Overview

EN IEC 63203-201-2:2022 (CLC / CENELEC adoption of IEC 63203-201-2:2022) is a measurement-methods standard for electronic textiles (e-textiles). It specifies how to measure the basic general and electrical properties of conductive fabrics and insulation materials used in clothes‑type wearable electronic devices. The document defines test methods for materials that serve as conductive traces, electrodes and similar functional elements in wearables. It does not cover high-resistance conductive fabrics for antistatic uses or heating applications, and it does not prescribe pass/fail material requirements - only standardized measurement procedures.

Key topics

• Material scope and classification
  • Classification of conductive fabrics and of electrical insulation materials used in e-textiles.
• Environmental conditioning
  • Atmospheric conditions and specimen conditioning required before testing (standardized pre-conditioning).
• Electrical properties (primary focus)
  • Sheet resistance measurement for conductive tracks.
  • Fusing current tests to characterize current-carrying behavior.
  • Electric insulation properties including test specimens, circuit set-ups and insulation test procedures to evaluate layer and substrate insulation.
• Durability and resistance tests
  • Perspiration resistance to assess chemical/biological effects from wear.
  • Detergent (washing) resistance for laundering durability of conductive and insulating layers.
• Test specimen preparation and set-up
  • Specimen geometries, pre-tensioning for non-stretch fabrics, and measurement circuit diagrams (figures provided in the standard).

Applications and users

This standard is practical for professionals involved in the design, testing and manufacture of wearable electronics and smart textiles:

• E-textile and smart textile manufacturers - to characterize conductive- yarns/fabrics and insulating components.
• Product designers / R&D teams - to validate electrical performance and durability of conductive traces and electrodes in garments.
• Test laboratories and quality departments - for reproducible, comparable measurement data used in material selection and supplier verification.
• Safety and compliance engineers - to assess insulation properties relevant to electrical safety in wearable systems.
• Academic researchers working on wearable sensors, garment-integrated electronics and printed textile conductors.

Keywords: electronic textile, e-textile, conductive fabrics, insulation materials, measurement methods, wearable electronic devices, smart textiles, sheet resistance, fusing current, perspiration resistance.

Related standards

Normative and related references cited include:

• IEC 60243-1 (electric strength of insulating materials)
• IEC 62631-3-1 (resistive properties of solid insulating materials)
• IEC 60468 (resistivity measurement methods)
• ISO 105‑E04 (colour fastness to perspiration)
• EN 16812 (linear electrical resistance of conductive tracks)

EN IEC 63203-201-2:2022 provides the standardized test foundation needed to compare and qualify conductive and insulating textile materials for garment-type wearable electronics.
