Scope
This handbook identifies data sources and respective methods that can be used for reliability prediction
of components. It proposes suitable data sources and an application matrix for component families.
References
EN Reference Reference in text Title
EN 16601-00-01 ECSS-S-ST-00-01 ECSS - Glossary of terms
EN 16602-30 ECSS-Q-ST-30 Space product assurance - Dependability
EN 16602-40 ECSS-Q-ST-40 Space product assurance - Safety
EN 16602-60 ECSS-Q-ST-60 Space product assurance - Electrical, electronic and
electromechanical (EEE) components
IEC 60050-191 International Electrotechnical Vocabulary - Chapter
191: Dependability and quality of service
Terms, definitions and abbreviated terms
3.1 Terms from other documents
For the purpose of this document, the terms and definitions from ECSS-S-ST-00-01 and IEC 60050-191
apply.
3.2 Abbreviated terms
For the purpose of this document, the abbreviated terms from ECSS-S-ST-00-01 apply.
Selection of reliability data and methods
4.1 Introduction
This handbook can be used whenever EEE and mechanical components reliability data or failure rates
are needed to perform quantitative dependability or safety analyses in accordance with ECSS-Q-ST-30
or ECSS-Q-ST-40.
The boundaries of this process are shown in Figure 4-1. Inputs are project requirements, handbook data
and manufacturer or user data. The selection process should consider selection criteria and methods of
use of data. Outputs are usually included in equipment reliability assessments. Selection is supported
by suitable justification.
Project
Requirements
Selection
Criteria
Equipment
Reliability
Assessment
Handbook
Methods for use of
Data and Selection Process
data
Methods
Justification
ECSS-Q-HB-30-08 Perimiter Outputs
Manufacturer/
User Data
Figure 4-1: Boundaries of ECSS-Q-HB-30-08 (inputs and outputs)
4.2 Selection process
The selection of a suitable methodology is made according to Figure 4-2. Where the customer requires
that a reliability prediction be computed according to a particular methodology, contractual
requirements are applicable.
The term “methodology” includes the process, data and equations as defined in a particular handbook
or prediction system.
Does the methodology
Does customer require any Use the required
Yes adequately address the Yes
particular methodology? methodology
component?
No
Use this document to select
Use the selected
No between a particular handbook or
methodology
manufacturing data
Figure 4-2: Selection process
In the case where there is no prescribed methodology, this handbook should be applied and a suitable
methodology should be selected.
In the case where the prescribed methodology does not adequately address the component under
consideration, this handbook should be applied and a suitable methodology should be selected.
In order to perform any reliability predictions, reliability data is needed as an input, and a suitable
methodology needs to be applied.
Figure 3 shows the decision logic that should be applied when selecting data sources. Data should be
obtained from the following sources, in order of preference:
• Handbook data
• Manufacturer or user data.
Start
Collect data on
Collect data on
application
components used
environment
Use scoring system
to examine
applicability of
methodology
Is there an applicable
Yes Use it
methodology
No
Use manufacturer/
User data
Figure 4-3: Decision logic
A description of data sources is given in clause 4.3.
The choice of a given data source is acceptable if it satisfies the criteria listed in clause 4.4. Data on the
handbook methodology, the components, environment and use should be collected. A suitable
methodology can be selected by using a weighted score ranking scheme, as described in clause 4.4.1.
The rationale for selection is justified according to clause 4.5.
A suitable methodology or instructions for use is described in clause 4.6.
If a handbook is determined to be not suitable for the component, then manufacturer or user data should
be used.
