1 Scope
This document defines the grades of electrical steel strip and sheet with specified mechanical properties
and magnetic polarization. It specifies general requirements, mechanical properties, magnetic
polarization, geometric characteristics, tolerances and technological characteristics, as well as inspection
procedures.
This document applies to electrical steel strip and sheet for the construction of poles and rims of rotating
electrical machines.
The grades are grouped into two classes according to their manufacturing process:
— hot-rolled grades;
— cold-rolled grades.
NOTE These materials correspond to EN 60404-1:2017, D.2.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
EN 10021, General technical delivery conditions for steel products
EN 10027-2, Designation systems for steels — Part 2: Numerical system
EN 10204, Metallic products — Types of inspection documents
FprEN 10251:2023, Magnetic materials — Methods of determination of the geometrical characteristics of
electrical steel sheet and strip
EN 60404-2, Magnetic materials — Part 2: Methods of measurement of the magnetic properties of electrical
steel strip and sheet by means of an Epstein frame
EN 60404-4, Magnetic materials — Part 4: Methods of measurement of d.c. magnetic properties of
magnetically soft materials
EN ISO 6892-1, Metallic materials — Tensile testing — Part 1: Method of test at room temperature
(ISO 6892-1)
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— IEC Electropedia: available at https://www.electropedia.org/
— ISO Online browsing platform: available at https://www.iso.org/obp
oSIST prEN 10265:2024
prEN 10265:2023 (E)
3.1
edge wave
wave factor
variation of flatness of a length of strip or sheet taking a form of waves at the slit edge of the product after
longitudinal side trimming or slitting of the product; characterised by the wave factor, i.e. by the relation
of the height of the wave to its length
Note 1 to entry: For examples of waves, see Figure 1.
[SOURCE: FprEN 10251:2023, definition 3.1]
Key
1 flat surface h height of wave (mm)
2 sheet l length of wave (mm)
3 rolling direction
Figure 1 — Example of wave
3.2
residual curvature
variations of flatness of a length of unwound strip or a sheet taking a permanent curvature in the direction
of rolling of the product
[SOURCE: FprEN 10251:2023, definition 3.2]
3.3
edge camber
greatest distance between a longitudinal edge of a length of strip or a sheet and the line joining the two
extremities of the measured length of this edge
Note 1 to entry: See Figure 2.
[SOURCE: FprEN 10251:2023, definition 3.3]
oSIST prEN 10265:2024
prEN 10265:2023 (E)
Figure 2 — Verification of the edge camber
4 Classification
The grades covered by this document are classified according to the specified value of the minimum proof
strength R , in MPa , according to the specified value of the minimum magnetic polarization at a DC
p0,2
magnetic field strength of 15 000 A/m, in T, and according to the nominal thickness of the product ,
in mm.
The grades are classified in two groups according to their manufacturing process: hot-rolled materials
and cold-rolled materials.
5 Designation
5.1 The conventional design
...
