Plain bearings — Lubrication holes, grooves and pockets
— Dimensions, types, designation and their application to
bearing bushes
1 Scope
This document specifies dimensions for lubrication holes, grooves and pockets for bearing bushes.
These dimensions can be entered, for example on drawings, using the designation examples. Their use
depends in particular on the specific operating conditions.
In addition, it enables the user to assign the different types of lubricant feed and distribution to solid
and steel-backed plain bearing bushes made of copper alloys, aluminium alloys, thermosetting plastics,
thermoplastics or artificial carbon.
NOTE Different types of lubricant feed and distribution for plain bearing bushes made of sintered metals
have not been specified due to the fact that these bushes are soaked with lubricant. Plain bearing bushes made of
artificial carbon are not lubricated with oil or grease.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated referenc
...
