EN 14278-1:2004

Textiles - Determination of cotton fibre stickiness - Part 1: Method using a manual thermodetection device

The standard describes a manual technique to simulate the tendency of cotton fibres to stick  to textile working surfaces.
Test specimens can be raw cotton fibre  (fibre sampled e.g. from a bale), or opened fibre, slivers, etc.

Textilien - Bewertung der Klebrigkeit von Baumwolle - Teil 1: Verfahren mit dem manuellen Thermodetektionsgerät

Diese Norm beschreibt ein manuelles Verfahren zur Simulierung der Neigung von Baumwolle, an textilen Arbeits-flächen zu kleben.
Als Messproben können Fasern von Rohbaumwolle (z. B. aus einem Ballen entnommene Fasern), geöffnete Baumwollfasern, Baumwollfaserbänder usw. verwendet werden.

Textiles - Determination du collage des fibres de coton - Partie 1: Méthode utilisant un dispositif manuel de thermodétection

La présente norme décrit une technique manuelle permettant de simuler la tendance des fibres de coton à coller aux surfaces de travail textile.
Les éprouvettes peuvent être constituées de fibres brutes de coton (fibres échantillonnées à partir d'une balle, par exemple), ou de fibres ouvertes, de rubans, etc.

Tekstilije - Ugotavljanje lepljivosti bombažnih vlaken - 1. del: Metoda z ročno napravo za toplotno zaznavanje prisotnosti

General Information

• Status: Published
• Publication Date: 25-May-2004
• Withdrawal Date: 29-Nov-2004
• ICS: 59.060.10 - Natural fibres
• Technical Committee: CEN/TC 248 - Textiles and textile products
• Drafting Committee: CEN/TC 248/WG 19 - Characterisation of fibres
• Current Stage: 9060 - Closure of 2 Year Review Enquiry - Review Enquiry
• Start Date: 02-Dec-2025
• Completion Date: 02-Dec-2025
• Ref Project: SIST EN 14278-1:2004 - Textiles - Determination of cotton fibre stickiness - Part 1: Method using a manual thermodetection device

Overview

EN 14278-1:2004 is a CEN European Standard that specifies a manual thermodetection method for the determination of cotton fibre stickiness. Published in 2004, the method simulates the tendency of cotton fibres to adhere to textile working surfaces during processing. Test specimens may be raw cotton (e.g., bale samples), opened fibre, slivers or comparable preparations. Results indicate the incidence of sticky points but do not investigate the origins of stickiness or directly measure sugar content.

Key topics and technical requirements

• Principle: a fibre web of fixed surface area and mass is sandwiched between two aluminium foils and exposed to sequential heat and pressure to reveal sticky points, which are then counted.
• Apparatus:
  • Manual thermodetection device with a copper-plated aluminium platen and a heating plate (heating plate dimension specified).
  • Electromechanical opener and accessories to prepare a uniform fibre web (specified widths, cylinder speeds and teeth density).
  • Aluminium foil: matt surface, thickness ~15 ± 5 µm (or mass ~40 ± 13.5 g/m²).
  • Remover/cleaner (non-woven cover, 400 ± 20 g) and light source (110 ± 10 W, oblique illumination).
  • Fan to vibrate adhering fibres.
• Test conditions:
  • Conditioning and testing atmosphere as per EN 20139 (standard atmospheres for textiles).
  • Heating phase: 84 ± 4 °C, pressure ~780 ± 50 N, duration 12 ± 2 s.
  • Ambient compression: pressure ~590 ± 50 N for 120 ± 10 s.
  • Rest: ensemble allowed to rest ≥ 60 ± 5 min before counting.
• Specimen preparation:
  • Fibre web dimensions ~540 ± 20 mm × 160 ± 20 mm or target mass ~29.5 ± 4 g/m²; specimen mass 2.5 ± 0.05 g for trio of tests.
• Results:
  • Count sticky points on both foils, average across three specimens. Annex A describes statistical treatment (distribution often Poisson/negative binomial; square-root transform recommended for variance stabilization).

Applications

• Routine quality control and acceptance testing of cotton bales and opened fibre.
• Process troubleshooting where fibre stickiness affects spinning, carding or other textile operations.
• Comparative testing in supply chain management to screen lots before processing.
• Research and interlaboratory studies on stickiness measurement methods.

Who uses this standard

• Textile testing laboratories and quality assurance teams
• Spinning mills, carding and opening facilities
• Cotton traders, ginneries and bale sampling services
• Standards bodies and researchers involved in textile material characterization

Related standards

• EN 14278-2: Method using an automatic thermodetection plate device
• EN 14278-3: Method using an automatic rotating drum device
• EN 20139: Standard atmospheres for conditioning and testing

Keywords: EN 14278-1:2004, cotton fibre stickiness, manual thermodetection device, thermodetector, textiles standard, cotton stickiness test.

Standards Content (Sample)

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Textilien - Bewertung der Klebrigkeit von Baumwolle - Teil 1: Verfahren mit dem manuellen ThermodetektionsgerätTextiles - Determination du collage des fibres de coton - Partie 1: Méthode utilisant un dispositif manuel de thermodétectionTextiles - Determination of cotton fibre stickiness - Part 1: Method using a manual thermodetection device59.060.10Naravna vlaknaNatural fibresICS:Ta slovenski standard je istoveten z:EN 14278-1:2004SIST EN 14278-1:2004en01-julij-2004SIST EN 14278-1:2004SLOVENSKI
STANDARD
EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 14278-1May 2004ICS 59.060.10English versionTextiles - Determination of cotton fibre stickiness - Part 1:Method using a manual thermodetection deviceTextiles - Determination du collage des fibres de coton -Partie 1: Méthode utilisant un dispositif manuel dethermodétectionTextilien - Bewertung der Klebrigkeit von Bauwolle - Teil1:Verfahren mit dem manuellen ThermodetektionsgerätThis European Standard was approved by CEN on 23 February 2004.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the Central Secretariat or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the Central Secretariat has the same status as the officialversions.CEN members are the national standards bodies of Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France,Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Slovakia,Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2004 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 14278-1:2004: ESIST EN 14278-1:2004

Statistical analysis.11
Results of this method are not directly related to the determination of sugar content. This standard consists of the following methods, under the general title "Textiles - Determination of cotton fibre stickiness": • Part 1: Method using a manual thermodetection device • Part 2: Method using an automatic thermodetection plate device • Part 3: Method using an automatic rotating drum device SIST EN 14278-1:2004

3 Terms and definitions For the purposes of this European Standard, the following terms and definitions apply. 3.1 stickiness level number of sticky points indicating the incidence of cotton fibre
stickiness 3.2 thermodetection action of revealing sticky points through the combined application of heat and pressure 3.3 sticky points entanglement of fibres or individual fibres that are attached to a working surface as a result of the inherent stickiness of the cotton 3.4 ensemble upper and lower aluminium foils enclosing a fibre sample 3.5 remover device to take away the non sticking fibres from the counting surface 4 Principle A fibre web, whose surface area and mass are fixed, is placed between two sheets of aluminium foil and pressed at two pressure levels applied successively at different temperature settings to reveal sticky points. The sticky points are then counted to evaluate the level of stickiness. SIST EN 14278-1:2004

NOTE The test method has been developed from practice where values of the major parameters (i.e. applied forces, surface area, temperature and time) have been fixed. Deviation from these va
...
