Designation: D6856/D6856M − 23
Standard Guide for
1
Testing Fabric-Reinforced “Textile” Composite Materials
This standard is issued under the fixed designation D6856/D6856M; the number immediately following the designation indicates the
year of original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last
reapproval. A superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
INTRODUCTION
A variety of fabric-reinforced composite materials have been developed for use in aerospace,
automotive, civil, construction, and other applications. These composite materials are reinforced with
continuous fiber yarns that are formed into two-dimensional or three-dimensional fabrics. Various
fabric constructions, such as woven, braided, stitched, and so forth, can be used to form the fabric
reinforcement. Due to the nature of the reinforcement, these materials are often referred to as “textile”
composites.
Textile composites can be fabricated from 2-dimensional (2-D) or 3-dimensional (3-D) fabrics.
Stitched preforms and 3-D fabrics contain through-thickness yarns, which can lead to greater
delamination resistance. Textile composites are also amenable to automated fabrication. However, the
microstructure (or fiber architecture) of a textile composite, which consists of interlacing yarns, can
lead to increased inhomogeneity of the local displacement fields in the laminate. Depending upon the
size of the yarns and the pattern of the weave or braid, the inhomogeneity within a textile composite
can be large compared to traditional tape laminates.
Thus, special care should be exercised in the use of the current ASTM standards developed for high
performance composites. In many cases, the current ASTM standards are quite adequate if proper
attention is given to the special testing considerations for textile composites covered in this guide.
However, in some cases, current standards do not meet the needs for testing of the required properties.
This guide is intended to increase the user’s awareness of the special considerations necessary for the
testing of these materials. It also provides the user with recommended ASTM standards that are
applicable for evaluating textile composites. The specific properties for which current ASTM
standards might not apply are also highlighted in this guide.
1. Scope 1.1.2 Assist the user in selecting the best currently available
ASTM test method for the measurement of commonly evalu-
1.1 This guide is applicable to the testing of textile com-
ated material properties for this class of materials.
posites fabricated using fabric preforms, such as weaves,
braids, stitched preforms, and so forth, as the reinforcement. 1.2 Areas where current ASTM test methods do not meet
The purpose of this guide is to: the needs for testing of textile composites are indicated.
1.1.1 Ensure that proper consideration is given to the unique
1.3 It is not the intent of this guide to cover all test methods
characteristics of these materials in testing.
which could possibly be used for textile composites. Only the
most commonly used and most applicable standards are
included.
1
This guide is under the jurisdiction of ASTM Committee D30 on Composite
Materials and is the direct responsibility of Subcommittee D30.04 on Lamina and
1.4 The values stated in either SI units or inch-pound units
Laminate Test Methods.
are to be regarded separately as standard. The values stated in
Current edition approved Nov. 1, 2023. Published November 2023. Originally
each system are not necessarily exact equivalents; therefore, to
approved in 2003. Last previous edition approved in 2016 as D6856 – 03 (2016).
DOI: 10.1520/D6856_D6856M-23. ensure conformance with the standard, each system shall be
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1
---------------------- Page: 1 ----------------------
D6856/D6856M − 23
used independently of the other, and values from the two Strength of Polymer Matrix Composite Laminates
systems shall not be combined. D5961/D5961M Test Method for Bearing Response of Poly-
1.4.1 Within the text the inch-pound units are shown in mer Matrix Composite Laminates
brackets. D6115 Test Method for Mode I Fatigue Delamination
Growth Onset of Unidirectional Fiber-Reinforced Poly-
1.5 This standard does not purport to address all of the
mer Matrix Composites
safety concerns, if any, associated with its use. It is the
D6415/D6415M Test Method for Measuring the Curved
responsibility of the user of this standard to establish appro-
Beam Strength of a Fib
...
This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: D6856/D6856M − 03 (Reapproved 2016) D6856/D6856M − 23
Standard Guide for
1
Testing Fabric-Reinforced “Textile” Composite Materials
This standard is issued under the fixed designation D6856/D6856M; the number immediately following the designation indicates the
year of original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last
reapproval. A superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
INTRODUCTION
A variety of fabric-reinforced composite materials have been developed for use in aerospace,
automotive, civil, construction, and other applications. These composite materials are reinforced with
continuous fiber yarns that are formed into two-dimensional or three-dimensional fabrics. Various
fabric constructions, such as woven, braided, stitched, and so forth, can be used to form the fabric
reinforcement. Due to the nature of the reinforcement, these materials are often referred to as “textile”
composites.
Textile composites can be fabricated from 2-dimensional (2-D) or 3-dimensional (3-D) fabrics.
Stitched preforms and 3-D fabrics contain through-thickness yarns, which can lead to greater
delamination resistance. Textile composites are also amenable to automated fabrication. However, the
microstructure (or fiber architecture) of a textile composite, which consists of interlacing yarns, can
lead to increased inhomogeneity of the local displacement fields in the laminate. Depending upon the
size of the yarns and the pattern of the weave or braid, the inhomogeneity within a textile composite
can be large compared to traditional tape laminates.
Thus, special care should be exercised in the use of the current ASTM standards developed for high
performance composites. In many cases, the current ASTM standards are quite adequate if proper
attention is given to the special testing considerations for textile composites covered in this guide.
However, in some cases, current standards do not meet the needs for testing of the required properties.
This guide is intended to increase the user’s awareness of the special considerations necessary for the
testing of these materials. It also provides the user with recommended ASTM standards that are
applicable for evaluating textile composites. The specific properties for which current ASTM
standards might not apply are also highlighted in this guide.
1. Scope
1.1 This guide is applicable to the testing of textile composites fabricated using fabric preforms, such as weaves, braids, stitched
preforms, and so forth, as the reinforcement. The purpose of this guide is to:
1.1.1 Ensure that proper consideration is given to the unique characteristics of these materials in testing.
1.1.2 Assist the user in selecting the best currently available ASTM test method for the measurement of commonly evaluated
material properties for this class of materials.
1.2 Areas where current ASTM test methods do not meet the needs for testing of textile composites are indicated.
1
This guide is under the jurisdiction of ASTM Committee D30 on Composite Materials and is the direct responsibility of Subcommittee D30.04 on Lamina and Laminate
Test Methods.
Current edition approved Sept. 1, 2016Nov. 1, 2023. Published September 2016November 2023. Originally approved in 2003. Last previous edition approved in 20032016
ɛ1
as D6856-03(2008)D6856 – 03 (2016). . DOI: 10.1520/D6856_D6856M-03R16.10.1520/D6856_D6856M-23.
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1
---------------------- Page: 1 ----------------------
D6856/D6856M − 23
1.3 It is not the intent of this guide to cover all test methods which could possibly be used for textile composites. Only the most
commonly used and most applicable standards are included.
1.4 The values stated in either SI units or inch-pound units are to be regarded separately as standard. The values stated in each
system may not beare not necessarily exact equivalents; therefore, to ensure conformance with the standard, each system shall be
used independently of the other. Combiningother, and values from the two systems may result in non-conformance with the
standard.shall not be combined.
1.4.1 Within the text the inch-pound units are shown in brackets.
1.5 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility
of the user of this standard to establish appropriate safety and healthsafe
...
