ASTM D2893-19
(Test Method)Standard Test Methods for Oxidation Characteristics of Extreme-Pressure Lubrication Oils
Standard Test Methods for Oxidation Characteristics of Extreme-Pressure Lubrication Oils
SIGNIFICANCE AND USE
4.1 These test methods have been widely used to measure the oxidation stability of extreme pressure lubricating fluids, gear oils, and mineral oils.
SCOPE
1.1 These test methods (A and B) cover the determination of the oxidation characteristics of extreme-pressure fluid lubricants, gear oils, or mineral oils.
Note 1: The changes in the lubricant resulting from these test methods are not always necessarily associated with oxidation of the lubricant. Some changes may be due to thermal degradation.
1.2 The values stated in SI units are to be regarded as standard. No other units of measurement are included in this standard.
1.3 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of regulatory limitations prior to use.
1.4 This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
General Information
Relations
Buy Standard
Standards Content (Sample)
This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the
Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
Designation: D2893 − 19
Standard Test Methods for
Oxidation Characteristics of Extreme-Pressure Lubrication
1
Oils
This standard is issued under the fixed designation D2893; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope* E2877 Guide for Digital Contact Thermometers
1.1 Thesetestmethods(AandB)coverthedeterminationof
3. Summary of Test Method
the oxidation characteristics of extreme-pressure fluid
lubricants, gear oils, or mineral oils.
3.1 The oil sample is subjected to a temperature of 95 °C
(Test MethodA) or 121 °C (Test Method B) in the presence of
NOTE 1—The changes in the lubricant resulting from these test methods
dry air for 312 h.
are not always necessarily associated with oxidation of the lubricant.
Some changes may be due to thermal degradation.
3.2 The oil is then tested for precipitation number and
1.2 The values stated in SI units are to be regarded as
increase in kinematic viscosity.
standard. No other units of measurement are included in this
standard.
4. Significance and Use
1.3 This standard does not purport to address all of the
4.1 These test methods have been widely used to measure
safety concerns, if any, associated with its use. It is the
the oxidation stability of extreme pressure lubricating fluids,
responsibility of the user of this standard to establish appro-
gear oils, and mineral oils.
priate safety, health, and environmental practices and deter-
mine the applicability of regulatory limitations prior to use.
5. Apparatus
1.4 This international standard was developed in accor-
5.1 Heating Bath or Block, thermostatically controlled,
dance with internationally recognized principles on standard-
capable of maintaining the oil sample in the test tube at a
ization established in the Decision on Principles for the
temperature of 95 °C 6 0.2 °C (Test Method A), or 121 °C 6
Development of International Standards, Guides and Recom-
1.0 °C (Test Method B) and large enough to hold the desired
mendations issued by the World Trade Organization Technical
number of oxidation cells immersed in the heating bath or
Barriers to Trade (TBT) Committee.
block to a depth of approximately 350 mm. The liquid heating
bath shall be fitted with a suitable stirring device to provide a
2. Referenced Documents
uniform temperature throughout the bath.
2
2.1 ASTM Standards:
5.2 Test Tubes, of borosilicate glass, 41 mm 6 0.5 mm
D91 Test Method for Precipitation Number of Lubricating
inside diameter and 600 mm in length are required, each fitted
Oils
withaslottedcork(Note2)stopperintowhichshallbeinserted
D445 Test Method for Kinematic Viscosity of Transparent
a glass air delivery tube of 4 mm to 5 mm of inside diameter.
and Opaque Liquids (and Calculation of Dynamic Viscos-
The length of the air delivery tube shall be such that one end
ity)
reaches to within 6 mm of the bottom of the tube and the other
D943 Test Method for Oxidation Characteristics of Inhibited
end projects 60 mm to 80 mm from the cork stopper.
Mineral Oils
E1 Specification for ASTM Liquid-in-Glass Thermometers
NOTE 2—New corks should be used for each run.
5.3 Flowmeter, one to each test tube, capable of measuring
an air flow of 10 L/h with an accuracy of 6 0.5 L/h.
1
These test methods are under the jurisdiction of ASTM Committee D02 on
Petroleum Products, Liquid Fuels, and Lubricants and is the direct responsibility of
5.4 Thermometer—ASTM Solvent Distillation Thermom-
Subcommittee D02.09.0D on Oxidation of Lubricants.
eter having a range from 76 °C to 126 °C and conforming to
Current edition approved Dec. 1, 2019. Published December 2019. Originally
the requirement for Thermometer 40C as prescribed in Speci-
approved in 1970. Last previous edition approved in 2014 as D2893 – 04 (2014).
DOI: 10.1520/D2893-19.
fication E1. Alternatively, calibrated digital contact thermom-
2
For referenced ASTM standards, visit the ASTM website, www.astm.org, or
eters such as PRTs (platinum resistance thermometers),
contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM
thermistors,orthermocouplesinaccordancewithGuideE2877
Standards volume information, refer to the standard’s Document Summary page on
the ASTM website. of equal or better accuracy may be used.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1
---------------------- Page: 1 ------
...
This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
´1
Designation: D2893 − 04 (Reapproved 2014) D2893 − 19
Standard Test Methods for
Oxidation Characteristics of Extreme-Pressure Lubrication
1
Oils
This standard is issued under the fixed designation D2893; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1
ε NOTE—Subsection 6.1 was updated editorially in July 2014.
1. Scope Scope*
1.1 These test methods (A and B) cover the determination of the oxidation characteristics of extreme-pressure fluid lubricants,
gear oils, or mineral oils.
NOTE 1—The changes in the lubricant resulting from these test methods are not always necessarily associated with oxidation of the lubricant. Some
changes may be due to thermal degradation.
1.2 The values stated in SI units are to be regarded as standard. No other units of measurement are included in this standard.
1.3 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility
of the user of this standard to establish appropriate safety safety, health, and healthenvironmental practices and determine the
applicability of regulatory limitations prior to use.
1.4 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2
2.1 ASTM Standards:
D91 Test Method for Precipitation Number of Lubricating Oils
D445 Test Method for Kinematic Viscosity of Transparent and Opaque Liquids (and Calculation of Dynamic Viscosity)
D943 Test Method for Oxidation Characteristics of Inhibited Mineral Oils
E1 Specification for ASTM Liquid-in-Glass Thermometers
E2877 Guide for Digital Contact Thermometers
3. Summary of Test Method
3.1 The oil sample is subjected to a temperature of 95°C95 °C (Test Method A) or 121°C121 °C (Test Method B) in the presence
of dry air for 312 h.
3.2 The oil is then tested for precipitation number and increase in kinematic viscosity.
4. Significance and Use
4.1 These test methods have been widely used to measure the oxidation stability of extreme pressure lubricating fluids, gear oils,
and mineral oils.
5. Apparatus
5.1 Heating Bath or Block, thermostatically controlled, capable of maintaining the oil sample in the test tube at a temperature
of 9595 °C 6 0.2°C0.2 °C (Test Method A), or 121121 °C 6 1.0°C1.0 °C (Test Method B) and large enough to hold the desired
1
These test methods are under the jurisdiction of ASTM Committee D02 on Petroleum Products, Liquid Fuels, and Lubricants and is the direct responsibility of
Subcommittee D02.09.0D on Oxidation of Lubricants.
Current edition approved June 1, 2014Dec. 1, 2019. Published July 2014December 2019. Originally approved in 1970. Last previous edition approved in 20092014 as
D2893 – 04 (2009).(2014). DOI: 10.1520/D2893-04R14E01.10.1520/D2893-19.
2
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
*A Summary of Changes section appears at the end of this standard
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1
---------------------- Page: 1 ----------------------
D2893 − 19
number of oxidation cells immersed in the heating bath or block to a depth of approximately 350 mm. The liquid heating bath shall
be fitted with a suitable stirring device to provide a uniform temperature throughout the bath.
5.2 Test Tubes, of borosilicate glass, 4141 mm 6 0.5 mm 0.5 mm inside diameter and 600 mm in length are required, each fitted
with a slotted cork (Note 2) stopper into which shall be inserted a glass air delivery tube of 44 mm to 5 mm 5 mm of inside
diameter. The length of the air delivery tube shall be such that one end reaches to within 6 mm of the bottom of the tube and the
other end projects 6060 mm to 80 mm 80 mm from the cork stopper.
NOTE 2—New corks should be used for each run.
5.3 Flowmeter, one to each test tube, capable of measuring an air flow of 10 L/h with an accuracy of 60.56 0.5 L/h.
5.4
...
