IMT cellular networks; Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive - Part 18: E-UTRA, UTRA and GSM/EDGE Multi-Standard Radio (MSR) Base Station (BS)

The present document applies to the following radio equipment type:
• Multi-Standard Radio capable Base stations (E-UTRA, UTRA, GSM/EDGE).
These radio equipment types are capable of operating in all or any part of the frequency bands given in table 1-1.
The present document covers requirements for multi-RAT capable E-UTRA, UTRA and GSM/EDGE MSR Base Stations for Release 9.
The present document is intended to cover the provisions of Directive 1999/5/EC [i.2] (R&TTE Directive), article 3.2, which states that "….. radio equipment shall be so constructed that it effectively uses the spectrum allocated to terrestrial/space radio communications and orbital resources so as to avoid harmful interference".
In addition to the present document, other ENs that specify technical requirements in respect of essential requirements under other parts of article 3 of the R&TTE Directive may apply to equipment within the scope of the present document.

Celična omrežja IMT - Harmonizirani EN, ki zajema bistvene zahteve člena 3.2 direktive R&TTE - 18. del: Multi-Standard Radio (E-UTRA, UTRA in GSM/EDGE) bazne postaje (BS)

Ta dokument velja za naslednjo vrsto radijske opreme:
• Multi-Standard radio (E-UTRA, UTRA, GSM/EDGE) zmožne bazne postaje.
Te vrste radijske opreme so zmožne delovati v vseh ali katerem koli delu frekvenčnega pasu, kot so navedeni v preglednici 1-1.
Ta dokument zajema zahteve zmožne bazne postaje za multi-RAT E-UTRA, UTRA in GSM/EDGE za izdajo 9.
Ta dokument zajema določbe člena 3.2. Direktive 1999/5/ES [i.2] (direktive R&TTE), ki navaja, da » … radijska oprema je narejena tako, da učinkovito izrablja spekter, razporejen za prizemne/vesoljske radiokomunikacije in orbitalne vire, tako da ne pride do škodljivega motenja«.
Poleg tega dokumenta se preostali EN, ki določajo tehnične zahteve v skladu z bistvenimi zahtevami v drugih delih člena 3 direktive R&TTE, lahko uporabljajo za opremo v okviru uporabe tega dokumenta.
