ASTM A659/A659M-22
(Specification)Standard Specification for Commercial Steel (CS), Sheet and Strip, Carbon (0.16 Maximum to 0.25 Maximum Percent), Hot-Rolled
Standard Specification for Commercial Steel (CS), Sheet and Strip, Carbon (0.16 Maximum to 0.25 Maximum Percent), Hot-Rolled
ABSTRACT
This specification covers hot-rolled carbon steel sheet and strip, in coils and cut lengths. The cast or heat analysis of the steel shall conform to the chemical composition for copper, nickel, chromium, molybdenum, vanadium, and columbium. The bending properties are measured.
SCOPE
1.1 This specification covers hot-rolled carbon steel (CS) sheet and strip, in coils and cut lengths, in which the maximum of the specified carbon range is over 0.15 and not over 0.25 % and the maximum of the specified manganese range is not over 0.90 %. This material is ordered to chemical composition.
1.2 This specification is not applicable to the steels covered by Specification A635/A635M.
1.3 The values stated in either SI units or inch-pound units are to be regarded separately as standard. The values stated in each system may not be exact equivalents; therefore, each system shall be used independently of the other. Combining values from the two systems may result in non-conformance with the standard.
1.4 This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
General Information
Buy Standard
Standards Content (Sample)
This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the
Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
Designation: A659/A659M −22
Standard Specification for
Commercial Steel (CS), Sheet and Strip, Carbon (0.16
1
Maximum to 0.25 Maximum Percent), Hot-Rolled
This standard is issued under the fixed designationA659/A659M; the number immediately following the designation indicates the year
of original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval.
A superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
This standard has been approved for use by agencies of the U.S. Department of Defense.
1. Scope* A749/A749M Specification for Steel, Strip, Carbon and
High-Strength, Low-Alloy, Hot-Rolled, General Require-
1.1 This specification covers hot-rolled carbon steel (CS)
ments for
sheet and strip, in coils and cut lengths, in which the maximum
E527 Practice for Numbering Metals and Alloys in the
of the specified carbon range is over 0.15 and not over 0.25 %
Unified Numbering System (UNS)
and the maximum of the specified manganese range is not over
3
2.2 Society of Automotive Engineers Standard:
0.90 %. This material is ordered to chemical composition.
J 1086 Numbering Metals and Alloys
1.2 This specification is not applicable to the steels covered
by Specification A635/A635M.
3. Ordering Information
1.3 The values stated in either SI units or inch-pound units
3.1 It is the purchaser’s responsibility to specify in the
are to be regarded separately as standard. The values stated in
purchase order all ordering information necessary to purchase
each system may not be exact equivalents; therefore, each
the needed material. Examples of such information include but
system shall be used independently of the other. Combining
are not limited to the following:
values from the two systems may result in non-conformance
3.1.1 ASTM specification number and year of issue,
with the standard.
3.1.2 Name of material (hot-rolled commercial steel (CS)
sheet, or hot-rolled commercial steel (CS) strip),
1.4 This international standard was developed in accor-
3.1.3 Grade designation or chemical composition, or both,
dance with internationally recognized principles on standard-
3.1.4 Copper-bearing steel (if required),
ization established in the Decision on Principles for the
3.1.5 Condition (as-rolled, pickled, or blast cleaned) (see
Development of International Standards, Guides and Recom-
4.1),
mendations issued by the World Trade Organization Technical
3.1.5.1 Material to this specification is furnished in the
Barriers to Trade (TBT) Committee.
hot-rolled condition. Pickled (or blast cleaned) must be speci-
2. Referenced Documents
fied if required,
2
3.1.6 Oiling (see 7.2),
2.1 ASTM Standards:
3.1.7 Edges (see 7.1),
A568/A568M Specification for Steel, Sheet, Carbon,
3.1.8 Dimensions(thickness,width,andwhethercutlengths
Structural,andHigh-Strength,Low-Alloy,Hot-Rolledand
or coils),
Cold-Rolled, General Requirements for
A635/A635M Specification for Steel, Sheet and Strip,
NOTE 1—Not all producers are capable of meeting all of the limitations
Heavy-Thickness Coils, Hot-Rolled, Alloy, Carbon,
of the thickness tolerance tables in Specification A568/A568M. The
purchaser should contact the producer regarding possible limitations prior
Structural, High-Strength Low-Alloy, and High-Strength
to placing an order.
Low-Alloy with Improved Formability, General Require-
ments for 3.1.9 Coil size (must include inside diameter, outside
diameter, and maximum mass),
3.1.10 Quantity,
1
This specification is under the jurisdiction of ASTM Committee A01 on Steel,
Stainless Steel and Related Alloys and is the direct responsibility of Subcommittee 3.1.11 Application (show part identification and
A01.19 on Steel Sheet and Strip.
description),
Current edition approved Nov. 1, 2022. Published December 2022. Originally
3.1.12 Cast or heat analysis report (request, if required),
approved in 1972. Last previous edition approved in 2018 as A659/A659M – 18.
3.1.13 Special requirements (if required).
DOI: 10.1520/A0659_A0659M-22.
2
For referenced ASTM standards, visit the ASTM website, www.astm.org, or
contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM
3
Standards volume information, refer to the standard’s Document Summary page on Available from Society of Automotive Engineers (SAE), 400 Commonwealth
theASTM website. Dr., Warrendale, PA 15096-0001, http://www.sae.org.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1
---------------------- Page: 1 ----------------------
A659/A659M − 22
TABLE 2 Limit
...
This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: A659/A659M − 18 A659/A659M − 22
Standard Specification for
Commercial Steel (CS), Sheet and Strip, Carbon (0.16
1
Maximum to 0.25 Maximum Percent), Hot-Rolled
This standard is issued under the fixed designation A659/A659M; the number immediately following the designation indicates the year
of original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval.
A superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
This standard has been approved for use by agencies of the U.S. Department of Defense.
1. Scope*
1.1 This specification covers hot-rolled carbon steel (CS) sheet and strip, in coils and cut lengths, in which the maximum of the
specified carbon range is over 0.15 and not over 0.25 % and the maximum of the specified manganese range is not over 0.90 %.
This material is ordered to chemical composition.
1.2 This specification is not applicable to the steels covered by Specification A635/A635M.
1.3 The values stated in either SI units or inch-pound units are to be regarded separately as standard. The values stated in each
system may not be exact equivalents; therefore, each system shall be used independently of the other. Combining values from the
two systems may result in non-conformance with the standard.
1.4 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2
2.1 ASTM Standards:
A568/A568M Specification for Steel, Sheet, Carbon, Structural, and High-Strength, Low-Alloy, Hot-Rolled and Cold-Rolled,
General Requirements for
A635/A635M Specification for Steel, Sheet and Strip, Heavy-Thickness Coils, Hot-Rolled, Alloy, Carbon, Structural,
High-Strength Low-Alloy, and High-Strength Low-Alloy with Improved Formability, General Requirements for
A749/A749M Specification for Steel, Strip, Carbon and High-Strength, Low-Alloy, Hot-Rolled, General Requirements for
E527 Practice for Numbering Metals and Alloys in the Unified Numbering System (UNS)
3
2.2 Society of Automotive Engineers Standard:
J 1086 Numbering Metals and Alloys
1
This specification is under the jurisdiction of ASTM Committee A01 on Steel, Stainless Steel and Related Alloys and is the direct responsibility of Subcommittee A01.19
on Steel Sheet and Strip.
Current edition approved Sept. 1, 2018Nov. 1, 2022. Published September 2018December 2022. Originally approved in 1972. Last previous edition approved in 20172018
as A659/A659M – 12 (2017).A659/A659M – 18. DOI: 10.1520/A0659_A0659M-18.10.1520/A0659_A0659M-22.
2
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
3
Available from Society of Automotive Engineers (SAE), 400 Commonwealth Dr., Warrendale, PA 15096-0001, http://www.sae.org.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1
---------------------- Page: 1 ----------------------
A659/A659M − 22
3. Ordering Information
3.1 It is the purchaser’s responsibility to specify in the purchase order all ordering information necessary to purchase the needed
material. Examples of such information include but are not limited to the following:
3.1.1 ASTM specification number and year of issue,
3.1.2 Name of material (hot-rolled commercial steel (CS) sheet, or hot-rolled commercial steel (CS) strip),
3.1.3 Grade designation or chemical composition, or both,
3.1.4 Copper-bearing steel (if required),
3.1.5 Condition (as-rolled, pickled, or blast cleaned) (see 4.1),
3.1.5.1 Material to this specification is furnished in the hot-rolled condition. Pickled (or blast cleaned) must be specified if
required,
3.1.6 Oiling (see 7.2),
3.1.7 Edges (see 7.1),
3.1.8 Dimensions (thickness, width, and whether cut lengths or coils),
NOTE 1—Not all producers are capable of meeting all of the limitations of the thickness tolerance tables in Specification A568/A568M. The purchaser
should contact the producer regarding possible limitations prior to placing an order.
3.1.9 Coil size (must include inside diameter, outside diamet
...
