajna področja uporabe so preskušanje protokolov (vključno z mobilnimi in internetnimi protokoli), preskušanje storitev (vključno z dopolnilnimi storitvami), preskušanje modulov, preskušanje platform na osnovi CORBA®, programski vmesniki (API) itd. TTCN-3 ni omejen na preskušanje skladnosti in se lahko uporabi za številne druge vrste preskušanja, vključno s preskušanjem interoperabilnosti, robustnosti, regresije, sistema in integracije. Specificiranje preskuševalnih nizov za protokole fizične plasti ne spada v področje uporabe tega dokumenta.
TTCN-3 je namenjen uporabi za specificiranje preskuševalnih nizov, ki so neodvisni od preskusnih metod, plasti in protokolov. Poleg besedilnega formata, ki je opredeljen v tem dokumentu, standard GFT (ETSI ES 201 873-3 [i.2]) določa format grafične predstavitve jezika TTCN-3. Specificiranje teh formatov ne spada na področje uporabe tega dokumenta.
Zasnova jezika TTCN-3 upošteva postopno uvedbo prevajalnikov TTCN-3, vendar pa realizacija izvršljivih preskuševalnih nizov (ETS) iz abstraktnih preskuševalnih nizov (ATS) ne spada na področje uporabe tega dokumenta.

General Information

Status
Published
Publication Date
28-May-2019
Current Stage
6060 - National Implementation/Publication (Adopted Project)
Start Date
16-May-2019
Due Date
21-Jul-2019
Completion Date
29-May-2019

Buy Standard

Standard
ETSI ES 201 873-1 V4.11.1 (2019-04) - Methods for Testing and Specification (MTS); The Testing and Test Control Notation version 3; Part 1: TTCN-3 Core Language
English language
367 pages
sale 15% off
Preview
sale 15% off
Preview
Standard
ETSI ES 201 873-1 V4.11.1 (2019-02) - Methods for Testing and Specification (MTS); The Testing and Test Control Notation version 3; Part 1: TTCN-3 Core Language
English language
368 pages
sale 15% off
Preview
sale 15% off
Preview
Standardization document
ES 201 873-1 V4.11.1:2019
English language
367 pages
sale 10% off
Preview
sale 10% off
Preview
e-Library read for
1 day

Standards Content (Sample)

ETSI ES 201 873-1 V4.11.1 (2019-04)






ETSI STANDARD
Methods for Testing and Specification (MTS);
The Testing and Test Control Notation version 3;
Part 1: TTCN-3 Core Language
