IMT cellular networks;Harmonized EN covering the essential requirements of article 3.2 of the R&TTE Directive;Part 14: Evolved Universal Terrestrial Radio Access (E-UTRA) Base Stations (BS)

The present document applies to the following radio equipment types:
1) Base Station for Evolved Universal Terrestrial Radio Access (E-UTRA).The present document covers requirements for E-UTRA Base Stations for 3GPP Release 8, 9, 10 and 11. This includes
the requirements for E UTRA Base Station operating bands and E-UTRA CA operating bands from 3GPP Release 12.
The present document is intended to cover the provisions of Directive 1999/5/EC [i.2] (R&TTE Directive), article 3.2,
which states that "….. radio equipment shall be so constructed that it effectively uses the spectrum allocated to
terrestrial/space radio communications and orbital resources so as to avoid harmful interference".
In addition to the present document, other ENs that specify technical requirements in respect of essential requirements
under other parts of article 3 of the R&TTE Directive may apply to equipment within the scope of the present
document.
NOTE: A list of such ENs is included on the web site http://www.newapproach.org.

Celična omrežja IMT - Harmonizirani EN, ki zajema bistvene zahteve člena 3.2 direktive R&TTE - 14. del: Bazne postaje za razviti prizemni radijski dostop za UMTS (E-UTRA)

Ta dokument se uporablja za radijsko opremo naslednjih vrst:
1) bazne postaje za razviti prizemni radijski dostop (E-UTRA). Ta dokument zajema zahteve za bazne postaje E-UTRA za izdaje 8, 9, 10 in 11 standarda 3GPP. To vključuje zahteve za pasove bazne postaje E-UTRA in pasove bazne postaje E-UTRA CA iz izdaje 12 standarda 3GPP.
Ta dokument zajema določbe člena 3(2) Direktive 1999/5/ES [i.2] (direktive R&TTE), ki določa, da »[...] mora biti radijska oprema skonstruirana tako, da učinkovito uporablja spekter, razporejen za prizemne/vesoljske radijske komunikacije in orbitalne vire, tako da ne pride do škodljivega motenja.«
Poleg tega dokumenta se za opremo na področju uporabe tega dokumenta uporabljajo tudi drugi standardi EN, ki določajo tehnične zahteve v zvezi z bistvenimi zahtevami iz drugih delov člena 3 direktive R&TTE.
