Introduction
Dental CAD/CAM systems have been successfully used for the fabrication of indirect dental restorations
such as inlays, crowns and bridges. The accuracy of these restorations is one of the most important
factors for their clinical success. This document provides standardized test methods to evaluate the
machining accuracy of computer-aided milling machines which are used as a part of dental CAD/CAM
systems and the information to be provided by the manufacturer. Flow charts of the test methods are
given in Figures A.1 and A.2.
There are two methods using metal dies or software to evaluate machining accuracy of the target
restoration(s). Either or both test methods should be selected to evaluate the machining accuracy.
v
© ISO 2023 – All rights reserved

---------------------- Page: 11 ----------------------
SIST EN ISO 23298:2023

---------------------- Page: 12 ----------------------
SIST EN ISO 23298:2023
INTERNATIONAL STANDARD ISO 23298:2023(E)
Dentistry — Test methods for machining accuracy of
computer-aided milling machines
1 Scope
This document specifies the test methods to evaluate the machining accuracy of computer-aided milling
machines as a part of dental CAD/CAM systems, which fabricate dental restorations, such as inlays,
crowns and bridges.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 1942, Dentistry — Vocabulary
ISO 18739, Dentistry — Vocabulary of process chain for CAD/CAM systems
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 1942, ISO 18739 and the
following apply.
ISO and IEC maintain terminology databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at https:// www .electropedia .org/
3.1
computer-aided milling machine
computer-aided machining device designed for subtractive manufacturing of dental prostheses using
rotary instruments for cutting and grinding
3.2
blank
material to be machined by a computer-aided milling machine (3.1)
Note 1 to entry: A blank can be a block (3.3) or a disc (3.4).
3.3
block
cuboidal material with holding device to be machined by a computer-aided milling machine (3.1)
3.4
disc
flat circular-shaped material to be machined by a computer-aided milling machine (3.1)
3.5
stock material
material blanks (3.2) that are in stock to be machined by a computer-aided milling machine (3.1)
1
© ISO 2023 – All rights reserved

---------------------- Page: 13 ----------------------
SIST EN ISO 23298:2023
ISO 23298:2023(E)
4 General
There are two methods to evaluate accuracy of the target restoration(s). The accuracy of target
restoration(s) shall be evaluated using one or both of the test methods described in Clause 5. The
test method(s) selected and corresponding results shall be provided in the instructions for use, the
technical manual or other means. When the machining accuracy is affected by the material, appropriate
material(s) shall be tested. Testing shall be performed on each material type that the manufacturer
indicates for use by the device. The metal die method (5.1) is a measurement method based on the
marginal adaptability of a machined restoration to a master die. Measurements obtained using this
method can be used to assess the adaptability at restoration margins. The software method (5.2) is
a measurement method based on a comparison of the scanned file of a milled restoration to a master
manufacturing file using reverse engineering software. Measurements obtained using this method can
be used to assess restoration margin, intaglio and external surface accuracy.
5 Test methods
5.1 Metal die method
5.1.1 Target restorations
Three types of restorations are the targets of this test method:
a) class II inlay,
b) crown, and
c) four-unit bridge.
Choose the restoration type(s) specified in the manufacturer’s instructions for use and technical
manual. If any of the restoration types are not specified by the manufacturer’s technical manual for the
equipment being tested, this restoration type shall be eliminated from the test procedure.
NOTE This test method is designed by adopting the same principle as the examination method of clinical
marginal adaptation. The clinical adaptation is examined by checking the discrepancy between the restoration
and the cavity margin or between it and the shoulder margin of the abutment.
5.1.2 Apparatus
5.1.2.1 Metal dies
Two types of metal dies given in Figure 1 (class II inlay) and Figure 2 (crown and four-unit bridge
dies) are used both for the preparation of three-dimensional data (manufacturing data set) and the
evaluation of the accuracy of restorations. Dies shall be constructed based on the drawings in Figure 1
and Figure 2. These dies consist of a non-malleable base part and one or more removable structure(s)
used for the evaluation of accuracy.
The diameter of the removable occlusal part, measured at the transition between the occlusal part and
the abutment, shall be not less than the diameter of the abutment at this transition and the difference of
diameter shall be not more than 10 μm.
The surface roughness (S ) of the die, excepting the surfaces which do not come in contact with the test
a
specimens/machined restorations, shall be less than 2 μm. Refer to ISO 25178-2 and other parts for test
methods.
If a mark for reference point is necessary, either a groove or a ridge, or both, may be placed on the part,
but shall be placed so as to not influence the evaluation of the results.
2
  © ISO 2023 – All rights reserved

---------------------- Page: 14 ----------------------
SIST EN ISO 23298:2023
ISO 23298:2023(E)
The removable occlusal part and removable shoulder are used for preparation of three-dimensional
data, but not used for evaluation of accuracy.
1)
NOTE An example of the machining device to fabricate the dies is VERTICAL CENTER NEXUS 410B .
Dimensions in millimetres
Key
1 base part
2 removable part
3 positioning pin
4 fixing screw
Figure 1 — Die for class II inlay specimen
1) VERTICAL CENTER NEXUS 410B is the trade name of a product supplied by Yamazaki Mazak. This information
is given for the convenience of users of this document and does not constitute an endorsement by ISO of the product
named. Equivalent products may be used if they can be shown to lead to the same results.
3
© ISO 2023 – All rights reserved

---------------------- Page: 15 ----------------------
SIST EN ISO 23298:2023
ISO 23298:2023(E)
Dimensions in millimetres
Key
1 base part 4 removable shoulder
2 abutment h height of the removable shoulder
s
3 removable occlusal part
The recommended size of the height of the removable shoulder is (3,6 ± 0,05) mm.
Figure 2 — Die for the crown and bridge specimen
4
  © ISO 2023 – All rights reserved

---------------------- Page: 16 ----------------------
SIST EN ISO 23298:2023
ISO 23298:2023(E)
5.1.2.2 Measuring devices used for metal dies
Measuring devices with accuracy of ≤2 μm shall be used for measurement of metal dies (5.1.3).
Coordinate measuring machine (CMM) can be useful to measure the size of a die.
2)
NOTE An example of a CMM is America Strato-Apex 574 .
5.1.2.3 Measuring devices used for discrepancy measurement
Measuring devices with accuracy of ≤5 μm shall be used for discrepancy measurement in 5.1.4. Three-
dimensional measuring microscopes, displacement meters and digital micrometers can be used.
5.1.3 Measurement of metal dies
Each die shall be measured using a measuring device specified in 5.1.2.2 to confirm the shape and
dimensions specified in Figure 1 or Figure 2. The specified dimensions of constructed die necessary
to prepare CAD data shall be measured in accordance with Annex B. The measured data are used to
prepare the three-dimensional data (see 5.1.4).
In case of a metal die for crown and bridge specimen, the height of the removable shoulder (h in
s
Figure 2), and the height from the upper surface of the removable shoulder (Key 4 in Figure 2) to the
upper surface of the removable occlusal part (Key 3 in Figure 2) shall be measured.
5.1.4 Preparation of three-dimensional data
5.1.4.1 General
The surface to be in contact with the metal die of each specimen type is determined by the measurements
of the dies made in 5.1.3. The external surfaces of each specimen type are determined by 5.1.4.2 and
5.1.4.3.
5.1.4.2 Class II inlay
The shapes and sizes of test specimen of class II inlay shall conform to the cavity of metal die (see
Figure 1). The occlusal and proximal surfaces shall be the same planes with the corresponding surface
of the metal die.
5.1.4.3 Crown and bridges
The shapes and sizes of test specimen of the crown and the bridge shall conform to Figure 3 (crown)
and Figure 4 (bridge). A mark to distinguish direction when placing the restoration on the metal die
shall be made on the top surface of the crown. In case of bridges, the mark shall be made on either
crown.
5.1.4.4 Preparation of CAD data (STL data)
To fabricate the target restorations, CAD data (STL data) for each of the restorations specified in 5.1.4.2
and 5.1.4.3 shall be prepared in accordance with Annex B. This CAD data shall then be processed by
CAM software to prepare the manufacturing data set.
The dimensions of any surfaces in contact with the die surfaces are obtained from the measuring
process in 5.1.3. Other dimensions are determined from Figure 3 and Figure 4.
The CAD data shall be prepared to ensure that the restoration meets the die without an allowance for
cement space.
2) STRATO-Apex 574 is the trade name of a product supplied by Mitsutoyo. This information is given for the
convenience of users of this document and does not constitute an endorsement by ISO of the product named.
Equivalent products may be used if they can be shown to lead to the same results.
5
© ISO 2023 – All rights reserved

---------------------- Page: 17 ----------------------
SIST EN ISO 23298:2023
ISO 23298:2023(E)
Dimensions in millimetres
Key
1 base part
2 abutment
3 removable occlusal part
4 removable shoulder
5 test specimen
6 mark to distinguish direction
Figure 3 — Test specimen of the crown
6
  © ISO 2023 – All rights reserved

---------------------- Page: 18 ----------------------
SIST EN ISO 23298:2023
ISO 23298:2023(E)
Dimensions in millimetres
Key
1 base part
2 abutment
3 test specimen
4 mark to distinguish direction
Figure 4 — Test specimen of the bridge
5.1.5 Machining of restorations
The prepared manufacturing data set shall be input into the computer-aided milling machine following
the manufacturer’s instruction. The CAM software shall use the same configuration and parameters
as is usually delivered. The target restoration shall be machined using the material specimen (blank)
following the manufacturer’s instruction.
NOTE 1 A manufacturer refers to a natural person actually manufacturing a computer-aided milling machine,
or a natural person supplying necessary information to use the computer-aided milling machine.
The target restoration shall be the same size of the prepared manufacturing data set. CAM software
contains a scaling factor to compensate for shrinkage of material during an additional process such as
sintering. The CAM software scaling factor used in this test shall be 1,00.
This test is carried out using a computer-aided milling machine maintained according to the
manufacturer’s instruction.
The evaluation of accuracy (see 5.1.6) is carried out using the restoration without any after treatment
such as a sintering process. If any support structures are necessary for fabrication, they shall not be
positioned on the surface contacting the die and shall be removed before the measurement.
NOTE 2 Support structures are carefully removed using an appropriate rotary instrument such as a carbide
laboratory cutter.
7
© ISO 2023 – All rights reserved

---------------------- Page: 19 ----------------------
SIST EN ISO 23298:2023
ISO 23298:2023(E)
Fabricate six specimens for each of the target restorations.
5.1.6 Evaluation of accuracy
5.1.6.1 General
The accuracy of the restorations is expressed by the discrepancy between the margin of a restoration
and baseline (cavity margin for inlays and the abutment shoulder for the crown and bridge).
The measurement of discrepancy is carried out using a measuring device specified in 5.1.2.3. The
measured value shall be expressed in millimetre to three decimal places. After each measurement, the
surface of metal die shall be cleaned to remove all particles and dust.
When two or more dies for each restoration type are prepared, evaluation of accuracy shall always be
performed using restorations prepared from measurement data specific to that die set.
5.1.6.2 Class II inlay
Place the inlay in the cavity of a metal die and apply a load of (25 ± 1) N, distributed evenly on the
centres of occlusal and proximal surfaces simultaneously. Round edges of the loading tip are preferred.
Remove the load after (30 ± 1) s and examine where the margin of the inlay is located.
V-shaped or M-shaped pressing device having inner corner of 90° and width of (4,5 ± 0,2) mm shall be
used for applying the load onto the occlusal and proximal surfaces of inlay simultaneously.
If necessary, the removable part of the inlay die should be retained with the fixation screw. See Figure 1.
NOTE The use of weighing paper or a thin elastomeric sheet can be used at the interface of
...

SLOVENSKI STANDARD
oSIST prEN ISO 23298:2022
01-februar-2022
Zobozdravstvo - Preskusne metode za natančnost obdelave računalniško podprtih
strojev za rezkanje (ISO/DIS 23298:2021)
Dentistry - Test methods for machining accuracy of computer-aided milling machines
(ISO/DIS 23298:2021)
Zahnheilkunde - Prüfverfahren zur Bewertung der Genauigkeit von computergesteuerten
Fräsmaschinen (ISO/DIS 23298:2021)
Médecine bucco-dentaire - Méthodes d'essai pour l'exactitude d'usinage des fraiseuses
à commande numérique (ISO/DIS 23298:2021)
Ta slovenski standard je istoveten z: prEN ISO 23298
ICS:
11.060.01 Zobozdravstvo na splošno Dentistry in general
oSIST prEN ISO 23298:2022 en,fr,de
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

---------------------- Page: 1 ----------------------
oSIST prEN ISO 23298:2022

---------------------- Page: 2 ----------------------
oSIST prEN ISO 23298:2022
DRAFT INTERNATIONAL STANDARD
ISO/DIS 23298
ISO/TC 106/SC 9 Secretariat: JISC
Voting begins on: Voting terminates on:
2021-12-10 2022-03-04
Dentistry — Test methods for machining accuracy of
computer-aided milling machines
Médecine bucco-dentaire — Méthodes d’essai pour l’exactitude d’usinage des fraiseuses à commande
numérique
ICS: 11.060.01
This document is circulated as received from the committee secretariat.
THIS DOCUMENT IS A DRAFT CIRCULATED
FOR COMMENT AND APPROVAL. IT IS
ISO/CEN PARALLEL PROCESSING
THEREFORE SUBJECT TO CHANGE AND MAY
NOT BE REFERRED TO AS AN INTERNATIONAL
STANDARD UNTIL PUBLISHED AS SUCH.
IN ADDITION TO THEIR EVALUATION AS
BEING ACCEPTABLE FOR INDUSTRIAL,
TECHNOLOGICAL, COMMERCIAL AND
USER PURPOSES, DRAFT INTERNATIONAL
STANDARDS MAY ON OCCASION HAVE TO
BE CONSIDERED IN THE LIGHT OF THEIR
POTENTIAL TO BECOME STANDARDS TO
WHICH REFERENCE MAY BE MADE IN
Reference number
NATIONAL REGULATIONS.
ISO/DIS 23298:2021(E)
RECIPIENTS OF THIS DRAFT ARE INVITED
TO SUBMIT, WITH THEIR COMMENTS,
NOTIFICATION OF ANY RELEVANT PATENT
RIGHTS OF WHICH THEY ARE AWARE AND TO
PROVIDE SUPPORTING DOCUMENTATION. © ISO 2021

---------------------- Page: 3 ----------------------
oSIST prEN ISO 23298:2022
ISO/DIS 23298:2021(E)
COPYRIGHT PROTECTED DOCUMENT
© ISO 2021
All rights reserved. Unless otherwise specified, or required in the context of its implementation, no part of this publication may
be reproduced or utilized otherwise in any form or by any means, electronic or mechanical, including photocopying, or posting on
the internet or an intranet, without prior written permission. Permission can be requested from either ISO at the address below
or ISO’s member body in the country of the requester.
ISO copyright office
CP 401 • Ch. de Blandonnet 8
CH-1214 Vernier, Geneva
Phone: +41 22 749 01 11
Email: copyright@iso.org
Website: www.iso.org
Published in Switzerland
ii
  © ISO 2021 – All rights reserved

---------------------- Page: 4 ----------------------
oSIST prEN ISO 23298:2022
ISO/DIS 23298:2021(E)
Contents Page
Foreword .iv
Introduction .v
1 Scope . 1
2 Normative references . 1
3 Terms and definitions . 1
4 General . 2
5 Test methods . 2
5.1 Metal die method . 2
5.1.1 Target restorations. 2
5.1.2 Apparatus . 2
5.1.3 Measurement of metal dies . 5
5.1.4 Preparation of three-dimensional data . 5
5.1.5 Machining of restorations . 7
5.1.6 E valuation of accuracy . 8
5.2 Test methods for software method . 14
5.2.1 General . 14
5.2.2 Test object . . . 15
5.2.3 Equipment and apparatus . 18
5.2.4 Machining of specimens . 19
5.2.5 Measurement . 20
5.2.6 Data alignment procedures . 21
5.2.7 Data analysis procedure . 22
5.2.8 Calculation of total errors . 25
6 Test report .26
6.1 General information.26
6.2 Specific information.26
6.2.1 Die method . 26
6.2.2 Software method. 27
6.3 Averaged characteristic accuracy values. 27
6.3.1 Die method . 27
6.3.2 Software method. 27
Annex A (informative) Flow chart of test method .28
Annex B (normative) Measurement of die set(s) and preparation of CAD data of target
restoration(s) . . .30
Annex C (informative) Contents of test report .40
Bibliography . 44
iii
© ISO 2021 – All rights reserved

---------------------- Page: 5 ----------------------
oSIST prEN ISO 23298:2022
ISO/DIS 23298:2021(E)
Foreword
ISO (the International Organization for Standardization) is a worldwide federation of national standards
bodies (ISO member bodies). The work of preparing International Standards is normally carried out
through ISO technical committees. Each member body interested in a subject for which a technical
committee has been established has the right to be represented on that committee. International
organizations, governmental and non-governmental, in liaison with ISO, also take part in the work.
ISO collaborates closely with the International Electrotechnical Commission (IEC) on all matters of
electrotechnical standardization.
The procedures used to develop this document and those intended for its further maintenance are
described in the ISO/IEC Directives, Part 1. In particular the different approval criteria needed for the
different types of ISO documents should be noted. This document was drafted in accordance with the
editorial rules of the ISO/IEC Directives, Part 2 (see www.iso.org/directives).
Attention is drawn to the possibility that some of the elements of this document may be the subject of
patent rights. ISO shall not be held responsible for identifying any or all such patent rights. Details of
any patent rights identified during the development of the document will be in the Introduction and/or
on the ISO list of patent declarations received (see www.iso.org/patents).
Any trade name used in this document is information given for the convenience of users and does not
constitute an endorsement.
For an explanation on the voluntary nature of standards, the meaning of ISO specific terms and
expressions related to conformity assessment, as well as information about ISO's adherence to the
World Trade Organization (WTO) principles in the Technical Barriers to Trade (TBT) see the following
URL: www.iso.org/iso/foreword.html.
This document was prepared by Technical Committee ISO/TC 106, Dentistry, Subcommittee SC 9, Dental
CAD/CAD systems.
This document cancels and replaces ISO/TR 18845:2017 which have been technically revised.
The main changes compared to ISO/TR 18845:2017 are as follows:
— changing the type of document from Technical Report (TR) to International Standard (IS);
— specifying two test methods using metal dies and software as the normative test methods;
— clarification of selection guidance of test methods;
— revision of the detail procedures of both test methods based on the inter-laboratory test.
Any feedback or questions on this document should be directed to the user’s national standards body. A
complete listing of these bodies can be found at www.iso.org/members.html.
iv
  © ISO 2021 – All rights reserved

---------------------- Page: 6 ----------------------
oSIST prEN ISO 23298:2022
ISO/DIS 23298:2021(E)
Introduction
Dental CAD/CAM systems have been successfully used for the fabrication of indirect dental restorations
such as inlays, crowns and bridges. The accuracy of these restorations is one of the most important
factors for their clinical success. This document provides standardized test methods to evaluate the
machining accuracy of computer-aided milling machines which are used as a part of dental CAD/CAM
systems and the information to be provided by the manufacturer. A flow chart of test method is shown
in Annex A.
There are two methods using metal dies or software to evaluate machining accuracy of the target
restoration(s). Either or both test methods should be selected to evaluate the machining accuracy.
v
© ISO 2021 – All rights reserved

---------------------- Page: 7 ----------------------
oSIST prEN ISO 23298:2022

---------------------- Page: 8 ----------------------
oSIST prEN ISO 23298:2022
DRAFT INTERNATIONAL STANDARD ISO/DIS 23298:2021(E)
Dentistry — Test methods for machining accuracy of
computer-aided milling machines
1 Scope
This document specifies the test methods to evaluate the machining accuracy of computer-aided milling
machines as a part of dental CAD/CAM systems, which fabricate dental restorations, e.g. inlays, crowns
and bridges
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 1942, Dentistry — Vocabulary
ISO 18739, Dentistry — Vocabulary of process chain for CAD/CAM systems
ISO 25178-2, Geometrical product specifications (GPS) — Surface texture: Areal — Part 2: Terms, definitions
and surface texture parameters
3 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 1942, ISO 18739 and the
following apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https:// www .iso .org/ obp
— IEC Electropedia: available at https:// www .electropedia .org/
3.1
computer-aided milling machine
computer-aided machining device designed for subtractive manufacturing of dental prostheses using
rotary instruments for cutting and grinding
3.2
blank
material for machining on a computer-aided milling machine (3.1). It may be a block (3.3) or a disk (3.4)
3.3
block
cuboidal material with holding device for machining on a computer-aided milling machine (3.1)
3.4
disc
disc-shaped material for machining on a computer-aided milling machine (3.1)
3.5
stock material
material blanks (3.2) that are in stock for machining on a computer-aided milling machine (3.1)
1
© ISO 2021 – All rights reserved

---------------------- Page: 9 ----------------------
oSIST prEN ISO 23298:2022
ISO/DIS 23298:2021(E)
4 General
There are two methods to evaluate accuracy of the target restoration(s). The accuracy of target
restoration(s) shall be evaluated using one or both of the test methods described in Clause 5. The test
method(s) selected and corresponding results shall be provided in the instruction for use, the technical
manual or other means. When the machining accuracy is affected by the material, appropriate
material(s) shall be tested. Testing shall be performed on each material type that the manufacturer
indicates for use by the device. The metal die method (5.1) is a measurement method based on the
marginal adaptability of a machined restoration to a master die. Measurements obtained using this
method can be used to assess adaptability at restoration margins. The software method (5.2) is
a measurement method based on a comparison of the scanned file of milled restoration to a master
manufacturing file using reverse engineering software. Measurements obtained using this method can
be used to assess restoration margin, intaglio and external surface accuracy.
5 Test methods
5.1 Metal die method
5.1.1 Target restorations
Three types of restorations, a) Class II inlay, b) crown and c) four-unit/element bridge, are the targets
of this test method. Choose the restoration type(s) specified in the manufacturer’s instructions for
use, and technical manual. If any of the restoration types are not specified by the manufacturer’s
technical manual for the equipment being tested, this restoration type shall be eliminated from the test
procedure.
NOTE This test method is designed adopting the same principle as the examination method of clinical
marginal adaptation. The clinical adaptation is examined checking the discrepancy between the restoration and
the cavity margin or between it and the shoulder margin of abutment.
5.1.2 Apparatus
5.1.2.1 Metal dies
Two types of metal dies given in Figure 1 (Class II inlay) and Figure 2 (crown and four-unit/element
bridge dies) are used both for the preparation of three-dimensional data (manufacturing data set)
and the evaluation of the accuracy of restorations. Dies shall be constructed based on the drawings
in Figure 1 and Figure 2, these dies consist of a non-malleable metal die and one or more removable
structure(s) used for the evaluation of accuracy.
The diameter of the removable occlusal part shall be not less than the diameter of abutment and the
difference of diameter shall be not more than 10 μm.
The surface roughness (Sa) of the die, excepting the surfaces which do not come in contact with the test
specimens/machined restorations, shall be less than 2 μm. Refer to ISO 25178-2 and other parts for test
methods.
If a mark for reference point is necessary, either a groove or a ridge, or both, may be placed on the part,
but shall be placed so as to not influence the evaluation of the results.
The removal occlusal part and removable shoulder are used for preparation of three-dimensional data,
but not used for evaluation of accuracy.
NOTE An example of the machining device to fabricate the dies is Vertical Center NEXUS 410B.
2
  © ISO 2021 – All rights reserved

---------------------- Page: 10 ----------------------
oSIST prEN ISO 23298:2022
ISO/DIS 23298:2021(E)
Dimensions in millimetres
Key
1 metal die
2 removable part
3 positioning pin
4 fixing screw
Figure 1 — Die for class II inlay specimen
3
© ISO 2021 – All rights reserved

---------------------- Page: 11 ----------------------
oSIST prEN ISO 23298:2022
ISO/DIS 23298:2021(E)
Dimensions in millimetres
Key
1 metal die
2 abutment
3 removable occlusal part
4 removable shoulder
h height of removable shoulder
s
NOTE The recommended size of the height of removable shoulder (h ) is (3,6 ± 0,05) mm.
s
Figure 2 — Die for crown and bridge specimen
4
  © ISO 2021 – All rights reserved

---------------------- Page: 12 ----------------------
oSIST prEN ISO 23298:2022
ISO/DIS 23298:2021(E)
5.1.2.2 Measuring devices to be used for metal dies
Measuring devices with accuracy of ≤2 μm shall be used for measurement of metal dies (5.1.3).
Coordinate measuring machine (CMM) can be useful to measure the size of die.
NOTE An example of a CMM is America Strato-Apex 574.
5.1.2.3 Measuring devices to be used for discrepancy measurement
Measuring devices with accuracy of ≤5 μm shall be used for discrepancy measurement in 5.1.4. Three-
dimensional measuring microscopes, displacement meters and digital micrometers can be used.
5.1.3 Measurement of metal dies
Each die shall be measured using a measuring device specified in 5.1.2.2 to confirm the shape and
dimensions specified in Figure 1 or Figure 2. The specified dimensions of constructed die necessary
to prepare CAD data shall be measured in accordance with Annex B. The measured data are used to
prepare the three-dimensional data (see 5.1.4).
In case of the metal die for crown and bridge specimen, the height of removable shoulder (h in Figure 2),
s
and the height from the upper surface of the removable shoulder (4 in Figure 2) to the upper surface of
the removable occlusal part (3 in Figure 2) shall be measured.
5.1.4 Preparation of three-dimensional data
5.1.4.1 General
The surface to be in contact with the metal die of each specimen type is determined by the
measurements of the dies made in 5.1.3. The external surfaces of each specimen type are determined
by the sections 5.1.4.2 and 5.1.4.3.
5.1.4.2 Class II inlay
The shapes and sizes of test specimen of class II inlay shall conform to the cavity of metal die (see
Figure 1). The occlusal and proximal surfaces shall be the same planes with the corresponding surface
of the metal die.
5.1.4.3 Crown and bridges
The shapes and sizes of test specimen of the crown and the bridge shall conform to Figure 3 (crown)
and Figure 4 (bridge). A mark to distinguish direction when placing the restoration on the metal die
shall be made on the top surface of crown. In case of bridges, the mark shall be made on either crown.
5.1.4.4 Preparation of CAD data (STL data)
To fabricate the target restorations, a CAD data (STL data) for each of the restorations specified in-5.1.4.2
and 5.1.4.3 shall be prepared in accordance with Annex B. This CAD data-shall then be processed by the
CAM software to prepare the manufacturing data set. The CAD data-shall not be modified by the CAM
software.
The dimensions of any surfaces in contact with the die surfaces are obtained from the measuring
process in 5.1.3. Other dimensions are determined from Figure 3 and Figure 4.
The CAD data shall be prepared to ensure that the restoration meets the die without an allowance for
cement space.
5
© ISO 2021 – All rights reserved

---------------------- Page: 13 ----------------------
oSIST prEN ISO 23298:2022
ISO/DIS 23298:2021(E)
Dimensions in millimetres
Key
1 metal die
2 abutment
3 removable occlusal part
4 removable shoulder
5 test specimen
6 mark to distinguish direction
Figure 3 — Test specimen of crown
6
  © ISO 2021 – All rights reserved

---------------------- Page: 14 ----------------------
oSIST prEN ISO 23298:2022
ISO/DIS 23298:2021(E)
Dimensions in millimetres
Key
1 metal die
2 abutment
3 test specimen
4 mark to distinguish direction
Figure 4 — Test specimen of bridge
5.1.5 Machining of restorations
The prepared manufacturing data set shall be input into the computer-aided milling machine following
the manufacturer’s instruction. The CAM software shall use the same configuration and parameters
as is usually delivered. The target restoration shall be machined using the material specimen (blank)
following the manufacturer’s instruction.
NOTE 1 A manufacturer means a natural or legal person actually manufacturing a computer-aided milling
machine or a natural or legal person supplying necessary information to use the computer-aided milling machine.
The target restoration shall be the same size of the prepared manufacturing data set. CAM software
contains a scaling factor to compensate for shrinkage of material during an additional process such as
sintering. The CAM software scaling factor used in this test shall be 1,00.
This test is carried out using a computer-aided milling machine maintained in accordance with the
manufacturer’s instruction.
7
© ISO 2021 – All rights reserved

---------------------- Page: 15 ----------------------
oSIST prEN ISO 23298:2022
ISO/DIS 23298:2021(E)
The evaluation of accuracy (see 5.1.6) is carried out using the restoration without any after treatment
such as a sintering process. If any support structures are necessary for fabrication, they shall not be
positioned on the surface contacting the die and shall be removed before the measurement.
NOTE 2 Support structures are carefully removed using an appropriate rotary instrument such as a carbide
laboratory cutter.
Fabricate six specimens for each of the target restorations.
5.1.6 Evaluation of accuracy
5.1.6.1 General
The accuracy of the restorations is expressed by the discrepancy between the margin of a restoration
and baseline (cavity margin for inlays and abutment shoulder for crown and bridge).
The measurement of discrepancy is carried out using a measuring device specified in 5.1.2.3. The
measured value shall be expressed in millimetre to three decimal places. After each measurement, the
surface of metal die shall be cleaned.
When two or more dies for each restoration type are prepared, evaluation of accuracy shall always be
performed using restorations prepared from measurement data specific to that die set.
The surface of the metal die shall be cleaned after each measurement.
5.1.6.2 Class II inlay
Place the inlay in the cavity of a metal die and apply a load of (25 ± 1) N, distributed evenly on the
centres of occlusal and proximal surfaces simultaneously. Remove the load after (30 ± 1) s and examine
where the margin of the inlay is located.
V-shaped or M-shaped pressing device having inner corner of 90° with (4,5 ± 0,2) mm shall be used for
applying the load onto the occlusal and proximal surfaces of inlay simultaneously.
If necessary, the removable part portion of the inlay die should be retained with the fixation screw. See
Figure 1.
NOTE 1 Round edges of the loading tip are preferred.
NOTE 2 The use of weighing paper or a thin elastomeric sheet can be used at the interface of the loading tip
and inlay specimen.
When the occlusal margin of the inlay is located higher than the occlusal baseline (occlusal margin
of the die cavity), measure the discrepancy between the inlay margin and the occlusal baseline [+L
A
in Figure 5 a)]. Similarly, when the proximal margin of the inlay extends past the proximal baseline
(proximal margin of the die cavity), measure the discrepancy between the inlay margin and the
proximal baseline [+L in Figure 5 b)]. The measured values for both occlusal and the proximal
B
discrepancies are expressed as positive values.
When the occlusal and proximal margins of the inlay are located at the same level of the baseline or
beneath the baseline, remove the metal die (2 in Figure 5) and place the inlay in the removable part
(1 in Figure 5). Apply a load of (25 ± 1) N, distributed evenly on the occlusal and proximal surfaces
simultaneously, and remove it after (30 ± 1) s. Measure the discrepancies between the occlusal inlay
margin and the occlusal baseline [−L and -L in Figure 5 c)] and between the occlusal inlay margin and
A B
the proximal baseline [−L in Figure 5 d)]. The measured values are expressed as negative values. If the
B
inlay margin is located at the same level of the baseline, the discrepancy is 0,000 mm.
8
  © ISO 2021 – All rights reserved

---------------------- Page: 16 ----------------------
oSIST prEN ISO 23298:2022
ISO/DIS 23298:2021(E)
For both cases, measurements with and without metal die, the measurement shall be carried out at three
points for the occlusal discrepancy [see Figure 5 e)] and at four points for the proximal discrepancy [see
Figure 5 f)]. A discrepancy shall be measured as horizontal discrepancy judging from the top.
NOTE When a measuring microscope is used, the discrepancy in the Z-direction cannot be precisely
measured because of its poor focusing accuracy.
The measured discrepancy data (three points for the occlusal discrepancy and four points for the
proximal discrepancy) of one inlay are averaged to represent the discrepancy of that inlay. Calculate
the average of the six representative discrepancy values and the standard deviations to express the
accuracy of the inlay.
9
© ISO 2021 – All rights reserved

---------------------- Page: 17 ----------------------
oSIST prEN ISO 23298:2022
ISO/DIS 23298:2021(E)
a)  Occlusal discrepancy with metal die b)  Proximal discrepancy with metal die
c)  Occlusal and proximal discrepancy meas- d)  Proximal discrepancy measurements without
urements without metal die metal die
e)  Measurement points for occlusal discrep- f)  Measurement points for proximal discrepancy
ancy
Key
1 removable part
2 metal die
3 inlay
+L discrepancy between the occlusal baseline and the inlay margin which is higher than the occlusal baseline
A
-L discrepancy between the occlusal baseline and the inlay margin which is lower than the occlusal baseline
A
+L discrepancy between the proximal baseline and the inlay margin which locates outside of the proximal baseline
B
-L discrepancy between the proximal baseline and the inlay margin which locates inside of the proximal baseline
B
Figure 5 — Discrepancy measurement of class II inlay
10
  © ISO 2021 – All rights reserved

---------------------- Page: 18 ----------------------
oSIST prEN ISO 23298:2022
ISO/DIS 23298:2021(E)
5.1.6.3 Crown
Remove a removable occlusal part (3 in Figure 2) and a removable shoulder (4 in Figure 2) from the
metal die. Place the crown on the abutment of a metal die (2 in Figure 2) referring the mark, which can
distinguish the direction on the upper surface of crown, (see 5.1.4.3 and Figure 6 e)). Each crown to be
measured shall be oriented in the same direction. Apply a load of (25 ± 1) N for (30 ± 1)
...

Questions, Comments and Discussion

Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
