SIST EN 14382:2019/kFprA1:2023

Gas safety shut-off devices for inlet pressure up to 10 MPa (100 bar)

This document specifies constructional, functional, testing marking and sizing requirements and documentation of gas safety shut-off devices:
-   for inlet pressures up to 100 bar and nominal diameters up to DN 400;
-   for an operating temperature range from -20 °C to +60 °C;
which operate with fuel gases of the 1st and 2nd family as defined in EN 437, used in the pressure regulating stations in accordance with EN 12186 or EN 12279, in transmission and distribution networks and also in commercial and industrial installations.
"Gas safety shut-off devices" will hereafter be called "SSDs" except in titles.
For standard safety shut-off devices when used in pressure regulating stations complying with EN 12186 or EN 12279, Annex ZA lists all applicable Essential Safety Requirements of Directive 2014/68/EU (PED).
This document considers the following temperature classes/types of SSDs:
-   temperature class 1: operating temperature range from -10 °C to 60 °C;
-   temperature class 2: operating temperature range from -20 °C to 60 °C;
-   functional class A: SSDs that close when damage to the pressure detecting element occurs or when external power fails and whose re-opening, is possible only manually;
-   functional class B: SSDs that do not close when damage to the pressure detecting element occurs but provide suitable and reliable protection and whose re-opening, is possible only manually;
-   type IS: (integral strength type);
-   type DS: (differential strength type).
SSDs complying with the requirements of this document may be declared as "in conformity with EN 14382" and bear the mark "EN 14382".
The material and functional requirements specified in this document may be applied to SSDs which use thermal energy or the effects of electrical energy to trip the operation of the closing member. For these SSDs the operational parameters are not specified in this document.
The SSD may incorporate a vent limiter, complying with the requirements in Annex J.
This standard for some paragraphs and sub clauses makes full reference to prEN 334:2016.
This document does not apply to:
-   SSDs upstream from/on/in domestic gas-consuming appliances which are installed downstream of domestic gas meters;
-   SSDs designed to be incorporated into pressure-regulating devices used in service lines  with volumetric flow rate ≤ 200 m3/h at normal conditions and inlet pressure ≤ 5 bar.
Continued integrity of safety shut-off devices is ensured by periodic functional checks. For periodic functional checks it is common to refer to national regulations/standards where existing or users/manufacturers practices.
This document considers the reaction of the SSDs functional class A to the specified reasonable expected failures in terms of "fail close" behaviour, but it should be consider that there are other types of failures whose consequences cannot bring to the same reactions (these risks are covered via redundancy as per EN 12186) and that residual hazards should be reduced by a suitable surveillance in use / maintenance.
In this document, both safety shut-off devices that can be classified as "safety accessories" by themselves according the Pressure Equipment Directive (2014/68/EU) as well as safety shut-off devices that can be used to provide the necessary pressure protection through redundancy (e.g. shutoff device integrated in a pressure regulator, shut-off device with a second shut-off device) are considered. Addition of environmental considerations;
The provisions in this document are in line with the state of art at the moment of writing.
This document does not intend to limit the improvement of actual provisions (materials, requirements, test methods, acceptance criteria, etc.) or the developing of new provisions for SSDs where they are suitable to ensure an equivalent level of reliability.

Gas-Sicherheitsabsperreinrichtungen für Eingangsdrücke bis 10 MPa (100 bar)

No scope available

Clapets de sécurité pour pressions amont jusqu'à 10 MPa (100 bar)

No scope available

Plinske varnostne zaporne naprave za vstopne tlake do 10 MPa (100 bar) - Dopolnilo A1

General Information

• Status: Not Published
• Public Enquiry End Date: 02-Nov-2022
• ICS: 23.060.40 - Pressure regulators
• Technical Committee: DPL - Gas supply
• Current Stage: 98 - Abandoned project (Adopted Project)
• Start Date: 08-Jan-2025
• Due Date: 13-Jan-2025
• Completion Date: 08-Jan-2025
• Directive: 2014/68/EU - Directive 2014/68/EU of the European Parliament and of the Council of 15 May 2014 on the harmonisation of the laws of the Member States relating to the making available on the market of pressure equipment
• Mandate: M/071 - Mandate to CEN for standardization in the field of Pressure equipment
• Mandate: M/601 - COMMISSION IMPLEMENTING DECISION of 1.3.2024 on a standardisation request to the European Committee for Standardization and the European Committee for Electrotechnical Standardization as regards pressure equipment and assemblies in support of Directive 2014/68/EU of the European Parliament and of the Council
• Ref Project: EN 14382:2019/FprA1 - Gas safety shut-off devices for inlet pressure up to 10 MPa (100 bar)

Relations

• Consolidated By: SIST EN 14382:2019+A1:2025 - Gas safety shut-off devices for inlet pressure up to 10 MPa (100 bar)
• Effective Date: 01-Feb-2025
• Revises: SIST EN 14382:2019 - Gas safety shut-off devices for inlet pressure up to 10 MPa (100 bar)
• Effective Date: 01-Oct-2022

Overview

SIST EN 14382:2019/kFprA1:2023 is a European standard developed by CEN focusing on gas safety shut-off devices (SSDs) designed for inlet pressures up to 10 MPa (100 bar). It specifies the essential constructional, functional, testing, marking, sizing requirements, and documentation criteria for SSDs used in gas transmission and distribution networks, as well as commercial and industrial installations. These devices are critical safety components used particularly in pressure regulating stations governed by EN 12186 or EN 12279 standards.

This standard covers SSDs operating within an ambient temperature range of -20 °C to +60 °C and with nominal diameters up to DN 400. It includes protective measures for fuel gases classified in the 1st and 2nd families according to EN 437, ensuring reliability and safety in handling high-pressure fuel gas systems.

Key Topics

• Scope & Applicability
  This standard applies to SSDs for inlet pressures up to 100 bar and sizes up to DN 400. It excludes devices used directly upstream or integrated into domestic gas appliances and those in service lines with low flow rates (≤ 200 m³/h at ≤ 5 bar).

• Temperature & Functional Classification

  • Temperature Class 1: Operating between -10 °C and 60 °C
  • Temperature Class 2: Operating between -20 °C and 60 °C
  • Functional Class A: SSDs that automatically close upon pressure detecting element failure or power loss and reopen only manually.
  • Functional Class B: SSDs that remain open during such failures but still provide reliable protection and manual reopening.

• Device Types

  • Integral Strength Type (IS)
  • Differential Strength Type (DS)

• Testing & Compliance
  The document specifies rigorous testing procedures, including design load tests, wear replacement verification, proof tests, and final inspection protocols. SSDs can be marked as "EN 14382" compliant upon fulfilling all requirements. It also aligns with the European Pressure Equipment Directive (PED 2014/68/EU), detailing essential safety requirements and conformity assessments.

• Additional Features
  The standard allows for SSDs using thermal or electrical energy to actuate closure, though operational parameters for such variants are outside the scope. SSDs may incorporate vent limiters following Annex J requirements.

• Safety & Maintenance
  The standard emphasizes periodic functional checks to maintain device integrity, referring users to national regulations or established manufacturer practices. Residual risks due to failure modes are to be managed via redundancy and surveillance per EN 12186 guidelines.

Applications

EN 14382 SSDs are primarily used in:

• Pressure Regulating Stations: Ensuring safe gas pressure management in transmission and distribution networks.
• Transmission and Distribution Networks: Providing automatic shut-off capabilities to prevent hazardous gas leaks or overpressure situations.
• Commercial and Industrial Installations: Protecting complex gas systems in factories, plants, and large facilities requiring high-pressure gas control.
• Safety Accessories: Offering autonomous or integrated safety functions compliant with relevant EU directives.

These devices contribute to enhancing gas system safety by effectively shutting off fuel supply in unsafe conditions, preventing accidents, equipment damage, and environmental hazards.

Related Standards

• EN 437: Specification for fuel gases used in gas appliances, relevant for classifying fuel gas families supported by EN 14382 SSDs.
• EN 12186 and EN 12279: Standards governing pressure regulating stations where EN 14382 SSDs are typically installed.
• EN 334: Referenced for certain testing and design details, particularly for temperature and functional performance verification.
• Directive 2014/68/EU (PED): Pressure Equipment Directive outlining essential health and safety requirements for devices like SSDs.
• National Regulations: Functional verification and surveillance practices often follow country-specific safety regulations supplementing EN 14382 provisions.

---

Keywords: gas safety shut-off devices, SSDs, EN 14382, gas pressure regulators, safety accessories, pressure regulating stations, fuel gas families, pressure equipment directive, industrial gas safety, gas transmission networks, gas distribution safety, functional class A and B SSDs, temperature class SSDs, gas system safety compliance.

Standards Content (Sample)

SLOVENSKI STANDARD
SIST EN 14382:2019/oprA1:2022
01-oktober-2022
Plinske varnostne zaporne naprave za vstopne tlake do 10 MPa (100 bar) -
Dopolnilo A1
Gas safety shut-off devices for inlet pressure up to 10 MPa (100 bar)
Gas-Sicherheitsabsperreinrichtungen für Eingangsdrücke bis 10 MPa (100 bar)
Clapets de sécurité pour pressions amont jusqu'à 10 MPa (100 bar)
Ta slovenski standard je istoveten z: EN 14382:2019/prA1
ICS:
23.060.40 Tlačni regulatorji Pressure regulators
SIST EN 14382:2019/oprA1:2022 en,fr,de
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

SIST EN 14382:2019/oprA1:2022
SIST EN 14382:2019/oprA1:2022
DRAFT
EUROPEAN STANDARD
EN 14382:2019
NORME EUROPÉENNE
EUROPÄISCHE NORM
prA1
September 2022
ICS
English Version
Gas safety shut-off devices for inlet pressure up to 10 MPa
(100 bar)
Clapets de sécurité pour pressions amont jusqu'à 10 Gas-Sicherheitsabsperreinrichtungen für
MPa (100 bar) Eingangsdrücke bis 10 MPa (100 bar)
This draft amendment is submitted to CEN members for enquiry. It has been drawn up by the Technical Committee CEN/TC 235.

This draft amendment A1, if approved, will modify the European Standard EN 14382:2019. If this draft becomes an amendment,
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for inclusion of
this amendment into the relevant national standard without any alteration.

This draft amendment was established by CEN in three official versions (English, French, German). A version in any other
language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC
Management Centre has the same status as the official versions.

CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia,
Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway,
Poland, Portugal, Republic of North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and
United Kingdom.
Recipients of this draft are invited to submit, with their comments, notification of any relevant patent rights of which they are
aware and to provide supporting documentation.

Warning : This document is not a European Standard. It is distributed for review and comments. It is subject to change without
notice and shall not be referred to as a European Standard.

EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION

EUROPÄISCHES KOMITEE FÜR NORMUNG

CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels
© 2022 CEN All rights of exploitation in any form and by any means reserved Ref. No. EN 14382:2019/prA1:2022 E
worldwide for CEN national Members.

----------------------
...
